Controls
OSD(On-screen Display) control buttons on the
front of the monitor function as follows:
SELECT Enters and exits the OSD menu.
CONTROL-/+ Selects one of the controls and decreases or increases
the adjustment.
RESET Resets the highlighted control to the factory setting.
Press -/+ button at the same time for approximately 1 sec.
Brightness: Adjusts the overall image and background
screen brightness.
Contrast: Adjusts the image brightness in relation to the
background.(Contrast control is also effective with "-,+"
button even though OSD window is not visible.)
R
Red Color Control: Adjust the red contrast of the display.
G
Green Color Control: Adjust the green contrast of the
display.
B
Blue Color Control: Adjust the blue contrast of the display.
Horizontal: Moves the image horizontally left or right.
Vertical position: Moves the image vertically up or down.
Horizontal size: Decreases or increases the horizontal size
of the image.
Vertical size: Decreases or increases the vertical size of the
image.
The Geometry controls allow you to adjust the curvature or angle of the
sides of your display.
E-4
Pincushion/Barrel: Decreases or increases the curvature
of the sides either inward or outward.
Trapezoid: Decreases or increases the bottom of the screen
to be the same as the top.
Parallelogram: Decreases or increases the tilt of the sides
either to the left or right.
Bow (Pincushion Balance): Decreases or increases the
curvature of the sides either to the left or right.
Rotates: Rotates the image.
Degauss: Select the degauss icon on "Icon select window"
and push "SELECT" button.
It will eliminate the stray magnetic field and correct the scan
of the electron beam, which affect the purity, focus and
convergence.
Note: Allow a minimum interval of 20 minutes to elapse
between uses of the degauss function.
9300 Color Temperature: Select the Color Temperature icon on
"Icon Select Window" and push "SELECT" button.
It can be switched to change the color Temperature.
(9300K, 7500K, 6500K, user)
OSD: There are 3 background colours (Blue, Black, and
white). These can be selected by "SELECT" button after the
selection of "OSD" on ìIcon select windowî.
Moiré Canceler: Reduces moiré levels.
EXIT: To exit OSD window. Select EXIT on "Icon select
window", then push "SELECT" button.
Note: If you do not push buttons within 10 seconds in OSD
condition, the window will automatically disappear.
E-5
