SymCom MotorSaver 250600 Installation Instructions page 4

SPECIFICATIONS
3-Phase Line Voltage
Frequency
Low Voltage (% of setpoint)
Trip
Reset
High Voltage (% of setpoint)
Trip
Reset
Voltage Unbalance (NEMA)
Trip
Reset
Trip Delay Time
Low / High Voltage Faults
Unbalance / Phasing Faults
Restart Delay Time
After a fault or complete power loss
Output Contact Rating - DPDT
Pilot Duty
General Purpose
Transient Protection
Power Consumption
Weight
Terminal
Wire AWG
Maximum Torque
Operating Temperature
UL
Visit our website at www.symcominc.com for our
complete catalog and new product listings!
Note: 50 Hz will increase all delay timers by 20%
475 to 600 VAC
50 or 60 Hz
90%
93%
110%
107%
6%
4.5%
4 Seconds
2 Seconds
Adjustable Manual, 2-300 Seconds
480 VA @ 240 VAC
10 A @ 240 VAC
IEC 1000-4-5 ; 1995 ± 6 kv
5 Watts (maximum)
14 Ounces
12-22 Gauge
7 inch-pounds
-40 to +70 C
o o
E68520
