9. Download and install BLAZER WMS app for your smartphone operating system.
Available on app stores.
10. For initial setup, tap the "radio" icon
Simply select the module and enter the appropriate numerical password.
11. Once connected, hit the back button to return to the main screen.
12. Now, select your vehicle type by tapping on the arrow to the right of the initial
schematic.
13. Next, select Light Position setup to assign lights to different locations on your
vehicle. Tap on the terminal and then tap on the desired location. Repeat this for
the remaining terminals and then hit enter to return to the main screen.
14. You are now set up to operate your Lights.
15. Activate the system by tapping the power icon
that it is powered on
16. Now, select a light. The light icon will turn blue to indicate it is the active selection.
17. You can turn on and off the light via the "individual Terminal ON/OFF" switch.
18. Note, terminal 2A is used in conjunction with a warning light with different strobe
patterns built into it. Turning on and off this terminal advances the flash to the next
flash pattern. In absence of a warning light, this terminal can be used just like the
other terminals in order to power on and off lights etc..
a. Most warning lights with strobe function will have three wires. Black, red and
yellow. Black is to be connected to negative of 18A, red to positive terminal of
18A and yellow is for advancing the strobe patterns. Consult with the
manufacturer of the
circuit or on the positive side
terminal 2A
19. Terminal 2B has been specifically designated for additional light controls.
With applicable lights, you may use the respective sliders to adjust both
brightness and flash speed.

App Instructions

.
light to determine if yellow is on the negative side of the
and connect it to the appropriate polarity of
.
CWL623 OWNER'S MANUAL
BLAZER-INTERNATIONAL.COM
to go to the "Connect" screen.
. It will turn green to indicate
