- Page 1 2 PCE HYDRAULIC VEHICLE POSITIONING JACKS 300MM STEEL ADJUSTING WHEEL RANGE FRAME WIDTH 345MM 625MM CONSTRUCTION CAPACITY K12101 - 2 Piece Hydraulic Vehicle Positioning Jacks (PU Castors) K12104 - 2 Piece Hydraulic Vehicle Positioning Jacks (NYLON Castors) ED1 (Feb 17)
-
Page 2: Table Of Contents
5. Front Castors 6. Steel Rollers 7. Locking Pin Specifications Model No ............K12101 ..........K12104 Rated Capacity (Each) ........684kg ..........684kg Wheel Width Capacity ........300mm ..........300mm Adjusting Range ........... 345-625mm ........345-625mm Castor Material Construction ...... Polyurethane (PU) ......Nylon... - Page 3 2 PIECE VEHICLE POSITIONING JACKS General Safety Warnings Save all WARNINGS and instructions for future reference. Read and understand the entire contents of this manual before attempting to use the Vehicle Positioning Jacks. The WARNINGS, cautions and instructions discussed in this instruction manual cannot cover all possible conditions or situations that could occur.
-
Page 4: Understanding Your Product
Close the Release Valve (4) clockwise until tight (DO NOT over-tighten) (Fig 3). If the Vehicle Positioning Jacks, (4) does not feel like it is operating correctly, repeat the above process until all air has been purged from the system. If the problem continues contact Kincrome Customer Service. Fig.1 Fig.2... -
Page 5: Assembly Instructions
2 PIECE VEHICLE POSITIONING JACKS OPERATION WARNING!: Only use the vehicle positioning jack on a flat & leveled surface. Ensure your work area is clean and tidy before use of the vehicle positioning jack. Position the vehicle Positioning Jack beside the vehicles wheel (Fig 7). Remove the pedal retaining clip (3) (Fig 8). -
Page 6: Care & Maintenance
2 PIECE VEHICLE POSITIONING JACKS CARE & MAINTENANCE Caution: Prior to making any adjustments ensure the pressure is removed from the hydraulic system. Caution: These procedures are in addition to the regular checks and maintenance explained as part of the regular operation of the hydraulically operated tool. -
Page 7: Trouble Shooting
1. Close the release valve (4). 2. Dirt on valve seals. 2. Replace the oil. 3. Worn seals. 3. Call Kincrome Customer Service. Pump unit will not produce 1. The reservoir could be overfilled or low 1. Check the fluid level. Do not pressure on hydraulic fluid. -
Page 8: Spare Parts & Exploded Diagram
2 PIECE VEHICLE POSITIONING JACKS Spare Parts List & Diagram Part No. Description Qty. Part No. Description Qty. K12100-1 Ram Assembly K12100-11 Lock Pin with Chain K12100-2 Bolt M16*115 K12100-12 Screw M6*20 K12100-3 Flat Washer 16 K12100-13 Lock Washer 6 K12100-4 Nut M16 K12100-14... -
Page 9: Warranty
(12 months) commences on the date that the product is purchased. If this product has materials or workmanship defects (other than defects caused by abnormal or non warranted use) you can, at your cost, send the product to place of purchase, an authorised Kincrome service agent or one of Kincromes addresses for repair or replacement. - Page 10 www.kincrome.com.au...
