2. Hardware Specification

Input
Max. sample rate
Channels
Bandwidth
Vertical resolution
Gain range
Range
Offset level
Coupling
Offset increments
Impedance
DC accuracy
Input protection
Timebase
Timebase range
Acquisition mode
Range
Pre/Post trigger
Time resolution
Buffer size
Chapter 1. Introduction
Realtime sampling: 100MS/s using one channel, 50MS/s using two
channels
Equivalent sampling: 5GS/s
2
200 MHz (-3dB)
Single shot bandwidth:20MHz
9 bits/channel
10mV ~ 10V/div @ x1 probe
(10mV, 20mV, 50mV, 100mV, 200mV, 500mV, 1V, 2V, 5V, 10V/div
1,2,5 sequence)
100mV ~ 100V/div @ x10 probe
1V ~ 1000V/div @ x100 probe
8 divisions
+/-4 divisions
AC, DC
0.02 div
1M ohm
+/-3%
42Vpk (DC + peak AC < 10 kHz, without external attenuation)
2ns/div ~ 10s/div
( 2ns, 4ns, 10ns, 20ns, 40ns, 100ns, 200ns, 400ns, 1us,
2us, 4us, 10us, 20us, 40us, 100us, 200us, 400us, 1ms,
2ms, 4ms, 10ms, 20ms, 40ms, 100ms, 200ms, 400ms, 1s,
2s, 4s, 10s /div 1-2-4 sequence)
Equivalent sampling: 2ns/div ~ 4us/div
Realtime sampling: 10us/div ~ 400ms/div
Roll mode: 1s/div ~ 10s/div
10 divisions
0% ~ 1000%
200ps
10K samples
3
