Thermolec DCC-9 Series Installation Manual

Main power supply 120/240-208v, single phase 100a - 125a
Hide thumbs Also See for DCC-9 Series:
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

INSTALLATION MANUAL
MANUEL D'INSTALLATION
MODELS
MODÈLES
DCC-9-40A, DCC-9-50A, DCC-9-60A
Manufactured by
Manufacturé par
1
E N G L I S H
F R A N Ç A I S
MAIN POWER SUPPLY
120/240-208V, Single Phase
100A - 125A
ALIMENTATION PRINCIPALE
120/240-208V, Monophasé
100A - 125A
APPROVED MARKET
North America
MARCHÉ AGRÉÉ
Amérique du Nord
Read and save these instructions
Lire et garder ces instructions
Designed by
Design par
NOVEMBER 2017 NOVEMBRE 2017 V4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCC-9 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Thermolec DCC-9 Series

  • Page 1 E N G L I S H F R A N Ç A I S INSTALLATION MANUAL MANUEL D’INSTALLATION MAIN POWER SUPPLY 120/240-208V, Single Phase 100A - 125A ALIMENTATION PRINCIPALE 120/240-208V, Monophasé 100A - 125A APPROVED MARKET North America MARCHÉ AGRÉÉ Amérique du Nord Read and save these instructions Lire et garder ces instructions...
  • Page 3: Table Of Contents

    Copyrights and Trade Names All information’s in this manual are subject to copyright protection Specifications and other intellectual property protection of THERMOLEC LTÉE. / RECHARGE VÉHICULE ÉLECTRIQUE and its licensors. This installation Characteristics manual cannot be modified, reproduced or copied without a prior writ- ten authorisation from THERMOLEC LTÉE.
  • Page 4: Safety Information

    Warning Precautions 7 – The components supplied for repairs 4 - THERMOLEC LTÉE. will not be held are guaranteed for the remaining of the Read all instructions prior using this Any improper use of the DCC – Charge...
  • Page 5: Characteristics

    CHARACTERISTICS TYPICAL INSTALLATION Conditions for application Electrical The DCC-9 manufactured by Thermolec is an Energy Management panel System specially designed to allow the connection of an EV Charger to EV Charger be connected to the main power of a unit when the electric meter is...
  • Page 6 NOTE: The DCC controller must be mounted so that STEP 4: CONDUCTOR CONNEXIONS the nameplate remains visible at all times. Consult the diagram on the next page for all details on the cable Do not install the DCC: connections configuration. This diagram is also found under the DCC - Outdoor cover.
  • Page 7 LEGEND LÉGENDE LOAD SHED CONTACTOR CONTACTEUR DE CHARGE MAIN POWER SUPPLY 120/240 - 208V DCC ELECTRONIC CONTROLLER DCC CONTRÔLEUR ÉLECTRONIQUE FUSE FUSIBLE DCC ELECTRONIC CONTROLLER ALIMENTATION PRINCIPALE 120/240 - 208V CIRCUIT BREAKER DISJONCTEUR CONTROLEUR ELECTRONIQUE DCC TRANSFORMER TRANSFORMATEUR CURRENT TRANSFORMER TRANSFORMATEUR DE COURANT PB SWITCH (RESET)
  • Page 8: Application

    LIGHTS CODE Charging station power supply 1. Put the circuit breaker in the ON position. 2. Check if the electric vehicle supply equipment (EVSE) is powered: Green The charging station is energized. EVSE powered: go to the next step. Green The charging station is energized.
  • Page 9 Toutes les informations contenues dans ce document sont soumises Information de sécurité aux droits d’auteur et aux autres droits de propriété intellectuelle de THERMOLEC LTÉE. / RECHARGE VÉHICULE ÉLECTRIQUE et ses Spécifications concédants de licence. Ce manuel d’installation ne peut pas être modifié, reproduit ou copié, en tout ou en partie, sans l’autorisa-...
  • Page 10: Information De Sécurité

    4 - THERMOLEC LTÉE. ne sera pas tenue tallation. original ou 90 jours. La plus longue des Ne jamais utiliser le DCC - Contrôleur de responsable de dommages ou délais et ne...
  • Page 11: Caractéristiques

    * approximatif, peut changer sans préavis. CARACTÉRISTIQUES EXEMPLE D’INSTALLATION Conditions d’applications Panneau Le DCC-9 de Thermolec est un contrôleur de charge pour véhicule électrique électrique spécialement conçu pour permettre de connecter une du condo borne de recharge en contexte de condo et d’immeuble multi-résiden- Borne de recharge tiels à...
  • Page 12 ÉTAPE 2 : PRÉPARATION À L’INSTALLATION 6. Vérifier que le DCC est fixé adéquatement au mur ou au plafond. 7. Défaire le support d’installation pour le plafond. 1. Couper l’alimentation principale 2. Choisir l’emplacement du DCC Installation au mur 1. Enlever les 4 vis du couvercle. Le DCC peut s’installer: - sur un plafond 2.
  • Page 13 LEGEND LÉGENDE LOAD SHED CONTACTOR CONTACTEUR DE CHARGE MAIN POWER SUPPLY 120/240 - 208V DCC ELECTRONIC CONTROLLER DCC CONTRÔLEUR ÉLECTRONIQUE FUSE FUSIBLE DCC ELECTRONIC CONTROLLER ALIMENTATION PRINCIPALE 120/240 - 208V CIRCUIT BREAKER DISJONCTEUR CONTROLEUR ELECTRONIQUE DCC TRANSFORMER TRANSFORMATEUR CURRENT TRANSFORMER TRANSFORMATEUR DE COURANT PB SWITCH (RESET)
  • Page 14: Utilisation

    UTILISATION ÉTAPE 6 : MISE EN MARCHE Alimentation du DCC Délais de recouvrement du véhicule électrique 1. Alimenter le DCC en électricité. À la suite d’une coupure d’alimentation de la borne de recharge, un délai de 15 minutes est enclenché afin de mesurer la consommation 2.
  • Page 15 ments = 6 minutes avant l’alimentation de la borne de recharge). Durant cette période, si la charge totale excède 80%, le temps de reprise reprendra du début. Rouge Mauvais fonctionnement.1) Vérifier tous les branchements. 2) Inspecter si les transformateurs de courant (CT) sont bien connectés et bien enclenchés.
