Button/Ports - Huawei WS5200 Product Description

HUAWEI Router WS5200
Product Description

1.2 Button/Ports

Figure 1-2 Button/Ports
Table 1-1 Buttons and ports
No.
1
2
3
4
5
01 (2018-01-26)
Button/Port Description
Hi button The indicator will flash red slowly when the router discovers a
device that supports HUAWEI HiLink. You can press the Hi
button to connect the device to the router's Wi-Fi.
By pressing the Hi button, you can also enable WPS to connect
a WPS device to the router.
Devices that support HUAWEI HiLink include: HUAWEI routers,
HUAWEI mobile phones (EMUI 5.0 or later), etc.
Power port Connect the power adapter to this port.
WAN port The blue port that connects to the Internet (e.g., a fiber optic
modem/broadband modem/cable modem).
LAN ports The grey ports that connect to network devices such as a
computer.
Reset button When the router is powered on, you can use a pointed object to
press and hold the reset button for more than two seconds until
the indicator turns off. The router should now be restored to
factory settings.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
NOTE
3
