Reviewed By: Quality Assurance: Claudia Boorman _________________ Name Signature Date NOTE: The user's authority to operate this equipment could be revoked through any changes or modifications not expressly approved by Daniels Electronics Ltd. The design of this equipment is subject to change due to continuous development. This equipment may incorporate minor changes in detail from the information contained in this manual.
GENERAL 1.1 Introduction The Frequency Select Handle provides the ability to select and display the operating frequency of the receiver or transmitter on the Front Panel. Power is provided from a regulated +9.5 Vdc supply and draws typically less than 4.0 mA in sleep mode. 1.2 Printed Circuit Board Numbering Convention To ease troubleshooting and maintenance procedures, Daniels Electronics Limited has adopted a printed circuit board (PCB) numbering convention in which the last two digits of the circuit board...
Page 6
This Page Intentionally Left Blank DANIELS ELECTRONICS Frequency Select Handle Instruction Manual...
THEORY OF OPERATION 2.1 General The user interface consists of an 8 digit display and 3 pushbuttons, frequency increase Ø, frequency decrease Œ, and options . On power up or key press, the synthesizer is interrogated ¸ ¸ ¸ ¸ for the current channel number and channel frequency.
Page 8
c) Both the Ø or Œ have two modes of operation. i. Single press is for small changes. Single button presses corresponds to single channel ( 25 kHz) steps. ii. Accelerated is for large steps. After 6 seconds of the button being pressed the frequency will change by8 channels per step (200 kHz).
ALIGNMENT General Under normal circumstances no alignment is required to the Frequency Select Handle. Repair Note The Frequency Select Handle employs a high percentage of surface mount components, which should not be removed or replaced using an ordinary soldering iron. Removal and replacement of surface mount components should be performed only with specifically designed surface mount rework and repair stations complete with Electro Static Dissipative (ESD) protection.
Page 10
This Page Intentionally Left Blank DANIELS ELECTRONICS Frequency Select Handle Instruction Manual...
ILLUSTRATIONS AND SCHEMATIC DIAGRAMS 4.1 VR-3A130 Receiver Front Panel RECE VER MADE IN CANADA RECEIVER MADE IN CANADA VR-3A130-SYD210 MODEL IDENTIFIER SQUELCH DISABLE SQ . DI SABLE ON / OFF SWITCH RF N I REFERENCE TYPE N RF SMA REFERENCE INPUT JACK INPUT JACK INPUT...
