- Page 1 USER MANUAL...
- Page 2 Welcome to the Quha Nemo self operated headband with char- ging dock for Quha Zono. Before you start using your Quha Nemo, for the best user experience, please read this manual care- fully first. Quha Nemo is a user operated headband with charging dock for the Quha Zono gyroscopic mouse.
- Page 3 Quha Nemo Main Parts 1. UNC camera thread 2. USB cable 3. Charging connector 4. Magnet attachment point Figure 2 - Charging dock...
- Page 4 Quha Nemo Main Parts 5. Headband connector 6. Mini USB connector 7. Quha Zono slot 8. Quha Sento arm (optional) 9. Magnet 10.Connector for 3.5 mm switches 11.Charging connector 12.Headband Figure 3 - Nemo cradle and headband...
-
Page 5: Installation
Connect Quha Zono and Nemo cradle 1. Connect the Quha Nemo cradle to the headband. 2. Slide the Quha Zono mouse in the cradle so that the Quha Zono mini USB charging port is connected to the cradle’s mini USB connector. - Page 6 1. Attach the charging dock to a mount of your preference (not included) with the standard 1/4” UNC camera thread. 2. Adjust the mount so that when the Quha Zono mouse has been attached to the dock, its position enables picking up Quha Zono without hands using head movements only.
- Page 7 Charging Quha Nemo charging dock has a magnet attachment that con- nects to the Quha Zono cradle. There is only one possible way to connect them together. The dock design and the magnet assist the connection. The magnet in the dock will hold the cradle firm- ly in its place when connected.
- Page 8 Sento puff switch (with version including Sento) Quha Sento is a contactless puff switch that is used to perform a short mouse click (clicking) or a long mouse click (dragging) together with the Quha Zono gyroscopic mouse. Using Quha Sento Quha Sento detects the air flow (puff) coming from the user’s...
-
Page 9: Technical Specifications
Storage temperature From +0°C to +45°C (from +32°F to +113°F) Sales Package Contents Quha Nemo cradle (optionally with Sento puff switch), head- band and charging dock USB charger with AC input plugs for EU, UK, US and SAA User manual... -
Page 10: Product Disposal
Keeping Quha Nemo Clean As a head worn device, Quha Nemo is easy to keep clean. All parts can be cleaned with a physiologically sensitive area cleaning liquids, such as water or Würth Multiclean. Product Disposal When the device has reached its end-of-life it should be recy- cled as electric and electronic waste. -
Page 11: Limited Warranty
This product is RoHS compliant. © 2018 Quha oy. Quha oy is not responsible for possible errors in this user manual. Quha oy reserves the right to revise the content of this... - Page 12 Designed and manufactured in Finland by Quha. www.quha.com Copyright 2018 Quha oy. Quha, the Q-mark, Quha Zono and Quha Nemo are trademarks or registered trademarks of Quha oy.
