- Page 1 8011M ACOUSTIC DECK UNIT U S E R H A R D W A R E M A N U A L 0004811_REV_D February 2016 EdgeTech 4 Little Brook Road West Wareham, MA 02576 Tel: (508) 291-0057 Fax: (508) 291-2491...
- Page 2 The information, figures, and specifications in this manual are proprietary and are issued in strict confidence on condition that they not be copied, reprinted, or disclosed to a third party, either wholly or in part, without the prior, written consent of EdgeTech. Any reproduction of EdgeTech supplied software or file sharing is strictly prohibited.
-
Page 3: Attention - Read This First
ATTENTION – READ THIS FIRST! All personnel involved with the installation, operation, or maintenance of the equipment described in this manual should read and understand the warnings and cautions provided below. CAUTION! This equipment contains devices that are extremely sensitive to static electricity. -
Page 4: Hardware Variations And Compatibility
HARDWARE VARIATIONS AND COMPATIBILITY The 8011M Acoustic Deck Unit contains both standard and proprietary hardware. At times, EdgeTech may change the standard components due to their availability or performance improvements. Although the component manufacturers—along with their models and styles—may change from unit to unit, replacement parts will generally be interchangeable. -
Page 5: About This Document
ABOUT THIS DOCUMENT We, the employees at EdgeTech, would like to thank you for purchasing 8011M. At EdgeTech, it is our policy to provide high-quality, cost-effective products and support services that meet or exceed your requirements. We also strive to deliver them on-time, and to continuously look for ways to improve them. -
Page 6: Warranty Statement
All equipment manufactured by EdgeTech is warranted against defective components and workmanship for a period of one year after shipment. Warranty repair will be done by EdgeTech free of charge. Shipping costs are to be borne by the customer. Malfunction due to improper use is not covered in the warranty, and EdgeTech disclaims any liability for consequential damage resulting from defects in the performance of the equipment. -
Page 7: Returned Material Authorization
RETURNED MATERIAL AU THORIZATION Prior to returning any equipment to EdgeTech, a Returned Material Authorization (RMA) number must be obtained. The RMA will help us identify your equipment when it arrives at our receiving dock and track the equipment while it is at our facility. The material should be shipped to the address provided in the EdgeTech Customer Service section. - Page 8 5. If the equipment is the property of EdgeTech (formerly EG&G Marine Instruments Division), please insure for full value. 6. Fax one invoice, packing list, and a copy of the airway bill to EdgeTech upon shipment. 8011M ACOUSTIC DECK UNIT...
-
Page 9: Customer Service
CUSTOMER SERVICE Customer service personnel at EdgeTech are always eager to hear from users of our products. Your feedback is welcome, and is a valuable source of information which we use to continually improve these products. Therefore we encourage you to contact EdgeTech Customer Service to offer any suggestions or... -
Page 10: Company Background
USBL positioning systems, and bathymetric systems—that have become standards in the industry. EdgeTech has also consistently anticipated and responded to future needs through an active research and development program. Current efforts are focused on the application of cutting-edge CHIRP and acoustic technology. -
Page 11: Table Of Contents
TABLE OF CONTENTS ATTENTION – READ THIS FIRST! ......................iii HARDWARE VARIATIONS AND COMPATIBILITY .................. iv ABOUT THIS DOCUMENT ........................v Purpose of this Manual ..........................v Liability ..............................v Warnings, Cautions, and Notes ......................... v WARRANTY STATEMENT ........................vi RETURNED MATERIAL AUTHORIZATION ................... - Page 12 4.2.5.1 8011M Host Mode Serial Commands ................4-9 8011M ACOUSTIC DECK UNIT 0004811_REV_D...
-
Page 13: List Of Tables
xiii LIST OF TABLES Table 2-1: General Specifications....................... 2-1 Table 2-2: 8012M Transducer Specifications ..................... 2-1 Table 4-1: Keypad Descriptions........................4-4... -
Page 15: Section 1: Overview
EdgeTech. The 8011M comes standard with a deck unit, set of headphones, spare connector for the auxiliary port, and a model 8012M transducer for dropping off the side of a vessel to transmit and receive acoustic signals. -
Page 17: Section 2: Specifications
SECTION 2: SPECIFICATIONS The specifications for the 8011M Acoustic Deck Unit are shown in Table 2-1 Table 2-2: GENERAL Frequencies Interrogate and Reply frequencies select 7.5 to 15 kHz Transmit 7.5 to 15.0 kHz - Operator adjustable Receive 7.0 to 15.0 kHz - Operator selectable multiple channels... -
Page 18: Auxiliary Cable Pin Out
Detect goes high on detection of a valid reply pulse this signal is delayed by 11 milliseconds from the actual detection. Pin 4 Trigger If the deck unit is in the ranging mode a positive edge in on this pin will initiate a ranging operation. The auxiliary port is 5 volt logic. 8011M ACOUSTIC DECK UNIT 0004811_REV_D... -
Page 19: Section 3: Installation
NOTE: On the early 8011M systems, the transducer connector is a Spirit, which is the same as used on earlier EG&G, EdgeTech, and ORE Offshore deck units. Transducers from these systems can be used with the 8011M. However, if the shorter (32 meter cable) transducer is used, the output power will be slightly reduced. - Page 20 6. The 8011M has an internal rechargeable battery. To fully charge the internal battery, the system must be plugged in and turned on for 5 hours. The 8011M will run on the internal battery for 4 to 6 hours depending on use.
-
Page 21: Section 4: Operation
2. Press the <CMD> key to send a standard ORE Offshore or EdgeTech command. Then enter the 6 digit command and press <ENT> to send it or <CLR> to modify it if needed. The display will change to (sending command now) and then (waiting for reply) until a reply is received. -
Page 22: Ranging (
The interrogate frequency is the frequency transmitted from the 8011M deck unit and the reply frequency is the frequency received by the 8011M deck unit. The correct frequencies can be found on the configuration sheet supplied with the underwater unit. Note: If you are testing an underwater unit in air use item 5 to change the minimum range gate to “0”.) - Page 23 8 seconds. 7. The default speed of sound in water used by the 8011M is 1500 meters per second. This can be changed by using the range set up menu. To enter a speed of sound first press <MENU> select item 2 (range set up) then item 6 (more options).
-
Page 24: Detailed Operating Instructions
0 to 9. Headphone volume (picture of a set of headphones) Range is 0 to 9 with 9 being the loudest. Backlight (picture of a light bulb) Pressing this will toggle the backlight on and off. 8011M ACOUSTIC DECK UNIT 0004811_REV_D... -
Page 25: Menu (
4.2.2 Menu (<MENU>) The <MENU> key is used to access the setup capabilities of the Model 8011M. In general when an item is selected in a menu either that item is chosen or a value will need to be entered or adjusted up and down. -
Page 26: Commands
7 to 8 pulse or 14 to 15 pulses long. Pressing <ENT> will exit the listening mode. EdgeTech acoustic equipment uses a 16 bit FKS code. The actual code that the operator enters is a six- digit code. The first digit encodes the two frequencies used for transmission and must be between 1 and 6 inclusive. -
Page 27: Ranging
4.2.5 Serial Port Operations The model 8011M acoustic deck unit has an RS232 port available to the user. The port can be used to log activity or to remotely control the deck unit. The 8011M serial port is always in logging mode when it is not under remote control (host mode). - Page 28 HOST MODE: press any key to exit While in host mode the 8011M will echo all characters sent in the com port. If using a terminal emulation program be sure to configure it not to locally echo characters. Host mode commands must exactly match the prescribed format, otherwise they will be rejected.
- Page 29 After the first reply is detected the 8011M will send a question mark and then send either a period or question mark every 250mS. A question mark indicates a valid reply was detected during that 250mS time period, a period indicates nothing was detected. The listening mode is terminated by sending a carriage return / line feed.
- Page 30 - An asterisk response from the 8011M (*) indicates command accepted. - A pound sign response from the 8011M (#) indicates serial command error. - Serial port is always in logging mode when not in Host mode.
