Page 1: Table Of Contents
All-in-one Convenience Cold, Ambient and Hot Water Dispenser with UV Operation Manual REN- HCA2200 Page Contents Preface / Parts Installation Safety Reminder Operation Method Replacement of UV Replacement of Filter 6, 7 Cleaning ＆ Maintenance 8, 9 Directions for Use 11- 15 Operation and Setting Please read these instructions completely before operating this unit... -
Page 2: Preface/Parts
Preface/Parts Before using this water dispenser , we advise you to read this manual thoroughly. Please follow the instructions to ensure proper operation and the lasting of the dispenser. Top Cover UV (inside) Safety Lock IC Board Control Panel Cold - Water Button Ambient - Water Button... -
Page 3: Installation
Installation Standard Installation of Tap Diverter Valve Gasket Connecting divertor to Adapter ourside threads on faucet Faucet Gasket adapters (use size as needed) Adapter Swivel Collar Handle Swivel Collar Remove Handle Existing Diverter valve 1/4” PE Aerator Diverter valve Water Pipe Installation using Under Sink Tri - way Socket 1. -
Page 4: Safety Reminder
Safety Reminder Leave a space no less than 15cm between Keep the machine away the wall and dispenser. from sunlight, heat, and wetness. Be sure to use single If the supply cord is damaged, it outlet socket with must be replaced by a special correct power cord or assembly available from voltage. -
Page 5: Operation Method
Operation Method 1. Turn on the main power switch for electricity but keep the power switches Cold Power Switch for hot and cold water OFF. These Hot Power Switch switches are found on the back of the dispenser. Next, turn on the water supply to allow water to fill up the tanks in the dispenser. -
Page 6: Replacement Of Uv
Replacement of UV Lamp When hearing the alarm from the dispenser, the WARN sign will flash to indicate malfunction. To replace UV Lamp, please disconnect the machine from the electricity before starting any procedures. First, press the button as directed in #1 to open the top cover. Second, follow steps #2, #3 and #4 to remove the UV cover. -
Page 7: Replacement Of Filter
Replacement of Filter When hearing the alarm from the dispenser, the WARN sign will flash to indicate filters need to be changed. To replace filters, please turn off the dispenser from the electricity before starting any procedures. First, press the button from behind the unit (as directed) in order to open the top cover. - Page 8 Replacement of Filter Place back the new filter into filter place. Push the filter head down until you hear the ‘click’ sound to secure filter position. Then you need to reset the day counter and flow meter back to “0000”. Hold the safety lock button and Set switch for 3 seconds until you hear 5 beep sounds.
-
Page 9: Cleaning & Maintenance
Cleaning & Maintenance 1. When drip collector is full, the water dispenser will make 3 long beeping sounds every 30 seconds. The FULL sign will be shown on the display. Please place the drip tray back and press the drip collector to let it to pop out (shown by arrow A). - Page 10 Cleaning & Maintenance 1. Please make sure the water dispenser is completely disconnected from electricity before cleaning. Hot Water Drain Caps Cold Water Drain 2. Remove the caps on top of the hot water and cold water drains. The remaining water in the tanks will drain out. Cleaning may start when both tanks are emptied.
-
Page 11: Directions For Use
Directions for Use This unit may provide water to containers of all sizes. When filling a small container or cup, simply open the drip tray (as shown). If the container is taller or bigger, please keep the drip tray and fill it directly under the dispensing point (as shown) Drip Tray... -
Page 12: Operation And Setting
Operation and Setting 1. Machine On All functions and signs on the screen are shown. Then according to each model to display its functions, cold and hot temperature, UV, Filter and enegy saving indicator. 2. Descriptions Hot water in use. The 98 C next to it is the hot water temperature. - Page 13 Operation and Setting 3. Setting Safety Lock To adjust hot water temperature, press set one time to indicate current hot water temperature. Press set again and hold for 3 seconds the temperature may be changed from 80 to 100 Default setting is 100. To complete setting, press set and hold for 3 seconds.
- Page 14 Operation and Setting 4. Energy Saving Turn on When energy saving is off, hold the lock button and press set to turn on. Turn off When energy saving is on, hold the lock button and press set to turn off. •...
- Page 15 Operation and Setting 7. Errors C101 Problem to the hot temperature control, not connected or over 105 C102 Temperature rises too quickly or empty heating. Will return to normal when water is added. Please contact distributor when error keeps appearing. C103 Constant heating for 1 hour or not reaching the set temperature.
- Page 16 For more advanced technical support, WhatsApp +65 8100 6600 For more information, please contact our H2O LIFE SOURCE office: H2O LIFE SOURCE (SEA) PTE LTD No 38 Jalan Pemimpin www.h2olifesource.com #06-02 @ M38 Singapore 577178 SINGAPORE |MALAYSIA | PHILIPPINES |...
