- Page 1 FACTORY AUTOMATION MANUAL IO-Link RFID Reader, HF 13.56 MHz, ISO 15693 IQT1-18GM-IO-V1 IQT1-F61-IO-V1 IQT1-FP-IO-V1...
- Page 2 IO-Link RFID Reader, HF The latest version of the General Terms of Delivery for Products and Services of the Electrical Industry set out by the German Electrical and Electronic Manufacturers' Association (ZVEI), and the "Extended Retention of Title" clause apply to this document.
-
Page 3: Table Of Contents
Intended Use ..........................6 General Safety Information......................6 Special Safety Instructions ......................7 3.4.1 IQT1-*-IO-V1......................... 7 3.4.2 IQT1-18GM-IO-V1......................... 7 Product Description ..........................8 Indicators and Operating Elements....................8 Connection ........................... 9 Accessories ..........................9 Installation ............................10 Storage and Transportation ......................10 Unpacking ...........................10... -
Page 4: Introduction
IO-Link RFID Reader, HF 1 Introduction Congratulations You have decided to purchase a device from Pepperl+Fuchs. Pepperl+Fuchs develops, produces, and markets electronic sensors and interface modules worldwide for the automation technology market. Please read the instruction manual carefully before installing this device and putting it into operation. -
Page 5: Declaration Of Conformity
This product was developed and manufactured in line with the applicable European standards and Directives. Important note! A Declaration of Conformity may be requested from the manufacturer. The product manufacturer, Pepperl+Fuchs GmbH, 68307 Mannheim, Germany, has a certified quality assurance system that conforms to ISO 9001. FCC and IC Information NOTICE: This device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s). -
Page 6: Safety
Make sure that the device cannot be inadvertently switched on again. If the device needs to be repaired, return it to Pepperl+Fuchs. The device may only be connected by a qualified electrical specialist. The same applies for any maintenance work that needs to be carried out when the system is live. -
Page 7: Special Safety Instructions
The read/write head is supplied with power via the IO-Link master. For technical details, refer to the product datasheet. 3.4.2 IQT1-18GM-IO-V1 Warning! Hot parts! Be careful not to burn your fingers when handling the device! After shutting down the device,... -
Page 8: Product Description
These products have RFID read/write heads with an IO-Link interface. The read/write heads write and read read/write tags within a frequency range of 13.56 MHz according to ISO 15693. The devices are connected via M12 plugs. Figure 4.1 IQT1-18GM-IO-V1 Figure 4.2 IQT1-F61-IO-V1 Figure 4.3... -
Page 9: Connection
According to the IO-Link standard, the connection line may be up to 20 meters long. Accessories You can connect the IQT1-*-IO-V1 read/write heads to any IO-Link master. The following IO- Link masters are available from Pepperl+Fuchs: IO-Link-Master02-USB IO-Link master for connection to higher-level devices via USB... -
Page 10: Installation
1. Attach the IQT1-F61-IO-V1 read/write head using two screws or the IQT1-FP-IO-V1 using four screws by feeding the screws through the mounting holes in the housing. Attach the IQT1-18GM-IO-V1 read/write head using suitable mounting materials, e.g., nuts or mounting aids. -
Page 11: Operation
IO-Link RFID Reader, HF Operation General Information about Tag Types Read/Write Tag 13.56 MHz (Inductive) Read/write tags in this frequency range offer a considerably higher reading speed than read/write tags for the 125 kHz system. Since this is a non-proprietary system, cost-effective read/write tags are available from many third-party manufacturers. -
Page 12: Io-Link
IO-Link RFID Reader, HF IO-Link The IQT1-*-IO-V1 read/write heads support IO-Link version 1.1. SIO mode is not supported. The process data size is always 32 bytes in/out. IO-Link Easy Mode Easy mode enables the intuitive commissioning of the read/write head without a function block. - Page 13 IO-Link RFID Reader, HF Choose read command This parameter defines the read command that the write/read head will perform at the next reading. Value range: UID, user memory Default value: UID Choose write command This parameter defines the write command that the read/write head will perform at the next writing.
- Page 14 IO-Link RFID Reader, HF Output Frame Byte Contents Write Read Occupied Occupied Occupied Write data … Write data Write data Byte 0 is composed of eight control bits. Six bits are currently unused. Read: As long as the read bit value is set to true, the configured read command will be executed.
-
Page 15: Timing
IO-Link RFID Reader, HF Frame length: Contains the number of valid bytes of data read in the input frame. Bytes 2 and 3 are not used and are allocated zero, because some controls such as the Rockwell Collins controls operate on four bytes. Read data: Bytes 4 to 31 contain the data in hexadecimal form, which is read by the read/write head from the read/write tag using the configured write command. - Page 16 The PACTware software is used to operate the system and can be downloaded here from the Pepperl+Fuchs website. Install the software on your PC. Now install the driver for the IO-Link master and the IODD file for the read/write head on your computer. The driver and the IODD file can be found on the corresponding product page.
- Page 17 IO-Link RFID Reader, HF Select the Online Parameterization menu option.
- Page 18 IO-Link RFID Reader, HF The read/write head automatically starts reading the UID of the read/write tags. The data can be found in the input frame of the process data.
- Page 19 IO-Link RFID Reader, HF DOCT-5706A 06/2017...
