Item no. EMW2600TS
A. Functions
1
An ideal device to control you appliance on/off automatically or timer setting by one push button.
2
The transmitter and receiver use a fixed code system, no pairing required.
3
Remote control transmitter is with a blue backlight LCD for showing current time and function mode.
4
Each function button has a LED indicator showing the program status whenever the LCD light is on
B. Diagram
Button
Function
1. press
myon/my off time setting
2.
press and hold to adjust continuously
1. under normal mode, press and hold for 4 seconds to set the current time
2. under function mode, works as the confirm button
1.
Press to select MY ON time, time display blinks
my on time
2. Press / button to set MY ON time
3.
Press one more time tocancelprogram setting
1.
Press to select MY OFF time, time display blinks
my off time
2. Press / button to set the MY OFF time
3.
Press one more time to cancel program setting
Press to select Sunset on function, press again to cancel
Sunset on
Press to select Sunrise off function, press again to cancel
Sunrise off
1. Press to select Countdown function, time display flashes
My
2. Press / button to set the countdown time (default time is 1hour) Press again to cancel
countdown
program setting
1. Press to select extra program function
My extra
programs
Press to turn on the background light, press again to turn off
bl
Reset button, press to clear all clock and programs settings
r
C. Connection
1
For safety use, please switch off your appliance before plugging in the device
2
Set your timer program
3
Connect your appliance to the device and plug the device to an outlet
D. Instruction Procedures
Instruction Manual
New TouchSmartSunsmart 7 day timer
/
to adjust time by minute, for real time, countdown and
