Multi-channel MPEG2 To H.264 Transcoder
This document contains information proprietary to Hangzhou Dibsys Technologies Co., Ltd., to its affiliates or to a third party to
which Hangzhou Dibsys Technologies Co., Ltd. may have a legal obligation to protect such information from unauthorized
disclosure, use or duplication. Any disclosure, use or duplication of this document or any of the information
herein for other than the specific purpose for which it was disclosed by Hangzhou Dibsys Technologies Co.,
Ltd., is expressly prohibited, except as Hangzhou Dibsys Technologies Co., Ltd., may otherwise agree in writing. Recipient by
accepting this document agrees to the above stated conditional use of this document and this information disclosed herein.
Add:03-13F,102# Xueyuan Road, West Lake District, Hangzhou City, China, Tel: 086-571-89714581,
Fax: 086-571-89714580, Website: www.dibvision.com Email: service@dibvision.com
Caster-T328(200ch)
Instruction Manual
RESTRICTIONS ON USE, DUPLICATION OR DISCLOSURE
OF PROPRIETARY INFORMATION
Copyright © 2009, Hangzhou Dibsys Technologies Co., Ltd.
IPTV Transcoder Caster-T328
Version:2016.1
Advertisement
Table of Contents
Related Manuals for Hangzhou Dibsys Technologies Co., Ltd. Caster-T328
Summary of Contents for Hangzhou Dibsys Technologies Co., Ltd. Caster-T328
- Page 1 IPTV Transcoder Caster-T328 Multi-channel MPEG2 To H.264 Transcoder Caster-T328(200ch) Instruction Manual Version:2016.1 RESTRICTIONS ON USE, DUPLICATION OR DISCLOSURE OF PROPRIETARY INFORMATION This document contains information proprietary to Hangzhou Dibsys Technologies Co., Ltd., to its affiliates or to a third party to which Hangzhou Dibsys Technologies Co., Ltd.
-
Page 2: Table Of Contents
IPTV Transcoder Caster-T328 Table of Contents Safety............................3 Introduction........................... 3 Safety Precautions.......................3 Caution and Warning Statements..................3 Safety Protection........................4 1.4.1 Technical Specifications......................4 1.4.2 Equipment Ratings........................4 Electrostatic Sensitive Devices..................5 Symbols..........................5 Introduction and Applications...................6 Application..........................6 Market Application Prospect....................7 Technical Application......................7 Device Data.......................... -
Page 3: Safety
IPTV Transcoder Caster-T328 Safety Read this section carefully before installation and use of the instrument. Introduction The instrument described this manual been designed for use properly trained personnel only. Adjustment, maintenance and repair of the exposed equipment should only be carried out by qualified personnel who are aware of hazards involved. -
Page 4: Safety Protection
IPTV Transcoder Caster-T328 order to prevent personal injury. Safety Protection 1.4.1 Technical Specifications This manual provides technical information important for safe operation of the equipment Please refer Section Technical Specifications information regarding technical specifications and the Sections Installation and Operating Instructions regarding instructions for use. -
Page 5: Electrostatic Sensitive Devices
IPTV Transcoder Caster-T328 The terminals are protected from becoming hazardous live by means of basic insulation and protective screening. Whenever it is likely that safe operation is impaired, the instrument must be made inoperative and secured against unintended operation. The appropriate servicing authority must be informed. -
Page 6: Introduction And Applications
IPTV Transcoder Caster-T328 Black/Yellow Live part shock risk of electric shock. To preserve the instrument from damage the operator must Black/Yellow refer to an explanation in the instruction manual White/Black Protective earth (grounding) terminal Black Alternating current (placed on the identification plate) Off (supply - mains switch). -
Page 7: Market Application Prospect
IPTV Transcoder Caster-T328 IPTV and remote video transmission Mobile TV/iphone/ipad Network TV and WEB TV Market Application Prospect It supports multi-screen with different resolutions, different encoding modes and different bit rates output. Therefore, one video source can have various applications. With suitable price and high performance in IPTV and broadcast TV, it helps operators and system integrator’s develop the market. -
Page 8: Device Data
IPTV Transcoder Caster-T328 Device Data Safety Cautions This equipment is designed and tested in accordance with National Standard Electrical Safety Regulations, which complies with safety conditions. The information and warnings of this manual fully comply with safety operation and maintenance. -
Page 9: Electrical Safety Features
IPTV Transcoder Caster-T328 Resolutions 80x64 • 176x120 • 128x96 (4:3) • 176x128 • 144x80 • 176x144 • 144x140 • 220x176 • 160x90 (16:9) • 240x176 • 320x240 352x288 • 400x300 • 480x360 • 720x576 • 1024x768 854x480(16:9) • 1280x720p • 1920x1080p • 1920x1080i... -
Page 10: Mains Voltage Cord And Fuses
IPTV Transcoder Caster-T328 protective earth lead of the building installation needs to be verified. Warning: Any interruption of the protective conductor inside or outside the instrument, or disconnection of the protective earth terminal, is likely to make the instrument dangerous. Intentional interruption is prohibited. -
Page 11: Rack Mounting
IPTV Transcoder Caster-T328 Rack Mounting This DIBSYS instrument is delivered in a 19" cabinet. If several cabinets are mounted in a 19" rack, special attention must be paid to the temperature inside the rack. Note: The operation of the fan is temperature controlled. -
Page 12: Operating Instructions
IPTV Transcoder Caster-T328 Operating Instructions Front Panel Front Panel Rear Panel... -
Page 13: Overview
IPTV Transcoder Caster-T328 Overview Web user interface is one of the network management interfaces of this equipment. Generally, we recommend to use browser to operate the WEB page. IP Address: you can find the Default IP address on the device. -
Page 14: Overall Situation Screen
IPTV Transcoder Caster-T328 Overall Situation Screen After the successfully landing, the web browser will display an overall situation screen of AnyStreaming, which provides the setting information of relevant parameters The left side of the manual: 【Task Management】The current configuration list, including the name of the added equipment, as shown... - Page 15 IPTV Transcoder Caster-T328 【Device Management】 including 【Host Management】 、 【Channel Management】 、 【Parameter Template】 1、【Host Management】To manage the host of the equipment, It doesn't need to reset the configuration, because the equipment has already been configured by our engineer before delivery 2、【Channel Management】To manage and configure the...
-
Page 16: Device Management
IPTV Transcoder Caster-T328 Device Management 5.6.1 Host Management Add a host when first enters the system. Click 【Device Management】 - 【 Host Management】 - 【Add New Host 】 , The host name is formed by letters, numbers, underlines. After configuring the parameters, click... -
Page 17: Parameter Template
IPTV Transcoder Caster-T328 It doesn’t need to reset the configuration, because the equipment has already been configured by our engineer before delivery You can click ” ”Button in order to the lastest Service/Tasks In general, this parameter has been successfully set before leaving the factory, so the users do not need to set and change it again. -
Page 18: Channel Management
IPTV Transcoder Caster-T328 In general, we advice the user to get the parameters from the folder (down load) in the task management 5.6.3 Channel Management... - Page 19 IPTV Transcoder Caster-T328 If want to add SPTS or a certain program of MPTS stream, please choose【Channel Management】, click “Add Stream Channel”, input the Channel name and IP address, finally click “Submit”. The stream address can be the multicast address or unicast address which is from the IP input signal source.
-
Page 20: 5.7 Task Management
IPTV Transcoder Caster-T328 5.7 Task Management AS shown in the following, 9 channels have been added into the current task management bar which are added through 【Channels Management】. Then set the parameters of every channel and output code streams. The number of added tasks will appear under the name of every channel. - Page 21 IPTV Transcoder Caster-T328 Press this button (Stop) to stop the running task. And press (start) this button to restart it. The condition of the task will be changed from (Edit) Edit and modify the parameters of the new added tasks. This operation can be performed only when the...
-
Page 22: Create Task
IPTV Transcoder Caster-T328 Create Task 5.8.1 Basic Configuration Press this button to enter the page of create task, as shown below. It mainly includes video, audio, output, storage and advance window configuration. Introduction of the basic configuration 1. Fill in the name of the task 2. -
Page 23: Video Setting
IPTV Transcoder Caster-T328 3. Choose allow input video and audio streams to transcode Generally, these three parameters should be selected. 4. To load the pre-configured parameters. If there are no pre-configured parameters, then no need to choose this content 5.8.2 Video Setting 【... -
Page 24: Audio Setting
IPTV Transcoder Caster-T328 【Frame Rate】 The frame number of output video streams. In general, we set it to 25, but it also can be set in accordance with the requirements of users. If check this, then the input and output signal frames remain unchanged. -
Page 25: Advance Setting
IPTV Transcoder Caster-T328 5.8.4 Advance Setting 【Affinity profile】kernel distribution profile Do not need to choose if it is default. 【AV Sync】The video and audio synchronization break, Unit: Millisecond, Default is 2000 【PCR Delay】TS PCR and DTS time difference setting. Default is 700ms 【TS PIDs】set the PMT, PID of Video and Audio. - Page 26 IPTV Transcoder Caster-T328 A. TS(UDP output)settings Multicast: the output protocol please select: TS Output multicast address: port@ transcoder IP address( port is user-defined, please check the details in network setting) VLC paly format:udp://@multicast address:port Unicast:output protocol please select : TS...
- Page 27 IPTV Transcoder Caster-T328 address) Noted: unicast address is the same as objective terminal IP address. B. HTTP output settings Output protocol, please select: TS over HTTP Output address will be: 127.0.0.1:8000/100(8000 is the default port. 100 is identifier which can distinguish...
- Page 28 IPTV Transcoder Caster-T328 VLC play address: http:// transcoder IP:8000/live/100.m3u8 After setting all the parameters, please press...
-
Page 29: Common Faults Analysis
IPTV Transcoder Caster-T328 Common Faults Analysis Using ping command to check if the network links up is regular Using VLC play software to check if it can play normally... -
Page 30: Protection To Fix Card
IPTV Transcoder Caster-T328 Protection to Fix Card Thank you very much for purchasing our product. In order to provide comprehensive after-sales service for your esteemed company, please fill in the following content when purchasing the product and properly keep the card. - Page 31 IPTV Transcoder Caster-T328 Thank you very much for your using our product!
