Quick Start Manual
Introduction
This Quick Start Guide acquaints users with Zilog's ZMOTION Intrusion Detection
Development Kit (part number ZMOTIONS200ZCOG) and provides instructions for set-
ting up and using the Kit to demonstrate its basic operation. The following topics are cov-
ered:
•
Getting
Started: the quickest way to get the board up and running; see page 3
•
Installing the
Lens: see page 5
Kit Contents
•
ZMOTION Intrusion Detection Development Board
•
USB SmartCable Debugger
•
1.2" focal flat lens holder
•
Three 1.2" focal flat lenses
–
ZWA12GI12V4
–
ZLR12GI12V3
–
ZVB12GIV1
•
Mini-USB serial cable
•
Wall mount power supply
•
Mounting hardware
Figure 1 shows the components of the Intrusion Detection Development Kit and Figure 2
displays the three lenses.
ZMOTION
Detection Development Kit
Quick Start Guide
®
Copyright ©2014 Zilog
www.zilog.com
Intrusion
®
, Inc. All rights reserved.
QS007802-1014
Advertisement
Table of Contents
Related Manuals for ZiLOG ZMOTION
Summary of Contents for ZiLOG ZMOTION
- Page 1 Quick Start Guide QS007802-1014 Introduction This Quick Start Guide acquaints users with Zilog’s ZMOTION Intrusion Detection Development Kit (part number ZMOTIONS200ZCOG) and provides instructions for set- ting up and using the Kit to demonstrate its basic operation. The following topics are cov- ered: •...
- Page 2 ® ZMOTION Intrusion Detection Development Kit Quick Start Guide 1.2" Lens Holder Figure 1. ZMOTION Intrusion Detection Development Kit Components QS007802-1014 Page 2 of 10...
-
Page 3: Getting Started
Figure 2. The Three Lenses contained in this Development Kit Getting Started The ZMOTION Intrusion Detection Development Kit contains several lens options. To provide a quick method of getting the Kit up and running, the ZMOTION MCU is initially programmed with a project using the RE200B-P pyroelectric ZMOTION_Intrusion_Demo sensor and the ZWA12GI12V4 lens. -
Page 4: Downloading Zmotion Software And Documentation
Checkout process to download the ZMOTION Software and Documentation files to your hard drive. (If you are a first-time visitor to the Zilog Store, you will be required to register before downloading this software). 2. When the download is complete, unzip the file to your hard drive, double-click to... -
Page 5: Installing The Lens
Quick Start Guide Installing the Lens Note: When mounting the ZMOTION Development Board vertically, special con- sideration should be taken regarding the height, angle and level plane of the board. Be sure to follow the lens manufacturer’s recommended height and mounting angle requirements to ensure optimal performance. - Page 6 ® ZMOTION Intrusion Detection Development Kit Quick Start Guide Figure 4. Flat Lens: ZWA12GI12V4 To assemble this flat lens and holder, observe the following brief procedure. 1. Place the lens into the inside of the cap, ensuring that the grooves of the lens are facing inward.
- Page 7 Figure 5. Assembled Flat 1.2" Lens Holder and Flat Lens 3. Place the lens and lens holder assembly onto the ZMOTION Development Board with the arrow on the lens holder pointing up, as shown in Figure 5; use the Primary Place- ment position labeled on the circuit board for the ZWA12GI12V4 lens.
-
Page 8: Installing Zds Ii And The Usb Smartcable
Intrusion Detection Development Kit Quick Start Guide Figure 6. Top of Lens Holder on the ZMOTION Development Board Installing ZDS II and the USB SmartCable To learn more about installing ZDS II and the USB SmartCable, installing the FTDI driver... - Page 9 ® ZMOTION Intrusion Detection Development Kit Quick Start Guide References Refer to the documentation in Table 1 for additional information about Zilog’s ZMOTION products. Table 1. ZMOTION Documentation Document Number Description PS0288 ZMOTION Intrusion Detection Product Specification PB0230 ZMOTION Intrusion Detection Product Brief...
- Page 10 NOLOGY DESCRIBED HEREIN OR OTHERWISE. The information contained within this document has been verified according to the general principles of electrical and mechanical engineering. ZMOTION is a registered trademark of Zilog, Inc. All other product or service names are the property of their respective owners. QS007802-1014...
