Summary of Contents for Blink Video Doorbell
- Page 1 Blink Video Doorbell Setup Guide...
- Page 2 Thank you for purchasing Blink! The Blink Video Doorbell lets you see and hear what’s happening at your front door and talk back through your smartphone with its two-way talk feature. We want you to have your Blink Video Doorbell up and For even more information, please visit our support site at: support.blinkforhome.com...
- Page 3 If you created an account, in your app select “Add a System”. If you logged into Do you like the view from your Blink Video Doorbell? If not, adjust it using the an existing account, select “Add a Blink Device”.
- Page 4 Figure A (Optional) Figure B (Optional) Doorbell with vertical angled wedge. Doorbell with horizontal Door angled wedge. Page | 6 Page | 7...
- Page 5 Based on how you positioned your doorbell in the last step, select the mounting If you are mounting your Blink Video Doorbell to a brick, stucco or other mortar option below that best describes your setup. Go to the page number provided and surface, drill pilot holes and use the included anchors prior to mounting.
- Page 6 You can find your removable mounting template on page 35. Use the provided mounting template to either mark drill points or drill pilot holes for designated “mounting plate” holes. Remove mounting plate from Blink Video Doorbell unit if you haven’t already. Wires Wires Loosen wire contact screws from mounting plate to allow space to wrap wiring.
- Page 7 Line up mounting plate with drilled holes and secure using provided mounting Attach Blink Video Doorbell unit to mounting plate and secure with screw using screws. provided hex wrench. Turn power back on. Figure C Test Blink Video Doorbell and check that your house chime works.
- Page 8 “mounting plate” holes. You can find your removable mounting template on page 35. Mounting plate Remove mounting plate from Blink Video Doorbell unit if you haven’t already. Screw mounting plate to wall using provided mounting screws. Continue on to the next page.
- Page 9 Figure B Blink Video Doorbell Blink Video Doorbell Attach Blink Video Doorbell unit to mounting plate and secure with screw using provided hex wrench. Turn power back on (if applicable). Test Blink Video Doorbell. Congratulations, you have installed your doorbell!
- Page 10 Figure A No Wires, Wedge Drill holes Screw 3/4 inch Use the provided mounting template to either mark drill points or drill pilot holes for designated “wedge” holes. You can find your removable mounting template on page 35. Note: Vertical wedge installation is the same as horizontal wedge installation. Wedge Secure wedge to wall using provided mounting screws.
- Page 11 Remove mounting plate from Blink Video Doorbell unit if you haven’t already. Attach Blink Video Doorbell unit to mounting plate and secure with screw using provided hex wrench. Line up holes on mounting plate with small holes on wedge and secure with provided mounting screws.
- Page 12 Figure A Wires and wedge Drill holes Screw 3/4 inch Position mounting template so that wires fit through designated “wiring” hole on template. You can find your removable mounting template on page 35. Note: Vertical wedge installation is the same as horizontal wedge installation. Use the provided mounting template to either mark drill points or drill pilot Wedge holes for designated “wedge”...
- Page 13 Remove mounting plate from Blink Video Doorbell unit if you haven’t already. Wrap wires around loosened screws and tighten securely (color of wire does not matter). Loosen wire contact screws from mounting plate to allow space to wrap wiring. Continue on to the next page.
- Page 14 Line up holes on mounting plate with small holes on wedge and secure with Attach Blink Video Doorbell unit to mounting plate and secure with screw using provided mounting screws. provided hex wrench. Turn power back on. Figure D Test Blink Video Doorbell and check that your house chime works.
- Page 15 If you are experiencing trouble Or need help with your Blink Video Doorbell or other Blink products, please visit support.blinkforhome.com for systems instructions and videos, troubleshooting information, and links to contact us directly for support. You can also visit our Blink Community at www.community.blinkforhome.com...
-
Page 16: Important Safeguards
BEFORE removing the existing doorbell or contact with skin or clothes, flush with water immediately. installing the Blink Video Doorbell so as to avoid fire, electric shock, or other injury or damage. You should turn off power at the circuit breaker or fuse and test that power is off before wiring. - Page 17 The Blink Video Doorbell meets the FCC Radio Frequency Emission Guidelines and is certified with the FCC. Information on the Blink Video Doorbell is on file with the FCC and can be found by inputting the device’s FCC ID into the FCC ID Search form available at https://www.fcc.gov/oet/ea/fccid.
-
Page 18: Mounting Template
Contact information: For communications concerning the Agreements, you may contact Blink by writing to Immedia Semiconductor, LLC, 100 Burtt Rd, Suite 100, Andover MA 01810, USA. Mounting Template Copyright Immedia Semiconductor 2018. Blink and all related logos and motion marks are trademarks of Amazon.com, Inc. or its affiliates.
Need help?
Do you have a question about the Video Doorbell and is the answer not in the manual?
Questions and answers
I keep getting error message that my blink doorbell is not syncing with my current system
To fix the syncing error with your Blink Video Doorbell, follow these steps:
1. Reset the Doorbell:
- Turn the doorbell around and locate the reset button.
- Press and hold the reset button for about 30 seconds.
- Wait for the red light to start blinking slowly, indicating the reset is complete.
2. Remove the Device from the Blink App:
- Open the Blink Home Monitor App.
- Delete the doorbell from the app to allow successful re-pairing.
3. Re-Pair the Doorbell:
- Follow the setup process in the Blink Home Monitor App.
- Ensure you have a stable Wi-Fi connection.
These steps should resolve the syncing error.
This answer is automatically generated
What and when do I use the sync module?
The Sync Module 2 for the Blink Video Doorbell connects up to 10 Blink devices and allows local storage of motion-triggered recordings on a USB flash drive. It is not required for basic functionality, as the doorbell can operate independently over Wi-Fi, sending notifications and recording motion events. However, the Sync Module 2 is useful if you want local storage instead of relying on cloud storage, access to On-Demand Live View and two-way audio at any time, and improved connectivity for multiple Blink devices.
This answer is automatically generated
What are the requirements for the doorbell transformer? Can you link to a transformer on amazon that would work with this product.
The Blink Video Doorbell requires a transformer with a minimum specification of 16 VAC and 10 VA to ensure proper operation and battery life extension.
This answer is automatically generated
Hoe kan ik het geluid van de bel binnen horen
You can hear the sound of the Blink Video Doorbell inside using the following methods:
1. In-Home Chime: If your doorbell is connected to compatible chime wiring (16 - 24 VAC at 50 - 60Hz, 40VA max), your existing in-home chime will sound when the doorbell is pressed.
2. Mini Camera: If your Blink Mini Camera and Video Doorbell are on the same system, the Mini Camera can play a chime sound when the doorbell is pressed.
3. Blink App: The Blink app can generate a chime sound on your mobile device when the doorbell is pressed.
4. Alexa Devices: If compatible Alexa devices are connected and notifications are enabled in Alexa settings, they can announce when the doorbell is pressed.
You can also customize the doorbell sound in the settings of the Blink app.
This answer is automatically generated
My Blink video doorbell seems to be working fine EXCEPT that without any reason the connected wired house doorbell chimes. I check the outside view and see nothing.
Your Blink Video Doorbell may cause the wired house doorbell to chime without reason due to incorrect wiring or a short in the system. If the wires are crossed or touching at the mounting bracket or inside the chime box, it can trigger the chime unexpectedly. Check the wiring connections to ensure they are secure and not shorting. Also, verify that the door chime settings in the Blink app are configured correctly.
This answer is automatically generated
if you have 2 doorbells and a moduel and ope a subscription do i disconnect the moduel
No, if you want to use Live View and two-way audio at any time on demand, you need a Sync Module. Without it, these features are only available within 60 seconds of a motion or doorbell notification.
This answer is automatically generated
when using a subscription do you disconnect your moduel
No, using a subscription with the Blink Video Doorbell does not require disconnecting the Sync Module.
