Daniels Electronics Ltd. OST-3H035 Instruction Manual

Enhanced am/fm synthesizer. 29 - 470 mhz
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MT-3 RADIO SYSTEMS
Copyright © 2000 Daniels Electronics Ltd. All rights reserved. No part of this publication may be
reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written consent of Daniels
Electronics Ltd.
DE™ is a registered trademark of Daniels Electronics Ltd. registered in the United States Patent and
Trademark Office.
Issue:
3
Issue Date:
March 2000
Printing Date:
March 2000
Part No.:
IM10-OS3AH
DANIELS
ELECTRONICS LTD.
ENHANCED AM/FM
SYNTHESIZER
INSTRUCTION MANUAL
OS(R/T)-3(A/H) 29 - 470 MHz
Covers models:
OST-3H035, OST-3H045, OSR-3H061
OST-3A128, OSR-3A149
OST-3H141, OST-3H162, OSR-3H141, OSR-3H162
OST-3H440, OSR-3H440
Previous Issue:
Previous Issue Date: March 1998
TM
2
Daniels Electronics Ltd.
Victoria, BC.
PRINTED IN CANADA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OST-3H035 and is the answer not in the manual?

Questions and answers

Related Manuals for Daniels Electronics Ltd. OST-3H035

Summary of Contents for Daniels Electronics Ltd. OST-3H035

  • Page 1 ENHANCED AM/FM SYNTHESIZER INSTRUCTION MANUAL OS(R/T)-3(A/H) 29 - 470 MHz Covers models: OST-3H035, OST-3H045, OSR-3H061 OST-3A128, OSR-3A149 OST-3H141, OST-3H162, OSR-3H141, OSR-3H162 OST-3H440, OSR-3H440 Copyright © 2000 Daniels Electronics Ltd. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written consent of Daniels Electronics Ltd.
  • Page 2 Reviewed By: Quality Assurance: Claudia Boorman _________________ Name Signature Date NOTE: The user's authority to operate this equipment could be revoked through any changes or modifications not expressly approved by Daniels Electronics Ltd. The design of this equipment is subject to change due to continuous development. This equipment may incorporate minor changes in detail from the information contained in this manual.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Page GENERAL..................1-1 1.1 Introduction...................1-1 1.2 OS(R/T)-3(A/H) Enhanced Synthesizer Family Models ........1-1 1.3 Performance Specifications ..............1-3 1.4 Printed Circuit Board Numbering Convention ...........1-4 THEORY OF OPERATION..............2-1 2.1 Internal Power and Control (Digital Board)..........2-1 2.2 Synthesizer Analog Circuitry (Analog Board)..........2-1 2.2.1 Common Analog Board Circuitry............2-1 2.2.2 29 - 71.4 MHz Analog Board Circuitry ..........2-3 2.2.3 118 - 159.4 MHz Multichannel AM Analog Board Circuitry......2-3...
  • Page 4 ILLUSTRATIONS AND SCHEMATIC DIAGRAMS........4-1 4.1 OS(R/T)-3H 29 - 71.4 MHz Analog Board Diagrams ........4-1 4.1.1 OS(R/T)-3H 29 - 71.4 MHz Analog Board Component Layout (Bottom) ..4-1 4.1.2 OS(R/T)-3H 29 - 71.4 MHz Analog Board Component Layout (Top) .... 4-2 4.1.3 OS(R/T)-3H 29 - 71.4 MHz Analog Board Schematic Diagram....

  • Page 5: General

    The eleven models are described as follows: Frequency Band: 29 - 50 MHz, Common OS-3H0xx Analog Board • OST-3H035 - synthesized, installed in transmitter, 29 - 38 MHz RF output. • OST-3H045 - synthesized, installed in transmitter, 38 - 50 MHz RF output.
  • Page 6 Frequency Band: 118 - 159.4 MHz, AM Multichannel OS-3H1xx Analog Board • OST-3A128 - synthesized, installed in AM transmitter, 118 - 138 MHz RF output. • OSR-3A149 - synthesized, installed in AM receiver, 139.4 - 159.4 MHz RF output. Frequency Band: 118 - 174 MHz, Common OS-3H1xx Analog Board •...

  • Page 7: Performance Specifications

    VCO and PLL technology. Compatible with Daniels MT-3 series transmitter and receiver modules. Frequency Range: 29 MHz - 38 MHz [± 0.5 MHz] (OST-3H035) Tuning range with no adjustment 38 MHz - 50 MHz [± 1.0 MHz] (OST-3H045) shown in [ ] brackets.

  • Page 8: Printed Circuit Board Numbering Convention

    1.4 Printed Circuit Board Numbering Convention To ease troubleshooting and maintenance procedures, Daniels Electronics Limited has adopted a printed circuit board (PCB) numbering convention in which the last two digits of the circuit board number represent the circuit board version. For example: •...

  • Page 9: Theory Of Operation

    THEORY OF OPERATION 2.1 Internal Power and Control (Digital Board) Refer to "OS(R/T)-3(A/H) Digital Board Schematic Diagram" in section 4 page 19. The synthesizer operates from +9.5 Vdc applied to connector pin P1-2. Total current drain is approximately 160 mA (65 ma for AM). Power Down control (P2-4) controls the +5.0 Vdc microcontroller regulator U2 through power MOSFET switch U1.
  • Page 10 (Analog Board) and jumper JU2 (AM Analog Board only) installed. The external reference source may be 9.6 MHz or 10.0 MHz through selection of jumper JU2 (Digital Board); install jumper JU2 (Digital Board) for 10.0 MHz reference selection. If an external signal is used for the reference source, it must be of low phase noise, high stability, with a level of 0 dBm ±...

  • Page 11: 71.4 Mhz Analog Board Circuitry

    C53, C57, C58, C59, L11, and L13. The six pole output filter provides a 50 MHz (OST-3H035, OST-3H045 TX) or 80 MHz (OSR-3H061 RX) cutoff frequency which reduces harmonic output to acceptable levels. SMB connector J2 provides interconnection to the companion transmitter or receiver with an output level of ≈...

  • Page 12: 128 - 174 Mhz Analog Board Circuitry

    diodes D1 and D2. Coarse frequency adjustment is provided by varactor diodes D6, D7. Select capacitor values C40 or C23 are chosen to position the operating frequency in one of two bands; 118 - 138 MHz, and 139.4 - 159.4.MHz. Varactor diodes D1 and D2 provide fine oscillator frequency control.

  • Page 13: 406 - 470 Mhz Analog Board Circuitry

    division ratio, established by the resistive dividers R21 and R22, allows low deviation (less than 5 kHz) direct frequency modulation of the VCO output signal. The PLL lowpass filter is formed from select component values C37, C38, C39, C45, R32, and R36.

  • Page 14: Synthesizer Digital Circuitry (Digital Board)

    2.3 Synthesizer Digital Circuitry (Digital Board) Refer to the "OS(R/T)-3(A/H) Digital Board Schematic Diagram" on page 4-19. Microcontroller U4 provides control of the synthesizer module. It communicates with synthesizer IC U10, monitors the synthesizer lock detect, manages PTT input/output, and determines the operating frequency from either four rotary BCD switches or four externally driven channel select lines.

  • Page 15: Frequency Select Handle Frequency Control

    The Base Frequency is the lowest frequency of any given synthesizer model. Model Number Freq. Range Base Frequency Freq. Increment OST-3H035 29 - 38 MHz 29 MHz 5.0/6.25 kHz OST-3H045 38 - 50 MHz 29 MHz 5.0/6.25 kHz...

  • Page 16: 6.25 Khz Channelization

    2.6 5.0/6.25 kHz Channelization. The operating frequency is determined as follows for Synthesizers having 5.0/6.25 kHz channel increment capability; • for BCD switch settings (in the range of 0000 to 4999 , multiply the switch setting by 5.0 kHz and add it to the synthesizer base frequency. Example: An OST-3H141 synthesizer has a base frequency of 128 MHz.

  • Page 17: Khz Channelization

    2.8 12.5 kHz Channelization. The operating frequency is determined as follows for Synthesizers having 12.5 kHz channel increment capability; • Multiply the BCD switch setting by 12.5 kHz and add it to the synthesizer base frequency. Example: An OST-3H440 synthesizer has a base frequency of 406 MHz. The selected channel number is 1978.
  • Page 18 This Page Intentionally Left Blank DANIELS ELECTRONICS 2-10 Enhanced AM/FM Synthesizer Instruction Manual OS(R/T)-3(A/H) 29 - 470 MHz...

  • Page 19: Synthesizer Alignment

    SYNTHESIZER ALIGNMENT 3.1 General OS(R/T)-3(A/H) enhanced synthesizer alignment is simplified by using a Type 84 subrack and RF extender card/cable to provide receiver or transmitter power and signal interconnection. Alternatively, +9.5 Vdc may be applied directly to a receiver or transmitter module through positive connection to pins B6 / Z6, and negative connection to pins B30 / Z30 / B32 / Z32.

  • Page 20: Os(R/T)-3(A/H) Synthesizer Alignment

    The corresponding internal synthesizer jumper settings are: Digital Board • Jumper JU2 not installed 9.6/10 MHz reference frequency, 9.6 MHz selected • Jumper JU1 installed AM Multichannel mode selected Analog Board • Jumper JU1: 'B' position Internal/External reference. Internal selected •...

  • Page 21: Synthesizer Removal And Installation

    3.5.3 Synthesizer Removal and Installation The synthesizer module is fastened to the main board (MT-3 Receiver IF/Audio Board or MT-3 Transmitter Main board) with a single counter sunk Phillips machine screw accessible from the top cover. Remove this screw to remove the synthesizer module. Using a plastic coated lifting tool, such as a small screwdriver with the tip covered in heat shrink material, gently lift the synthesizer module from the main circuit board by applying pressure in a rotating fashion about four corners of the synthesizer module.

  • Page 22: Vhf Os(R/T)-3H 29 - 71.4 Mhz Vco Alignment

    unstable or spurious RF output signal. The "Unlocked" red LED will also be illuminated when the PLL is unlocked. Check that the requested channel number is within the frequency range of the particular synthesizer model. An unlocked condition may be rectified by adjusting the VCO tuning elements as described in the following procedures (no adjustment requires for the multichannel AM Synthesizers).

  • Page 23: Vhf Os(R/T)-3A 118 - 159.4 Mhz Alignment

    3 . 5 . 5 . 2 VHF OS(R/T)-3A 118 - 159.4 MHz Alignment Refer to the "OS(R/T)-3A 118 - 159.4 MHz Analog Board Component Layout" diagrams and the "OS(R/T)-3A 118 - 159.4 MHz Analog Board Schematic Diagram" located in section 4 on pages 5, 6, and 7.

  • Page 24: Uhf Os(R/T)-3H 406 - 470 Mhz Vco Alignment

    3 . 5 . 5 . 4 UHF OS(R/T)-3H 406 - 470 MHz VCO Alignment Refer to the "OS(R/T)-3H 406 - 470 MHz Analog Board Component Layout" diagrams and the "OS(R/T)-3H 406 - 470 MHz Analog Board Schematic Diagram" located in section 4 on pages 13, 14 and 15.
  • Page 25 External reference input . Install jumper JU1-A, JU2 on Analog Board. This mode is used in applications requiring better than ±1 ppm frequency stability. An external 9.6/10.0 MHz reference signal must be provided at synthesizer SMB connector J1. (Located on the Analog Board) Reference Frequency Select .
  • Page 26 This Page Intentionally Left Blank DANIELS ELECTRONICS Enhanced AM/FM Synthesizer Instruction Manual OS(R/T)-3(A/H) 29 - 470 MHz...

  • Page 27: Illustrations And Schematic Diagrams

    ILLUSTRATIONS AND SCHEMATIC DIAGRAMS OS(R/T)-3H 29 - 71.4 MHz Analog Board Diagrams 4.1.1 OS(R/T)-3H 29 - 71.4 MHz Analog Board Component Layout (Bottom) + C50 J211 1.5µH 22µF 4.7µH 4.7µH 180R 22µF 180R 1.5µH 10µH 1-14pF 10µH 470nF 1.0µF 1.0µF 1.0µF C48 SEL 22µF...

  • Page 28: Os(R/T)-3H 29 - 71.4 Mhz Analog Board Component Layout (Top)

    4.1.2 OS(R/T)-3H 29 - 71.4 MHz Analog Board Component Layout (Top) Remove seven M2.0 machine screws to 330pF remove analog board. 15K0 10nF 33R2 MMBD701L BYD17J 10R0 3.3pF 274R 49R9 330pF 330pF 47pF 22pF 12pF 27R4 TRANSMITTER RECEIVER 33pF MSA-0611 47R5 47R5 330pF...

  • Page 29: Os(R/T)-3H 29 - 71.4 Mhz Analog Board Schematic Diagram

    AGND AGND AGND AGND AGND 10K0 10R0 1.0nF TRANSMITTER RECEIVER DESIGNATION OST-3H035 OST-3H045 OSR-3H061 TX 29 - 40 MHz TX 39 - 50 MHz TX 50.4 - 71.4 MHz EXTERNAL REFERENCE 100 pF INPUT (50Ω) 150 pF 56 pF 56 pF...
  • Page 30 This Page Intentionally Left Blank DANIELS ELECTRONICS Enhanced AM/FM Synthesizer Instruction Manual OS(R/T)-3(A/H) 29 - 470 MHz...

  • Page 31: Os(R/T)-3A 118 - 159.4 Mhz Analog Board Diagrams

    OS(R/T)-3A 118 - 159.6 MHz Analog Board Diagrams 4.2.1 OS(R/T)-3A 118 - 159.6 MHz Analog Board Component Layout (Bottom) 1.5uH J211 1.5uH 22uF 1.5µH 330R 680nF 1.5uH C49 SEL 1.5uH 680R LED1 10uH SELECT COMPONENTS AM TX AM RX DESIG. 118 - 138 MHz 139.4 - 159.4 MHz OST - 3A130-10...
  • Page 32 4.2.2 OS(R/T)-3A 118 - 159.6 MHz Analog Board Component Layout (Top) Select values Remove seven M2.0 MMBD701L machine screws to 11k8 remove analog board. 10R0 27pF 49R9 MSA-0611 330pF 100µF 100µF BYD17J 6.8µF 10R0 3.3pF 47pF 47nH 10nF 330pF 1k82 10R0 2.2µF 10nF...

  • Page 33: Os(R/T)-3A 118 - 159.4 Mhz Analog Board Schematic Diagram

    +8VA C32 AND C33 ARE SURFACE MOUNT OR THROUGH HOLE PARTS 4.2.3 OS(R/T)-3A 118 - 159.4 MHz Analog Board Schematic Diagram +8VA +8VA + C42 22uF 10nF AGND SI9945DY TO ALL +8VA SUPPLY POINTS 10nF 10R0 100nF +5VB +8VA BYD17J AGND AGND OUTPUT...
  • Page 34 This Page Intentionally Left Blank DANIELS ELECTRONICS Enhanced AM/FM Synthesizer Instruction Manual OS(R/T)-3(A/H) 29 - 470 MHz...

  • Page 35: Os(R/T)-3H 128 - 174 Mhz Analog Board Diagrams

    OS(R/T)-3H 128 - 174 MHz Analog Board Diagrams 4.3.1 OS(R/T)-3H 128 - 174 MHz Analog Board Component Layout (Bottom) + C50 J211 22µF 1.5µH 100µF 100µF 180R 1.5µH 22µF 180R 1.5µH 1.5µH 1-14pF 330R 1.5µH 1.0 µF C49 SEL 22µF 220R 680R 1.5µH...

  • Page 36: Os(R/T)-3H 128 - 174 Mhz Analog Board Component Layout (Top)

    4.3.2 OS(R/T)-3H 128 - 174 MHz Analog Board Component Layout (Top) C24 Fine Frequency Adjust Select values Remove seven M2.0 machine screws to 11k8 330pF remove analog board. 27pF 10nF 33R2 BYD17J MMBD701L 10R0 47nH 6.8µF 49R9 330pF 330pF 27R4 274R 18R2 10nF...

  • Page 37: Os(R/T)-3H 128 - 174 Mhz Analog Board Schematic Diagram

    4.3.3 OS(R/T)-3H 128 - 174 MHz Analog Board Schematic Diagram +8VA +8VA SI9945DY +8VA AGND MODULATION INPUT OUTPUT TO ALL +8VA SUPPLY POINTS 10R0 BYD17J 10uH 22uF 10nF 11K8 4.7uF 180R SHDN 1.0nF AGND AGND AGND AGND 100uF 100uF 3.5 dB Pad +8VA 1.5uH MSA-0611...
  • Page 38 This Page Intentionally Left Blank DANIELS ELECTRONICS 4-12 Enhanced AM/FM Synthesizer Instruction Manual OS(R/T)-3(A/H) 29 - 470 MHz...

  • Page 39: Os(R/T)-3H 406 - 470 Mhz Analog Board Diagrams

    OS(R/T)-3H 406 - 470 MHz Analog Board Diagrams 4.4.1 OS(R/T)-3H 406 - 470 MHz Analog Board Component Layout (Bottom) 180R + C50 22µF VCO INSTALLED (U17) 100µF 100µF 1.5µH 1.5µH RX 427.4 - 451.4 MHz TX 406 - 470 MHz LVCO-2309 TEV VCO-190-435 MT 22µF...

  • Page 40: Os(R/T)-3H 406 - 470 Mhz Analog Board Component Layout (Top)

    4.4.2 OS(R/T)-3H 406 - 470 MHz Analog Board Component Layout (Top) 10nF 33R2 BYD17J 10nF 18R2 MSA-0611 10R0 274R 274R 330pF 10pF 274R 18R2 100pF 330pF 27R4 47R5 47R5 330pF 18nH 15pF 330pF 10R0 274R 18R2 MSA-0611 10nF 33R2 10pF 18nH 47R5 330pF...

  • Page 41: Os(R/T)-3H 406 - 470 Mhz Analog Board Schematic Diagram

    4.4.3 OS(R/T)-3H 406 - 470 MHz Analog Board Schematic Diagram +8VA +8VA SI9945DY +8VA AGND MODULATION INPUT OUTPUT TO ALL +8VA SUPPLY POINTS 10R0 BYD17J 10uH + C12 22uF 10nF 11K8 4.7uF 180R Band Pass Filter SHDN 1.0nF (Optional) AGND AGND AGND AGND...
  • Page 42 This Page Intentionally Left Blank DANIELS ELECTRONICS 4-16 Enhanced AM/FM Synthesizer Instruction Manual OS(R/T)-3(A/H) 29 - 470 MHz...

  • Page 43: Os(R/T)-3(A/H) Digital Board Diagrams

    OS(R/T)-3(A/H) Digital Board Diagrams 4.5.1 OS(R/T)-3(A/H) Digital Board Component Layout (Bottom) 100nF 4.7uF MC33064 27k4 6k81 BC817 27k4 P1 1ROW x 12P 1ROW x 9P 22pF 8.0Mhz 10M0 68HC11E2 22pF OPL550 27k4 27k4 27k4 OP140A 10k0 BAS16 BC817 OP140A 1ROW x 6P 10k0 OP140A 47uF...

  • Page 44: Os(R/T)-3(A/H) Digital Board Component Layout (Top)

    4.5.2 OS(R/T)-3(A/H) Digital Board Component Layout (Top) BC817 27k4 27k4 27k4 27K4 27k4 27k4 27k4 27k4 27k4 27k4 27k4 27k4 BC817 27k4 27k4 27k4 27k4 27k4 BC817 27k4 27k4 27k4 27k4 10k0 100nF R 33 332R BC817 BC817 100nF R 17 27k4 R 32 BAS16...

  • Page 45: Os(R/T)-3(A/H) Digital Board Schematic Diagram

    4. 5. 3 OS(R/T)-3(A/H) Digital Board Schematic Diagram +5VD +5VD +5VD PRIORITY COR TO ALL +5 VDC SUPPLY POINTS P1-12B +5VD 10.0uH P1-2 SI9933DY 27K4 68HC811E2 CHAN SEL3 (I/P) P1-20 27K4 27K4 LP2951 DGND 27K4 +5VD BC817 27K4 CHAN SEL1 (I/P) 100nF 47uF MODB...
  • Page 46 This Page Intentionally Left Blank DANIELS ELECTRONICS 4-20 Enhanced AM/FM Synthesizer Instruction Manual OS(R/T)-3(A/H) 29 - 470 MHz...

  • Page 47: Parts Lists

    1008-4A103K5R CAP., SM 4.7uF TANT., 10%, 16V 1055-5B475K16 CAP., SM 10nF CER, 0805, X7R, 50V 1008-4A103K5R CAP., SM, 150pF CER., 0805,C0G 1008-2A151J1G OST-3H035 CAP., SM, 100pF CER., 0805,C0G 1008-2A101J1G OST-3H045 CAP., SM, 56pF CER., 0805, C0G 1008-1A560J1G OSR-3H061 CAP., 1-14pF TRIM., STAND. >6 1082-A1R0014J CAP., SM 1.0nF CER., 0805, X7R, 50V...
  • Page 48 1054-6G226M20 CAP., SM 10nF CER, 0805, X7R, 50V 1008-4A103K5R CAP., SM 330pF CER., 0805, COG 1008-2A331J1G CAP., SM, 56pF CER., 0805, C0G 1008-1A560J1G OST-3H035 CAP., SM, 56pF CER., 0805, C0G 1008-1A560J1G OST-3H045 CAP., SM, Not Installed Not Installed OSR-3H061 CAP., 22uF DIP. TANT., 20%, 20V 1054-6G226M20 CAP., SM 10nF CER, 0805, X7R, 50V...
  • Page 49 Ref. Desig Description Part No. Q1, Q2 TRANSISTORBC817 NPN, SOT23 2120-BC817025 TRANSISTORBC807 PNP, SOT23 2120-BC807025 TRANSISTORBC817 NPN, SOT23 2120-BC817025 JFET, J211 RF N-CHAN. TO-92 2041-J2110000 POT., SM 5K0 1T, TOP ADJ 1174-AS2502J1 RES., SM 49R9 0805, 1%,100ppm 1150-1A49R9FP RES.330R METAL FILM, 5%, 0.5W 1101-2A0331JP R3, R4 RES., SM 10K0 0805, 1%,100ppm...
  • Page 50 Ref. Desig Description Part No. U1 - U4 DIODE, OPL550 I/R SENSOR,TTL O/P,PLST 2014-1L18230T LED, OP140A I/R,GaAs,.81 x .23,PLAST. 2013-1G18230A I.C., LT1129-IS8, PROG. VOLT REG, SO8 2305-11290N08 U7 U8 I.C., LP2951 PROG. VOLT REG, SO-8 2305-29510N08 MOSFET, SI9945DY, N CHAN.,SO-8 2142-SI9945DY I.C., MC145191, PLL FREQ/SYNTH, SO-20 2355-45191N20...

  • Page 51: Os(R/T)-3(A/H) 118 - 159.4 Mhz Analog Board Electrical Parts List

    5.2 OS(R/T)-3A 118 – 159.4 MHz Analog Board Electrical Parts List Ref. Desig Description Part No. C1- C3 CAP., SM ,1.0nF CER., 0805, X7R, 50V 1008-3A102K5R CAP., SM, 10nF CER, 0805, X7R, 50V 1008-4A103K5R CAP., SM, 100nF CER., 0805, X7R, 50V 1008-5A104K5R CAP., SM, 47uF TANT., 20%, 16V 1055-6D476M16...
  • Page 52 Ref. Desig Description Part No. C50, C51 CAP., SM, 100nF CER., 0805, X7R, 50V 1008-5A104K5R CAP., SM, 10nF CER, 0805, X7R, 50V 1008-4A103K5R CAP., SM, 27pF CER., 0805, COG 1008-1A270J1G CAP., SM, 47pF CER., 0805, COG 1008-1A470J1G CAP., SM, 27pF CER., 0805, COG 1008-1A270J1G CAP., SM, 2.2uF TANT., 20%, 20V 1055-5B225K20...
  • Page 53 Ref. Desig Description Part No. R23 - R25 RES., SM, 10R0 0805, 1%,100ppm 1150-1A10R0FP RES., 1R2 METAL FILM, 5%, 0.5W 1101-0A01R2JI RES., SM, 11K8 0805, 1%,100ppm 1150-4A1182FP RES., SM, 10R0 0805, 1%,100ppm 1150-1A10R0FP RES., SM, 18K2 0805, 1%,100ppm 1150-4A1822FP RES., SM, 10R0 0805, 1%,100ppm 1150-1A10R0FP RES., SM, 100R 0805, 1%,100ppm 1150-2A1000FP...

  • Page 54: Os(R/T)-3H 128 - 174 Mhz Analog Board Electrical Parts List

    5.3 OS(R/T)-3H 128 - 174 MHz Analog Board Electrical Parts List Ref. Desig Description Part No. C1-C3 CAP., SM, 1.0nF CER., 0805, X7R, 50V 1008-3A102K5R CAP., SM, 10nF CER, 0805, X7R, 50V 1008-4A103K5R CAP., SM, 100nF CER., 0805, X7R, 50V 1008-5A104K5R CAP., SM, 47µF TANT., 20%, 16V 1055-6D476M16...
  • Page 55 Ref. Desig Description Part No. CAP., 22µF DIP. TANT., 20%, 20V 1054-6G226M20 CAP., SM, 10nF CER, 0805, X7R, 50V 1008-4A103K5R CAP., SM, 330pF CER., 0805, COG 1008-2A331J1G CAP., SM, 27pF CER., 0805, COG 1008-1A270J1G CAP., 22µF DIP. TANT., 20%, 20V 1054-6G226M20 CAP., SM, 10nF CER, 0805, X7R, 50V 1008-4A103K5R...
  • Page 56 Ref. Desig Description Part No. RES., NOT INSTALLED NOT INSTALLED RES., SM, 18K2 0805, 1%,100ppm 1150-4A1822FP RES., SM, 10R0 0805, 1%,100ppm 1150-1A10R0FP RES., SM, 49R9 0805, 1%,100ppm 1150-1A49R9FP RES., 12K METAL FILM, 5%, 0.5W 1101-4A0123JP (OS-3H141) RES., 15K METAL FILM, 5%, 0.5W 1101-4A0153JP (OS-3H162) RES., 680R METAL FILM, 5%, 0.5W...

  • Page 57: Os(R/T)-3H 406 - 470 Mhz Analog Board Electrical Parts List

    5.4 OS(R/T)-3H 406 - 470 MHz Analog Board Electrical Parts List Ref. Desig Description Part No. C1 - C3 CAP., SM 1.0nF CER., 0805, X7R, 50V 1008-3A102K5R CAP., SM 10nF CER, 0805, X7R, 50V 1008-4A103K5R CAP., SM 100nF CER., 0805, X7R, 50V 1008-5A104K5R CAP., SM 47uF TANT., 20%, 16V 1055-6D476M16...
  • Page 58 Ref. Desig Description Part No. CAP., 100nF FILM, MMK5, 10%, 63V 1016-5A104K63 OST-3H440 CAP., NOT INSTALLED NOT INSTALLED OSR-3H440 DIODE, BYD17J RECTIFIER,SOD87 2101-BYD17J00 DIODE, BAS16 SWITCHING, SOT23 2100-BAS16000 L1 - L3 CHOKE, RF/MOULD.10uH 10%,.25 1251-4A00100K L6 - L10 CHOKE, RF/MOULD.1.5uH 10%,.25 1251-3A001R5K L11 L12 INDUCTOR, SM18nH CER,10%,1008...
  • Page 59 Ref. Desig Description Part No. RES., SM 47R5 0805, 1%,100ppm 1150-1A47R5FP RES., SM 27R4 0805, 1%,100ppm 1150-1A27R4FP RES., SM 33R2 0805, 1%,100ppm 1150-1A33R2FP RES.180R METAL FILM, 5%, 0.5W 1101-2A0181JP RES.220R METAL FILM, 5%, 0.5W 1101-2A0221JP RES., SM 49R9 0805, 1%,100ppm 1150-1A49R9FP RES., SM 10K0 0805, 1%,100ppm 1150-4A1002FP...

  • Page 60: Os(R/T)-3(A/H) Digital Board Electrical Parts List

    5.5 OS(R/T)-3(A/H) Digital Board Electrical Parts List Ref. Desig Description Part No. C1,C2 CAP., SM, 100nF CER., 0805, X7R, 50V 1008-5A104K5R C3-C5 CAP., SM, 47µF TANT., 20%, 16V 1055-6D476M16 C6,C7 CAP., SM, 22pF CER., 0805, COG 1008-1A220J1G CAP., SM, 4.7µF TANT., 10%, 16V 1055-5B475K16 C9-C14 CAP., SM, 100nF CER., 0805, X7R, 50V...

  • Page 61: Os(R/T)-3(A/H) Synthesizer Mechanical Parts List

    5.6 OS(R/T)-3(A/H) Synthesizer Mechanical Parts List Description Part No. Qty. CASE, OS-3H SYNTH. MODULE,ALUM 3702-66100920 CONN., SMB, JACK,2 HOLE FLANGE 5120-J2SC01BG FERRITE, BEAD,73 MIX, 3X3.5mm OD (CON3-CON5) 1210-73030350 3 OS-3H050 FERRITE, BEAD,43 MIX, 3X3.5mm OD (CON3-CON5) 1210-43030350 3 OS-3A130 FERRITE, BEAD,43 MIX, 3X3.5mm OD (CON3-CON5) 1210-43030350 3 OS-3H150 FERRITE, BEAD,61 MIX, 3X3.5mm OD (CON3-CON5)
  • Page 62 This Page Intentionally Left Blank DANIELS ELECTRONICS 5-16 Enhanced AM/FM Synthesizer Instruction Manual OS(R/T)-3(A/H) 29 - 470 MHz...

  • Page 63: Revision History

    REVISION HISTORY ISSUE DATE REVISION May 97 • Issue 1 Mar 98 • Changes to the AM Analog board (OST-3A128) to improve performance ECO #547. C37 was 220nF is now 100nF and C40 was 8.2pF is now not installed C45 was 33nF is now 22nF and C49 was 2.2nF is now 1.5nF R32 was 33kΩ...
  • Page 64 ISSUE DATE REVISION DANIELS ELECTRONICS Enhanced AM/FM Synthesizer Instruction Manual OS(R/T)-3(A/H) 29 - 470 MHz...
