Setting the operating mode of the Fronius Power
Control Box
The operating
mode adjus-
ting dial
Operating
Setting
modes and
settings
(2)
(3) (4)
(1) 12VDC Class
Mode
-
2 Input only
1 2 3 4 5 6 7 8 9 10 11 12
Mode
Description
Test mode
10 % of the maximum possible output power is fed into
the grid (irrespective of what is connected to the termi-
nals).
0
4-relay mode (factory setting)
Depending on the limit set by the ripple control signal
receiver, 100 %, 60 %, 30 % or 0 % of the maximum
possible output power is fed into the grid.
1
2-relay mode
Depending on the combination in which the two relays
are actuated on the ripple control signal receiver, 100
%, 60 %, 30 % or 0 % of the maximum possible output
2
power is fed into the grid.
3-relay mode
Depending on the limit set by the ripple control signal
receiver, 60 %, 30 % or 0 % of the maximum possible
output power is fed into the grid.
3
Reserved for other operating modes
Settings 4 - 9 are currently assigned to 4-relay mode.
-
4
9

The operating mode adjusting dial

is used to control the inverter func-
tion.
IN OUT
(1)
1 2 3
12
