PRYME Radio Product PRYMEBLU BT-500 Series User Manual

Charging the PRYMEBLU Adapter
STEP ONE: Charging the PRYMEBLU Adapter
The PRYMEBLU Adapter has an internal Lithium Ion rechargeable battery pack which must be charged prior to operation, and must be
recharged regularly. A fully charged battery will provide approximately 10 hours (or more) of operation before needing to be recharged,
however, operating time can vary depending on usage and the condition of the battery pack. Recharge the battery regularly.
To charge the PRYMEBLU Adapter:
1. Ensure the PRYMEBLU Adapter is turned o , using the switch located on the back of the device.
2. Plug the supplied wall charger into a standard 120 volt AC outlet.
3. Plug the charger into the charge jack on the bottom of the PRYMEBLU Adapter. You will need to remove the protective rubber cover that
is inserted into the charge jack. (To prevent dust and moisture from damaging your adapter, always ensure this cover is in place when you
are not charging the adapter.)
4. Once the charging process has begun, the LED indicator on the top of the PRYMEBLU Adapter will show a constant blue light. Typical
charge time is approximately 5-6 hours. Actual charge time will vary depending on several factors including the battery's charge state,
condition, and age.
6. Disconnect the charger from the adapter when charging is completed.
Charging Cautions:
- Use only the wall charger supplied by the manufacturer. Do not use any other charger.
- Do not use a wall charger that appears to be damaged. (Example: frayed wires, melted plastic, etc.)
Contact PRYME to get a new manufacturer-approved replacement charger.
- Do not tamper with or modify the PRYMEBLU Adapter or charger.
-Always turn the power switch to the o position when charging the PRYMEBLU Adapter.
3
Controls and Connection
Radio Connector
Plugs into the two-way
radio's Mic/Speaker jack.
Multifunction Talk Switch
Used to place the PRYMEBLU
Adapter in pairing mode.
Once paired with an audio
accessory, this switch is used
to activate the Push-To-Talk
function of the two-way radio
There is a clothing clip on
the back of the long cord
versions. (BT-501LC, BT-503LC)

QUICK START

1. Connect the PRYMEBLU adapter to a compatible two-way radio.
2. Pair the PRYMEBLU adapter with a compatible wireless audio accessory.
3. Test and use.
Connecting the Adapter to Radio
STEP TWO: Connecting to a Two-Way Radio
To connect your PRYMEBLU Adapter to a two-way radio, follow these steps:
* Always turn o your two-way radio before connecting the PRYMEBLU Adapter.
* Plug the PRYMEBLU adapter's radio connector into the speaker-microphone / audio accessory jack of your two-way radio.
* You can attach the PRYMEBLU Adapter to your two-way radio or clothing using the Velcro fastener.
USING THE FRICTION PAD
The PRYMEBLU Adapter is supplied with a rubber Friction Pad. This pad provides additional protection and stability when using the Velcro
Fastener to attach the adapter to a radio or other location.
To install the rubber Friction Pad do the following:
1. Open the Velcro Fastener on the back of the PRYMEBLU Adapter so that the two straps are separated.
2. Align the Friction Pad so that it is centered over the Velcro Fastener on the back of the adapter.
3. Slide one strap of the Velcro Fastener into one of the slots in the Friction Pad and pull the strap through.
4. Slide the other Velcro Fastener strap through the other slot in the Friction Pad.
5. Place the PRYMEBLU Adapter in the position you wish to mount it and close the Velcro Fastener.
Status LED
The LED ashes messages that
let the user know the current
status of the PRYMEBLU Adapter
Belt Clip Version
Velcro Fastener
or Belt Clip
Used to attach
the PRYMEBLU
adapter to the
two-way radio
or to the user's
belt or lapel
2
ON
4
Velcro Fastener
Version
