Attendant
®
BLUETOOTH
WEIGHT INDICATOR
Owner's Manual
Please keep and refer to this Owner's Manual.
Thank you for purchasing an Attendant
Bluetooth Weight Indicator. Please read this entire guide carefully and keep it
®
for future reference. This guide will provide you with instructions, warnings, warranty information, and other important
information about your Attendant Bluetooth Weight Indicator. Share this information with your housekeeping, nursing and
maintenance staff to help ensure the Bluetooth Weight Indicator is cared for properly. Share this information with those
individuals who will be assembling, using, servicing, and/or cleaning the Product to help ensure it is cared for properly.
STOP! READ THIS MANUAL THOROUGHLY BEFORE PROCEEDING.
1-800-245-9917

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Attendant and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Direct Supply Attendant

Summary of Contents for Direct Supply Attendant

  • Page 1 This guide will provide you with instructions, warnings, warranty information, and other important information about your Attendant Bluetooth Weight Indicator. Share this information with your housekeeping, nursing and maintenance staff to help ensure the Bluetooth Weight Indicator is cared for properly. Share this information with those individuals who will be assembling, using, servicing, and/or cleaning the Product to help ensure it is cared for properly.

  • Page 2: Table Of Contents

    Body Mass Index (BMI) Operation ..13 DEVICE: Your Attendant Weight Indicator. Weight Recall .........14 WE, US and OUR: Direct Supply Manufacturing, Inc. Serial ID Storage ........14 “You” means the User, Caregiver or any other individuals who will be using or servicing the Product.
  • Page 3 Warnings, FCC Compliance Statement & Proper Disposal Warnings Read and follow all directions and warnings before use or assembly. Do not use or assemble if you do not understand the contents of this manual – contact your distributor for assistance. Damage, injury or even death may result from improper use of this product or not following directions and warnings.

  • Page 4: Specifications

    Specifications Power Requirements 6 AA Alkaline, Ni-Cad or NiMH batteries (not included) OR an optional 100 to 240 VAC 50/60Hz 12 VDC 1A wall plug-in UL/CSA listed AC power adapter Operating Temperature 14 to 104ºF (-10 to +40ºC) Display 6 digit, 7 segment 0.7"...

  • Page 5: Site Preparation Requirements

    Electrical Power The Attendant Bluetooth Weight Indicator has been designed to operate from a 100 to 240 VAC 50/60Hz 12 VDC 1A wall plug-in UL/CSA listed AC power adapter. Note that a special order is not required for operation at 230 VAC.

  • Page 6: Installation

    Installation • WARNING: Unpack the product in an area with sufficient room to work. Do not allow children, animals or individuals with impaired cognitive or physical abilities near the product until it has been completely set up and the work area has been cleared of all debris Unpacking 1.

  • Page 7: Interconnections

    Load Cell Connection The load cell cable connects to the Attendant Bluetooth Weight Indicator via a 9-pin “D” connector on the rear panel of the indicator. Figure No. 4 shows the pin identification for the load cell connector. Make certain that the pins are correctly identified before soldering a wire to them.

  • Page 8: Optional Ac Power Adapter

    Battery Status The Attendant Bluetooth Weight Indicator will operate for up to 250 hours on new Alkaline batteries or for up to 100 hours on fully charged Ni-Cad or NiMH batteries depending on the condition of the batteries (from new to about 500 recharges).

  • Page 9: Battery Installation/Replacement

    Battery Installation/Replacement Battery Push in and To install or remove the batteries, the following steps Cover lift here should be followed: 1. Make sure the AC power adapter is unplugged. 2. Remove the indicator from the scale mounting bracket. (Referring to Figure No. 3, pull the spring plunger down and slide the indicator away from the bracket.) 3.

  • Page 10: Keypad Functions

    Keypad Functions • CAUTION! DO NOT operate the keypad with pointed objects (pencils, pens, etc.). Damage to keypad resulting from this practice is NOT covered under warranty. ENTER PRINT Figure No. 10 With the indicator off, pressing this key will apply power to the indicator and turn on the display.

  • Page 11: Body Mass Index Functions

    This key is used to change the weighing units to the alternate units of measurement. For example, with pounds displayed, pressing this key will change the weighing units to kilograms. NOTE! This feature must be enabled during setup and calibration for this key to be operational. This key is used to lock and unlock the display.

  • Page 12: Annunciators

    Annunciators The annunciators are turned on to indicate that the display is in the mode corresponding to the annunciator label or that the status indicated by the label is active. Figure No. 11 The low battery annunciator is located in the upper-left corner of the display. It is used to indicate the battery status.

  • Page 13: Operation

    Operation Basic Weighing Operation To Weigh 1. Press ON/OFF key to turn on indicator. 2. Press ZERO key to zero weight display. The ZERO and lb or kg annunciator will turn on to show that scale is ready for use. 3.

  • Page 14: Weight Recall

    They cannot be printed. Serial ID Storage The Attendant Bluetooth Weight Indicator has been equipped with Serial ID storage for 200 records. Each ID stores the ID Index, Weight, Height, BMI and Unit of Measure. When the ENTER/PRINT key is pressed, the indicator will assign the current values to a new ID and store the ID in memory.

  • Page 15: Setup And Calibration

    Setup & Calibration Your Attendant Bluetooth Weight Indicator has been thoroughly tested and calibrated before being shipped to you. If you received the indicator with a scale, calibration is not necessary. If the indicator is being connected to a scale for the first time or recalibration is necessary for other reasons, proceed as indicated.
  • Page 16 Setup & Calibration (cont.) i n t = (INTERVAL SETTING) Press the ENTER/PRINT key to view the current setting. If the value displayed is acceptable, press the ENTER/PRINT key again. Otherwise, press the keys to scroll through and select a new value and then press the ENTER/PRINT key to save it and proceed to the next prompt.
  • Page 17 F L T = (DIGITAL FILTER LEVEL SELECTION) Your indicator will arrive with factory filter settings of 1 = Minimal. Please check with Tech Support before changing filter level, break range and sample rate. Press the ENTER/PRINT key to view the current setting. If the value displayed is acceptable, press the ENTER/PRINT key again.
  • Page 18 Setup & Calibration (cont.) L o A d = (LOAD CALIBRATION WEIGHT) With the display showing L o A d =, perform the following steps: 1. Make certain the scale platform is empty and free of debris. 2. Place the desired amount of calibrated test weights on the scale platform. A minimum of 50% of scale’s capacity is required.
  • Page 19 ENTER/PRINT key to save it and proceed to the next prompt. Consult Direct Supply Equipment & Furnishings for the Acceleration of Gravity value for your location. O P G C...
  • Page 20 Setup & Calibration (cont.) b A n d = (AUTO LOCK RESET BAND) If Auto Lock is selected, the display will change to show the b A n d = (Auto Lock Reset Band) prompt. This is the number of division changes needed to reset the auto lock.

  • Page 21: Setup And Calibration

    • CAUTION! Selecting 1 or 2 enables battery charging. DO NOT select 1 or 2 when using Alkaline batteries. S L e e P = (Sleep Mode) The Sleep Mode feature also conserves battery power when the indicator remains unused for a period of approximately 1 to 9 minutes. When enabled, the load cell excitation will be reduced and the display will show S L E E P .

  • Page 22: Setup Review

    To pair a Bluetooth-capable device with the scale, select the name of the scale from the list of available connections: 750DS2 SCALE XXXX. XXXX represent the last four digits of the Attendant Bluetooth Weight Indicator serial number. The serial number of the unit is located on a label on the top side of the indicator.

  • Page 23: Error And Status Displays

    Error & Status Displays Display Meaning - E r r - General error, invalid keypad entry was attempted. Attempting to display a negative number greater than –9,999 or a positive - O F - number greater than 99,999. Indicates an attempt to zero a weight outside scale zero range. (See Four - t r L - Percent Zero Tracking Range Limit).

  • Page 24: Event Counter

    Event Counter and Care & Cleaning Event Counter The Attendant Bluetooth Weight Indicator has been designed with an Event Counter type of security seal. When selected, the Attendant Bluetooth Weight Indicator will display two three digit numbers representing the Calibration and Configuration counters.

  • Page 25: Parts Identification

    Parts Identification Item Qty Description Keypad PC Board Rear Panel Front Panel End Cap Battery Holder Mounting Spear Washer, #6 Lock Int. Tooth Screw, #6X.375 TH Sheet Metal (Black) Screw, #6X.50 TH Sheet Metal (White) Screw, #6-32X.312 THMS W/THD-Lock Patch Serial Tag Optional AC Adapter 100-240VAC/12VDC @ 1 AMP...

  • Page 26: Appendix A - Indicator Mounting Brackets

    Appendix A INDICATOR MOUNTING BRACKETS Mounting Bracket Assembly...
  • Page 27 Limited Warranty We offer to you, as the original purchaser, a warranty for the Attendant Bluetooth Weight Indicator. Our warranty applies for the limited warranty period stated below. If any device or device part listed below is defective in material or workmanship during the applicable limited warranty period, we will repair or replace it at our cost.
  • Page 28 Distributed by Direct Supply Manufacturing , Inc. 6635 N Industrial Road, Milwaukee WI 53223. ® ™ ©2017 Direct Supply Manufacturing, Inc. All Rights Reserved. Direct Supply , Attendant , and all associated logos are the registered ® ® trademarks of Direct Supply Inc., used under license.
