MultiScreen Encoder
Dibsys Technologies Co.,Ltd
Multi-channel MPEG2 To H.264 Transcoder
Caster-T322(25ch)
Instruction Manual
Version: 5.0
2015-12-25
RESTRICTIONS ON USE, DUPLICATION OR DISCLOSURE
OF PROPRIETARY INFORMATION
This document contains information proprietary to Hangzhou Dibsys Technologies Co., Ltd., to its affiliates or to a third party
to which Hangzhou Dibsys Technologies Co., Ltd. may have a legal obligation to protect such information from unauthorized
disclosure, use or duplication. Any disclosure, use or duplication of this document or any of the information herein for other
than the specific purpose for which it was disclosed by Hangzhou Dibsys Technologies Co., Ltd., is expressly prohibited,
except as Hangzhou Dibsys Technologies Co., Ltd., may otherwise agree in writing. Recipient by accepting this document
agrees to the above stated conditional use of this document and this information disclosed herein.
Copyright © 2009, Hangzhou Dibsys Technologies Co., Ltd.
Add:13F,102# Xueyuan Road, West Lake District, Hangzhou City, China
Tel: 086-571-89714581, Fax: 086-571-89714580
Website:
www.dibvision.com
Email: support@dibvision.com
-
1
Advertisement
Table of Contents
Related Manuals for Hangzhou Dibsys Technologies Co., Ltd. Caster-T322
Summary of Contents for Hangzhou Dibsys Technologies Co., Ltd. Caster-T322
- Page 1 MultiScreen Encoder Dibsys Technologies Co.,Ltd Multi-channel MPEG2 To H.264 Transcoder Caster-T322(25ch) Instruction Manual Version: 5.0 2015-12-25 RESTRICTIONS ON USE, DUPLICATION OR DISCLOSURE OF PROPRIETARY INFORMATION This document contains information proprietary to Hangzhou Dibsys Technologies Co., Ltd., to its affiliates or to a third party to which Hangzhou Dibsys Technologies Co., Ltd.
-
Page 2: Table Of Contents
MultiScreen Encoder Dibsys Technologies Co.,Ltd Table of Contents Safety............................. 4 Introduction..........................4 Safety Precautions........................4 Caution and Warning Statements..................4 Safety Protection........................5 1.4.1 Technical Specifications....................... 5 1.4.2 Equipment Ratings....................... 5 Electrostatic Sensitive Devices....................6 Symbols............................6 Introduction and Applications....................7 Application..........................7 Market Application Prospect....................8 Device Data..........................8 Safety Cautions......................... - Page 3 MultiScreen Encoder Dibsys Technologies Co.,Ltd 5.8.2 Video Setting........................25 5.8.3 Audio Setting........................26 5.8.4 Advance Setting........................26 5.8.5 OUTPUT Setting......................... 27 E. HLS Setting.............................31 Common Faults Analysis..................... 32 Using ping command to check if the network links up is regular........32 Using VLC play software to check if it can play normally..........32 Protection to Fix Card........................
-
Page 4: Safety
MultiScreen Encoder Dibsys Technologies Co.,Ltd Safety Read this section carefully before installation and use of the instrument. Introduction The instrument described in this manual has been designed for use by properly trained personnel only. Adjustment, maintenance and repair of the exposed equipment should only be carried out by qualified personnel who are aware of hazards involved. -
Page 5: Safety Protection
MultiScreen Encoder Dibsys Technologies Co.,Ltd Safety Protection 1.4.1 Technical Specifications This manual provides technical information important for safe operation of the equipment Please refer to the Section Technical Specifications for information regarding technical specifications and the Sections Installation and Operating Instructions regarding instructions for use. Technical assistance may be obtained from your local DIBSYS customer support organization or Hangzhou Dibsys Technologies Co., Ltd 13F,102# Xueyuan Road, West Lake District, Hangzhou City, China... -
Page 6: Electrostatic Sensitive Devices
MultiScreen Encoder Dibsys Technologies Co.,Ltd Specifications. The terminals are protected from becoming hazardous live by means of basic insulation and protective screening. Whenever it is likely that safe operation is impaired, the instrument must be made inoperative and secured against unintended operation. The appropriate servicing authority must be informed. For example, safety is likely to be impaired if the instrument fails to perform the intended measurements or shows visible damage WARNING: Protection provided by the equipment may be impaired, if the... -
Page 7: Introduction And Applications
On (supply - mains switch). Introduction and Applications Caster-T322 provides a most powerful transcoding solution for producing live video streams, supports multi-screen, multi-rate, multi-resolution, and multi-encoding modes, helps operators optimize high quality video content, and then transmits to Internet TV, mobile TV and PC users. It can support IP input, and provide up to 25 SD or 10 720P or 6 1080P channels transcoding in one unit. -
Page 8: Market Application Prospect
MultiScreen Encoder Dibsys Technologies Co.,Ltd Market Application Prospect It supports multi-screen with different resolutions, different encoding modes and different bit rates output. Therefore, one video source can have various applications. With suitable price and high performance in IPTV and broadcast TV, it helps operators and system integrator develop the market. This equipment is more suitable for IPTV, because it is of excellent image effects. - Page 9 MultiScreen Encoder Dibsys Technologies Co.,Ltd ASI Input Four ASI port Output IP Output type Two Gig Ethernet Ports Mpeg-2/H.264/H.263/MPEG4 SP/MPEG4 ASP; MPEG-1 Layer II, AAC, AC3, AMR, WMA , MP3 TS Over UDP/RTP/HTTP Streaming format 3GP Over RTP FLV Over HTTP/RTMP HTTP Live streaming Apple HLS (m3u8) File Output...
-
Page 10: Electrical Safety Features
MultiScreen Encoder Dibsys Technologies Co.,Ltd Video Bitrate 32kbps to 5Mbps Deinterlacing; MABFF CABAC; Noise reduction; Sharpening; Enhancement filter Visual Optimizing Audio encoding LC-AAC, HE-AAC and HE-AACv2 (including Parametric Stereo) Audio encoding MPEG-1 Layer, AC3, MP3 Sample rate 8khz to 48khz Data rate 8kbps to 384kbps Management... -
Page 11: Mains Voltage Cord And Fuses
MultiScreen Encoder Dibsys Technologies Co.,Ltd Before connecting the equipment to the mains of the building installation, the proper functioning of the protective earth lead of the building installation needs to be verified. Warning: Any interruption of the protective conductor inside or outside the instrument, or disconnection of the protective earth terminal, is likely to make the instrument dangerous. -
Page 12: Rack Mounting
Note: The operation of the fan is temperature controlled. If the Caster-T322 is mounted between other instruments with high surface temperature, this cooling may not be sufficient. Under these circumstances, it is recommended to make space between the instruments, and to establish forced circulation (cooling) in the rack. -
Page 13: Operating Instructions
MultiScreen Encoder Dibsys Technologies Co.,Ltd Operating Instructions Front Panel Front Panel NIC 1 LED NIC 2 LED Power LED Power Switch There are several items on the front panel: one power Led; two NIC status Led, and one power switch. The Interfaces from Left to Right are: USB port 1, 2 Indicator1 indicates Network Signal connect 1 (Off by default) -
Page 14: Rear Panel
MultiScreen Encoder Dibsys Technologies Co.,Ltd Rear Panel Overview Web user interface is one of the network management interfaces of this equipment. Login Screen Only enter the correct user name and password to have the access to the next step. The default login IP address is 192.168.1.167/webtrans Note: For this, we will stick the IP address on the device. -
Page 15: Overall Situation Screen
MultiScreen Encoder Dibsys Technologies Co.,Ltd Note: Username: please enter user name, such as: admin Password: please enter password, such as: 123 Login: Press this button to land on the management interface and enter into the homepage Overall Situation Screen... -
Page 16: Device Management
MultiScreen Encoder Dibsys Technologies Co.,Ltd After the successfully landing, the web browser will display an overall situation screen of Anystreaming (iptv encoding/transcoding platform), which provides the setting information of relevant parameters. The left side of the manual: 【Task Management】The current configuration list, including the name of the added equipment, as shown below: TASK, the main function is to show the new tasks and the name of the programs which the transcocder has already input, as shown below: 【Device Management】including【Host Management】... - Page 17 MultiScreen Encoder Dibsys Technologies Co.,Ltd New Host】, The host name is formed by letters, numbers, underlines. After configuring the parameters, click “Submit”, then you will see the added host, as shown below: It doesn’t need to reset the configuration, because the equipment has already been configured by our engineer before delivery.
-
Page 18: Channel Management
MultiScreen Encoder Dibsys Technologies Co.,Ltd 5.6.2 Channel Management If want to add SPTS or a certain program of MPTS stream, please choose【Channel Management】, click “ ”, input the Channel name and IP address, finally click “ ”. The stream address can be the multicast address or unicast address which is from the IP input signal source. Currently, it shows the 1 configured Tasks under Model 1. - Page 19 MultiScreen Encoder Dibsys Technologies Co.,Ltd 2. You will find the program ID (such as Program 1, Program 2..) for each channel (different IDs) 3. Open the web UI of the transcoder, you will find in the Channel Management the channels sources, “Add stream channel”.
-
Page 20: Parameter Template
MultiScreen Encoder Dibsys Technologies Co.,Ltd Note: @eth1 means the channel is come from eth1, if it comes from the same eth port, then you do not need to put. 5.6.3 Parameter Template If you want to self define the added transcoding parameters, please choose【Parameter Template】, click “... -
Page 21: Task Management
MultiScreen Encoder Dibsys Technologies Co.,Ltd Task Management AS shown in the following, 9 channels have been added into the current task management bar which are added through 【Channels Management】. Then set the parameters of every channel and output code streams. The number of added tasks will appear under the name of every channel. - Page 22 MultiScreen Encoder Dibsys Technologies Co.,Ltd Press this button to delete all the tasks of the current channel. Please be cautious about proceeding. t o add a new task for the current channel, set the parameters of the task and generate a stream.
-
Page 23: Task Management
MultiScreen Encoder Dibsys Technologies Co.,Ltd 5.8 Task Management 5.8.1 Basic Configuration Press this button to enter the page of create task, as shown below. It mainly includes video, audio, output, storage and advance window configuration. - Page 24 MultiScreen Encoder Dibsys Technologies Co.,Ltd Introduction of the basic configuration 1. Fill in the name of the task 2. Display the IP address and port number, where the video signal sources of the current task come from. 3. Choose allow input video and audio streams to transcode 4.
-
Page 25: Video Setting
MultiScreen Encoder Dibsys Technologies Co.,Ltd 5.8.2 Video Setting 【 Encode Format 】 The encoding model of output bit rate, such as h.264, h.263, mpeg4, transparent, generally choose h.264; 【Profile】baseline, main profile, high profile 【Level】The encoding level : 10-51, such as 30, 40 【Bit ate Control】Set the video stream control to keep the video streams change regularly. -
Page 26: Audio Setting
MultiScreen Encoder Dibsys Technologies Co.,Ltd 5.8.3 Audio Setting 【Audio Codec】 The audio encoding model, such as AAC、 AMR、 AC3、 MP2A、 WMA、 Transparent, default is AAC 【Bitrate】The output audio bit rate,default is 64kbps, and can be set in line with the requirement of users. You can set 32,64,128,192,256,384kbps 【Sample rate】The output audio sampling ratio,default is48000,If choose it, then the input and output audio sampling ratio remain unchanged... -
Page 27: Output Setting
MultiScreen Encoder Dibsys Technologies Co.,Ltd 【TS PIDs】set the PMT, PID of Video and Audio. the value uses decimal system, such as 100/101/102 【disp inteval】when sending the TS, for how many packets (1316)1316 need to insert 10ms Sleep, default 5.8.5 OUTPUT Setting Each module has two Ethernet port, the main Ethernet port(eth0), and assistant Ethernet port(eth1). - Page 28 MultiScreen Encoder Dibsys Technologies Co.,Ltd Unicast:output protocol please select : TS Output unicast address will be: port@ transcoder IP address(the details , please check network settings) VLC play format:udp://@unicast address:port(the PC which with unicast ip address can play this address) Noted: unicast address is the same as objective terminal IP address.
- Page 29 MultiScreen Encoder Dibsys Technologies Co.,Ltd C. RTSP output settings Output protocol, please select: RTP over HTTP Output address: 127.0.0.1:554/live/100(554 is default port,100 is identifier , you can change it by yourself) Channel name no need to fill in VLC play address:rtsp://transcoder IP:554/live/100 D.
- Page 30 MultiScreen Encoder Dibsys Technologies Co.,Ltd RTMP to streaming media server (1)output protocol, please select : RTMP Output address: server IP:1935/live/100(1935 is server port, default is 1935, live is channel name, 100 is stream name) Stream name no need to fill in (2)Output protocol, please select : RTMP Output address;...
-
Page 31: Hls Setting
MultiScreen Encoder Dibsys Technologies Co.,Ltd E. HLS Setting Output protocol, please select: HLS over HTTP Output address: 127.0.0.1:8000/100(8000 is default port,100 is identifier ,which can distinguish stream address, you can change it by yourself) Channel name no need to fill in VLC play address: http:// transcoder IP:8000/live/100.m3u8 After setting all the parameters, please press... -
Page 32: Common Faults Analysis
MultiScreen Encoder Dibsys Technologies Co.,Ltd Common Faults Analysis Using ping command to check if the network links up is regular Using VLC play software to check if it can play normally... -
Page 33: Protection To Fix Card
MultiScreen Encoder Dibsys Technologies Co.,Ltd Protection to Fix Card Thank you very much for purchasing our product. In order to provide comprehensive after-sales service for your esteemed company, please fill in the following content when purchasing the product and properly keep the card. Product Name/Model：... - Page 34 MultiScreen Encoder Dibsys Technologies Co.,Ltd Thank you very much for your using our product!
