alatech SC003 Quick Start Manual

ALATECH
MAGNET-LESS CYCLING
SPEED / CADENCE SENSOR
FEA TURES
Dual Band Technology
The sensor can connect to both
smartphones and ANT+ bike computers
via its ANT+ and Bluetooth capabilities.
Wireless Connection
The sensor wirelessly track speed or
cadence while cycling. Easy installation,no
magnet required
Accurate Measurement
Provides you with accurate speed and
cadence data during your ride.

IN THE BOX

1
Speed Sensor
2
Hub rubber pad
PLACE BA TTERY
1
Twist the battery cover counter-clockwise to OPEN to remove the cover.
2
Place the battery (CR 2032) into the cover with positive (+) side facing the
inside of the battery cover. Make sure the O-ring is in the groove of the battery
cover.
3
To replace the battery cover, aligned the cover dot with OPEN.
4
Press and twist the cover clockwise back into place (the cover dot points to
LOCK).
5
Check the battery back cover is indeed locked to ensure water resistance.
INST ALLA TION
Used As A Speed Sensor
If you do not have two sensors and use one of
them as a speed sensor, please skip this task.
1
Select the smallest size hub rubber ring that
can fits your wheel hub securely.
2
Place the sensor on the hub rubber pad with
logo facing up. Hold them on top of the wheel
hub.
3
Pull the hub rubber ring around the wheel hub,
and attach it to the hook on both sides of the
sensor.
4
Rotate the wheel for detection
move and touch other parts of your bike.
Used As A Cadence Sensor
If you do not have two sensors and use
one of them as a cadence sensor, please
skip this task.
1
Place the sensor on the crank rubber
pad with logo facing up. On the
non-drive side, hold them on the crank
arm.
2
Pull the crank rubber ring around the crank arm, and
attach it to the hook on both sides of the sensor.
3
Rotate the crank arm for detection
move and touch any part of your shoe or bike.
Quick Start Guide
.
3
Cadence Sensor
4
Crank rubber pad
1
O-ring
Note1, 3
SC003
APPS
Ala cycling (Compatible with
other APP , like as Wahoo fitness)
Compatible with iPhone 4S or
later, and with selected Android
devices using Android 4.4 or
later and support Bluetooth 4.0.
2
, the sensor should not
Note2
Note1, 3
, the sensor should not
Note2
(Android / iOS)
5
Ø26.4
Crank rubber ring
6
Hub rubber ring
3
Ø50
Ø57
Ø63
4
