Introduction
This Quick Start Guide acquaints users with Zilog's ZMOTION
provides instructions for setting up and using the kit to demonstrate its basic operation.
The following topics are covered:
Getting
Started: the quickest way to get the board up and running; see page 4
•
Installing the Pyroelectric Sensor
•
Installing the Lens
•
Installing ZDS II and the USB Smart Cable
•
Download and Run the Sample Project
•
Board Design Information
•
Kit Contents
™
ZMOTION
Development Board
•
USB Smart Cable Debugger
•
0.9" Focal Flat Lens Holder
•
0.77" Focal Circular Lens Holder
•
Selection of Lenses
•
Selection of Pyroelectric sensors
•
–
DB9
DB9 serial cable
•
Wall mount power supply
•
CD with Sample applications and product documentation
•
CD with ZDS II
•
Various mounting hardware
•
Figures 1 through 3 show images of the components of the kit plus the sensors and lenses
it contains. The
Getting Started
ZMOTION™ Detection and
Control Development Kit
Quick Start Guide
– see page 5
– see page 8
– see page 24
section follows on page 4.
Copyright ©2010 by Zilog
www.zilog.com
™
– see page 15
– see page 19
®
, Inc. All rights reserved.
QS007601-1010
Development Kit and
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ZiLOG ZMOTION
Summary of Contents for ZiLOG ZMOTION
- Page 1 Control Development Kit Quick Start Guide QS007601-1010 Introduction ™ This Quick Start Guide acquaints users with Zilog’s ZMOTION Development Kit and provides instructions for setting up and using the kit to demonstrate its basic operation. The following topics are covered: Getting Started: the quickest way to get the board up and running;...
- Page 2 ZMOTION™ Detection and Control Development Kit Quick Start Guide ZMOTION Pyroelectric USB Smart ZDS II & DB9–DB9 Power Supply Development Sensors (3) Cable (1) Application CDs (2) Serial Cable (1) Board (1) 0.77” Focal Circular Machine Screws Mica Washers 0.9” Focal Flat...
- Page 3 ZMOTION™ Detection and Control Development Kit Quick Start Guide Figure 2. The Three Pyroelectric Sensors, from left to right: RE200B-P, SDA02-54-P, and SBDI46-504AA QS007601-1010 Page 3 of 28...
-
Page 4: Getting Started
2. Install the CWM 0.5 GI V1 lens as described on page ™ 3. Insert the power supply output connector into jumper J1 on the ZMOTION Develop- ment Board and apply AC power to the power supply. 4. The Blue power LED will illuminate and the Red LED will initially illuminate and re- –... - Page 5 Installing the Pyroelectric Sensor ™ The Pyroelectric sensor used on the ZMOTION Development Board can be changed by inserting the device into the appropriate socket. Proper orientation is ensured by aligning the tab on the sensor to the silkscreened tab on the circuit board. The tab on each 3-pin pyroelectric sensor aligns to the silkscreened tab labeled U9.
- Page 6 ZMOTION™ Detection and Control Development Kit Quick Start Guide Figure 4. Pyroelectric Sensor installation The leads on the pyroelectric sensor should be trimmed no shorter than 2.3mm (.090") and no longer than 3.3mm (0.130"), as indicated in Figure 5. For more information about the...
- Page 7 ZMOTION™ Detection and Control Development Kit Quick Start Guide Figure 5. Trimming the leads on the pyro prior to installation QS007601-1010 Page 7 of 28...
-
Page 8: Installing The Lens
CM 0.77 GI V5 Flat Lens Holder 0.9 Focal AA 0.9 GI T1 When mounting the ZMOTION development board vertically or from Installation Note: the ceiling, special consideration should be taken regarding the height and levelness of the board. Be sure to follow the lens manufacturer’s recommended height requirements to ensure optimal performance. - Page 9 ZMOTION™ Detection and Control Development Kit Quick Start Guide Figure 6. NCL-9(26) Lens and PIR Sensor installed on the ZMOTION™ Development Board QS007601-1010 Page 9 of 28...
- Page 10 Figure 7. Figure 7. Assembled clip-in lens installed on the ZMOTION Development Board Circular Lens Holder The circular lens holder, shown in Figure 8 is a 2-piece assembly that provides a 0.77"...
- Page 11 Use the provided ¾" machine screws (2) with a nut to secure the cap in place. ™ 3. Place the lens and lens holder assembly on the to ZMOTION Development Board aligning the primary placement arrow on the lens holder with the secondary placement arrow on the circuit board, as shown in Figure 9.
- Page 12 ZMOTION™ Detection and Control Development Kit Quick Start Guide Figure 9. Top of lens holder on the ZMOTION™ Development Board ⅜ 4. Use the provided " machine screws (4) with a nut to secure the lens holder in place. See Figure 10.
-
Page 13: Flat Lens Holder
ZMOTION™ Detection and Control Development Kit Quick Start Guide Figure 10. Assembled Circular 0.77" Lens holder and Circular Lens installed on the ZMOTION™ Development Board Flat Lens Holder The flat lens holder, shown in Figures 11 and 12, is a two-piece assembly that provides a 0.9"... - Page 14 ZMOTION™ Detection and Control Development Kit Quick Start Guide Figure 11. Flat 0.9" Lens Holder (Cap and Base) Figure 12. Flat Lens: AA 0.9 GI T1 QS007601-1010 Page 14 of 28...
-
Page 15: Installing Zds Ii And The Usb Smart Cable
Figure 13. Assembled Flat 0.9" Lens Holder and Flat Lens Installing ZDS II and the USB Smart Cable Observe the following the steps to install Zilog Developer Studio (ZDS II) and its associ- ated documentation. 1. Insert the ZDS II CD into the CD-ROM drive. The DemoShield installer launches automatically. - Page 16 CD-ROM drive to your hard disk using Windows Explorer, or read the documentation directly from the CD-ROM itself. For customer service and technical support, Zilog recommends that you create an account at support.zilog.com. Installing the USB Smart Cable This section describes how to install the USB Smart Cable and associated driver software for your particular operating system.
- Page 17 1. Connect the Zilog USB device to the host PC. The wizard Found New Hardware should activate automatically after connecting the Zilog USB device for the first time. If prompted to connect to Windows Update, select No, not at this time 2.
- Page 18 Quick Start Guide 1. Connect the Zilog USB device to the host PC. The wizard should Add New Hardware activate automatically after connecting the Zilog USB device for the first time. 2. After the wizard has been activated, click Add New Hardware Next 3.
- Page 19 ZMOTION™ Detection and Control Development Kit Quick Start Guide Figure 14. Connecting the Six-Conductor Ribbon Cable to the USB Smart Cable 2. Attach the free end of the ribbon cable to the DBG connector (ZDI Interface) on the development board. Ensure that pin 1 on the ribbon cable (indicated by the dark stripe) is aligned with pin 1 on the target connector (indicated by a on P3 of the board).
- Page 20 2. Open the project. When you first receive your kit, this ZMOTION_Basic.zdsproj ™ project is already loaded into the ZMOTION MCU. Right-click within the open grey area below the menu icons and select to turn on the tabs at the bottom Workbook Mode of the editor and therefore make it easier to switch between files.
- Page 21 ZMOTION™ Detection and Control Development Kit Quick Start Guide ™ 4. Make sure the ZMOTION Development Board is powered OFF, then connect the USB Smart Cable (Debugger) to P3, as described above. 5. Apply power to the development board, then click the icon in ZDS II.
- Page 22 ZMOTION™ Detection and Control Development Kit Quick Start Guide 7. Click the icon to start the application running. The Red LED (LED3) will be ON initially until the pyroelectric sensor stabilizes – a period that can take up to 30 seconds.
- Page 23 Devel- API_INIT ™ opment Board. Use the Lens Selection Guide in the ZMOTION Lens and Pyroelectric Sensor Product Specification (PS0286) to determine which API_INT file is required for each lens and Pyroelectric Sensor combination.
- Page 24 408-513-1500 408-513-1500 408-513-1500 Website: www.zilog.com Website: www.zilog.com Website: www.zilog.com Title Title Title ZMOTION Bundled Solutions 8-Pin Series Development Kit ZMOTION Bundled Solutions 8-Pin Series Development Kit ZMOTION Bundled Solutions 8-Pin Series Development Kit Page Page Page Schematic Schematic Schematic Size...
- Page 25 ZMOTION™ Detection and Control Development Kit Quick Start Guide Mechanical Information Figure 18. ZMOTION™ Development Board Mechanical Diagram QS007601-1010 Page 25 of 28...
- Page 26 ZMOTION™ Detection and Control Development Kit Quick Start Guide Pyroelectric Sensor Socket Mechanical information for the socket that holds the pyroelectric sensor is shown below. The leads on the pyroelectric sensor should be trimmed no shorter than 2.3mm (.090") and no longer than 3.3mm (0.130").
- Page 27 ZMOTION™ Detection and Control Development Kit Quick Start Guide References Refer to the documentation in Table 2 for additional information about Zilog’s ZMOTION products. Table 2. ZMOTION Documentation Document Number Description PS0286 ZMOTION™ Lens and Pyroelectric Sensor Product Specification PS0285 ZMOTION™...
- Page 28 NOLOGY DESCRIBED HEREIN OR OTHERWISE. The information contained within this document has been verified according to the general principles of electrical and mechanical engineering. ZNEO is a registered trademark of Zilog, Inc. All other product or service names are the property of their respective owners. QS007601-1010...
