.4. HEAD VIBRATION

Connect to head massage,control by remote:
Click head massage + button,head massage strengthens by one level;
Click head massage button,head massage weakenby one level;
This function takes effect only by pressing the corresponding button on the remote.

.5. MULTIFUNCTION port

Connect with the same other Control box or Other accessories;
.6. Power LED& PAIRING LED
Power supply for control box, PAIRINGLED of control box flashes for 4 times,and then turns off, POWER LED turns
on

.7. Power

Connect to the 29V DC;

.8. RESET button

Press and hold the RESET button the Head, Foot and Lumber actuators will moves to lower position.

.9. Pair Function

Double click RESET button pairing LED turns on the control box enters into mode of code paring
Press and hold the paring LED of Remote, the backlight of paring LED flashes, the backlight of remote flashes, the
remote enters into mode of code paring;
The backlight of paring LED of remote stops flashing, and the paring led of control box turns off, it indicates that
the code paring is successful;
If fails, repeat all the processes above;
