- Page 1 GLCD2038A Lithium-ion Drill/Driver Perceuse / Tournevis de 20v lithium-ion Taladro / Tornillador de 20v de litio-ion Operator’s Manual Manuel d’utilisation Manual del Operario TOLL FREE 888-552-8665 HELP LINE: www.genesispowertools.com WEBSITE:...
-
Page 2: Specifications
SPECIFICATIONS • Model: ------------------------ GLCD2038A • Motor Input:------------------- 20V DC • No Load Speed:--------------- 0-350/0-1300 RPM, Reversible • Chuck Size:------------------- 3/8” (10mm) • Torque Settings:--------------- 22 • Max. Torque:------------------- 350 in.-lbs • Battery: ----------- - ----------- 20 Volt, Lithium-Ion, 1.5Ah • Charger Input:----------------- 120V~/ 60Hz • Charging time:---- ------------ 3-5 hours • Net weight: -------------------- 2 .5 Lbs Includes: 1-Battery, Charger and 1-Double-ended screwdriver bit WArNING: To reduce the risk of injury, user must read and understand this operator’s manual before operating this tool. -
Page 3: Work Area Safety
WORK AREA SAFETY Keep your work area clean and well lit. • Cluttered benches and dark areas invite accidents. Do not operate power tools in explosive atmospheres, • such as in the presence of flammable liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes. Keep bystanders, children, and visitors away while operating a power tool. • Distractions can cause you to lose control. ELECTRICAL SAFETY Power tool plugs must match the outlet •... - Page 4 Always use properly fitting NIOSH/OSHA approved respiratory protection appropriate for dust exposure, and wash exposed areas with soap and water. 20V Lithium-ion Drill/Driver Operator’s Manual GLCD2038A...
-
Page 5: Extension Cords
SERVICE • Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. • Service your power tool periodically. When cleaning a tool, be careful not to disassemble any portion of the tool since internal wires may be misplaced or pinched. WArNING: rEAD AND UNDErSTAND ALL WArNINGS, CAUTIONS AND OPErATING INSTrUCTIONS BEFOrE USING THIS EQUIPMENT. Failure to follow all instructions listed below may result in electric shock, fire and/or serious personal injury. -
Page 6: Important Safety Instructions For Charger
This will reduce the risk of explosion and possibly personal injury. Never use a battery which has been dropped or received a sharp blow. • damaged battery is subject to explosion. Properly dispose of a dropped or damaged battery immediately. Use designated battery pack (Genesis™ - Model GLAB20A) and charger • (Genesis™ - Model GLACH20AS) for this tool. use of any other batteries may result in a risk of fire. SAVE THESE INSTRUCTIONS IMPOrTANT SAFETY INSTrUCTIONS FOr CHArGEr &... - Page 7 Do not charge battery pack • when temperature is below 50 degrees f (10 degrees C) or above 104 degrees f (40 degrees C). Store tool and battery pack in a location where temperature will not exceed 122 degrees f (50 degree C). This is important to prevent serious damage to the battery cells. Place charger on flat non-flammable surface • and away from flammable materials when re-charging the battery pack. To reduce risk of electric shock, • unplug charger from outlet before attempting any maintenance or cleaning. f operating time has become excessively shorter, • I stop operating immediately. It may result in a risk of overheating, possible burns and even an explosion. Battery leakage may occur •...
-
Page 8: Contents In Package
If you find anything wrong, do not operate the tool until the parts have been replaced or the fault has been rectified. Failure to do so could result in serious personal injury. CONTENTS IN PACKAGE Description Q'TY Drill Charger Adaptor Charger Stand Screwdriver Bit Operator's Manual 20V Lithium-ion Drill/Driver Operator’s Manual GLCD2038A... -
Page 9: Operation
OPErATION WArNING: To reduce the risk of serious personal injuries, read and follow all important safety warning and instructions before using this tool. WArNING: Always be sure that the tool is switched off before insertion or removal of the battery pack. INSTALLING OR REMOVING THE BATTERY PACK (FIG 2) • To install the battery pack, slide the battery pack (1) into the... -
Page 10: Electric Brake
4. use a speed that will not strip the screw head or break the screw. Maintain your balance. GENERAL DRILLING 1. Clamp your workpiece. use torque setting 22 ( ) then exert enough pressure to start the drill bit and keep drilling. Do not force or stall the bit. Don’t bend or twist the bit. Let the tool and the drill bit do the work. 2. Maintain your balance and be prepared for binding and for bit breakthrough. WArNING: Forcing a drill bit, bending or twisting the bit, or failure to maintain balance in case of binding and breakthrough can result in serious personal injury. 20V Lithium-ion Drill/Driver Operator’s Manual GLCD2038A... -
Page 11: Maintenance
THIS PRODUCT IS NOT WARRANTED IF USED FOR INDUSTRIAL OR COMMERCIAL PURPOSES. ACCESSORIES INCLUDED IN THIS KIT ARE NOT COVERED BY THE 2 YEAR WARRANTY. BATTERY INCLUDED IS WARRANTED FOR ONE (1) YEAR AFTER DATE OF PURCHASE. TOLL-FrEE HELP LINE 888-552-8665 for questions about this or any other GeNeSIS Product, please call Toll-free: www.genesispowertools.com Or visit our web site: ©richpower Industries, Inc. All rights reserved Richpower Industries, Inc. - Page 12 Richpower Industries, Inc. 736 Hampton Road Williamston, SC USA www.richpowerinc.com 2015.08. V01...
