3rd Eye AWTC60WP User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WARNING
Failure to follow all instructions and safety precautions in this
manual, in the vehicle and body manufacturers' manuals and
on the safety decals attached to the vehicle, body and this
product could result in serious injury or death to operators,
service technicians or bystanders and/or damage to property.
AWTC60WP HD
DO NOT operate the vehicle or install this product before you
READ and UNDERSTAND the vehicle Operation Manual, this
Camera
manual and other applicable manufacturers' manuals, and all
safety decals. This product must be installed by certified
technicians/installers familiar with the vehicles on which they
will be making the installation.
USER MANUAL
ISSUED OCTOBER 2018
© 2018 3rd Eye
3E-AWTC60WP-UM-1018

Advertisement

Table of Contents
loading

Related Manuals for 3rd Eye AWTC60WP

Summary of Contents for 3rd Eye AWTC60WP

  • Page 1 This product must be installed by certified technicians/installers familiar with the vehicles on which they will be making the installation. USER MANUAL ISSUED OCTOBER 2018 © 2018 3rd Eye 3E-AWTC60WP-UM-1018...

  • Page 2: Table Of Contents

    How to Connect the Cable ....................................7 Features and Specification Features and Specification Features and Specification ....................................8 Installation Installation Installation ....................................10 Dimensions Dimensions Dimensions ....................................13 ..................................14 Index Issued October 2018 Copyright 2018, 3rd Eye Table of Contents Printed in U.S.A.
  • Page 3 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference and, 2. This device must accept any interference received, including interference that may cause undesired operation Issued October 2018 Copyright 2018, 3rd Eye Printed in U.S.A.
  • Page 4 Thank you for purchasing our product. Please read this User Manual before using the product. All product documentation is subject to change without notice. Please go to www.3rdeyecam.com to get the most current documentation for your 3rd Eye products. Issued October 2018 Copyright 2018, 3rd Eye Printed in U.S.A.

  • Page 5: Awtc60Wp

    USER MANUAL AWTC60WP AWTC60WP HD CAMERA COLOR CAMERA USER MANUAL ISSUED OCTOBER 2018 3E-AWTC60WP-UM-1018 Issued October 2018 Copyright 2018, 3rd Eye Printed in U.S.A.

  • Page 6: Precautions

    4. The allowance temperature range for operation of this camera is between -20 to 65° (-4 to 146°F) and the allowable humidity is 85% maximum. If the camera is to be placed in an extremely dusty location, a special housing may be necessary to protect the camera and lens. Issued October 2018 Copyright 2018, 3rd Eye Precautions Printed in U.S.A.

  • Page 7: Camera Cable Pin Function

    USER MANUAL AWTC60WP CAMERA CABLE PIN FUNCTION Video GND (OPTION) Power Shield GND Issued October 2018 Copyright 2018, 3rd Eye Camera Cable Pin Function Printed in U.S.A.

  • Page 8: Din Pin Waterproof Assurance

    DIN PIN WATERPROOF ASSURANCE NOTE: Wrap the whole cable connection from one end to another end with the Weather-Sealer Strip (NOT SUPPLIED) to ensure adequate insulation against water. Issued October 2018 Copyright 2018, 3rd Eye DIN Pin Waterproof Assurance Printed in U.S.A.

  • Page 9: How To Connect The Cable

    Rotate the ring on the male connector by hand as shown in image below. STEP 3: Then screw in securely to the threads on the female connector. Issued October 2018 Copyright 2018, 3rd Eye How to Connect the Cable Printed in U.S.A.

  • Page 10: Features And Specification

    G-Force Rating : 30 · Isolated ground · Automatic heater · Double window glasses & replaceable outer glass B. Optical · Lens : F=2.9 H:96° V:72° Diagonal 120° Issued October 2018 Copyright 2018, 3rd Eye Features and Specification Printed in U.S.A.
  • Page 11 Operating Voltage Range : 9V-15V D. General · Operating Temperature : -40°C - 65°C (with Heat) E. Accessories · Supplied Accessories : Mounting Bracket & Screw Kits, Sun Shield Issued October 2018 Copyright 2018, 3rd Eye Features and Specification Printed in U.S.A.

  • Page 12: Installation

    Screw the camera bracket on with the 6 x 20 mm self-tapping screws. STEP 4: When attaching with threaded screws, drill 6.5 mm holes at the points you have just marked. Issued October 2018 Copyright 2018, 3rd Eye Installation Printed in U.S.A.
  • Page 13 STEP 7: Mount the camera by pushing the camera into the camera bracket. STEP 8: Attach the camera loosely with the 4 screws M3 x 10 mm in the slots. Issued October 2018 Copyright 2018, 3rd Eye Installation Printed in U.S.A.
  • Page 14 Tighten the 4 screws in the slots of the camera bracket. NOTE: This camera is set to mirror for default. If need to change, please adjust it from your monitor. Issued October 2018 Copyright 2018, 3rd Eye Installation Printed in U.S.A.

  • Page 15: Dimensions

    USER MANUAL AWTC60WP DIMENSIONS Issued October 2018 Copyright 2018, 3rd Eye Dimensions Printed in U.S.A.

  • Page 16: Index

    INDEX camera cable pin function dimensions DIN pin waterproof assurance features and specifications how to connect the cable installation precautions Issued October 2018 Copyright 2018, 3rd Eye Index Printed in U.S.A.
  • Page 17 WARRANTY DISCLAIMER 4.1 This warranty shall become null, void, and not apply if Client fails to notify 3rd Eye in writing of such defects prior to the expiration of the Warranty Period, if the defect is not reproducible, or if the defect is caused by (a) customer damage, negligence, misuse, tampering, accident, fire, variation or interruption of electricity;...
  • Page 18 Customer Care: 866-804-2984 3rd Eye 22130 Merchants W ay STE 100 Katy, TX 77449...
