Arnott SK-2806 Installation Manual

Front shock kit for 2007-2014 gm full size suvs
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Congratulations on your purchase of an Arnott
offer a high quality product at the industry's most competitive pricing. Thank you for your confidence in us and
Proper installation is essential to experience and appreciate the benefits of this system. Please take a moment
to review these installation instructions before you begin to install these components on your vehicle. The
removal and installation of air suspension products should only be performed by a fully qualified, ASE
It is equally important to be aware of all necessary safety measures while installing your new Air Suspension
System. This includes proper lifting and immobilizing of the vehicle and isolation of any stored energy to
WARNING: The air suspension system is under pressure (up to 10 bar, or 150 lbf/in). Verify pressure has been relieved
and disconnect power to the air suspension system prior to disassembly. Do not allow dirt or grease to enter the system.
Always wear standard hand, ear, and eye protection when servicing the air suspension system.
Arnott
is committed to the quality of its products. If you have a question or problem with any Arnott product,
®
please contact Arnott by calling 800-251-8993 during normal business hours or email techassistance@arnottinc.com.
(In the EU please call +31 (0)73 7850 580 or email info@arnotteurope.com)
1
SK-2806
ARNOTT FRONT SHOCK KIT
FOR
GM FULL SIZE SUVs
air suspension product. We at Arnott Incorporated are proud to
®
our product.
Certified, professional.
prevent personal injury or property damage.
"Engineered to Ride, Built to Last
2806
SK-
2007-2014
"
®
REV 3
09/23/2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SK-2806 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Arnott SK-2806

Summary of Contents for Arnott SK-2806

  • Page 1 Always wear standard hand, ear, and eye protection when servicing the air suspension system. Arnott is committed to the quality of its products. If you have a question or problem with any Arnott product, ® please contact Arnott by calling 800-251-8993 during normal business hours or email techassistance@arnottinc.com.

  • Page 2: Figure

    2806 ARNOTT FRONT SHOCK KIT 2007-2014 GM FULL SIZE SUVs GENERAL INFORMATION: Reading this manual signifies your agreement to the terms of the general release, waiver of liability, and hold harmless agreement, the full text of which is available at www.arnottinc.com.
  • Page 3 2806 ARNOTT FRONT SHOCK KIT 2007-2014 GM FULL SIZE SUVs LIFT THE HOOD TO EXPOSE THE TOP OF THE COIL STRUT. LOCATE AND DISCONNECT THE ELECTRICAL CONNECTOR. (FIGURES 10-3, 10-4) FIGURE 10-3 FIGURE 10-4 REMOVE THE 3 WIRE CLIPS AND TOP MOUNTING NUTS. (FIGURES 10-5, 10-6, 10-7)
  • Page 4 2806 ARNOTT FRONT SHOCK KIT 2007-2014 GM FULL SIZE SUVs REMOVE THE TWO (2) LOWER MOUNTING BOLTS. (FIGURES 10-8, 10-9) FIGURE 10-8 FIGURE 10-9 LOOSEN, DO NOT REMOVE, THE SWAY BAR END LINK HARDWARE. (FIGURE 10-10) FIGURE 10-10 CAREFULLY REMOVE COIL STRUT FROM THE VEHICLE. (FIGURE 10-11)
  • Page 5 2806 ARNOTT FRONT SHOCK KIT 2007-2014 GM FULL SIZE SUVs Use a spring compressor tool for the following removal steps. SHOCK REMOVAL RELEASE CLIP AND REMOVE THE TOP ELECTRICAL CONNECTOR AND SHOCK ROD STEM. (FIGURES 20-1, 20-2, 20-3, 20-4) FIGURE 20-1...

  • Page 6: Table Of Contents

    2806 ARNOTT FRONT SHOCK KIT 2007-2014 GM FULL SIZE SUVs COMPRESS THE COIL SPRING AND REMOVE THE TOP SHOCK ROD NUT. (FIGURES 20-5, 20-6) FIGURE 20-5 FIGURE 20-6 REMOVE TOP MOUNT PLATE, OFFSET PLATE AND RUBBER ISOLATOR. (FIGURES 20-7, 20-8)
  • Page 7 2806 ARNOTT FRONT SHOCK KIT 2007-2014 GM FULL SIZE SUVs COIL STRUT REASSEMBLY Tighten all nuts and bolts to manufacturer's specifications during the assembly process. ASSEMBLY IS IN REVERSE ORDER OF SHOCK DISASSEMBLY. COIL STRUT INSTALLATION Tighten all nuts and bolts to manufacturer's specifications during the installation process.
  • Page 8 2806 ARNOTT FRONT SHOCK KIT 2007-2014 GM FULL SIZE SUVs COIL SENSOR INSTALLATION INSTALL THE COIL SENSOR, PROVIDED IN THIS KIT, ONTO THE TOP OF THE SHOCK ROD. TIGHTEN UNTIL SECURE. (FIGURE 40-1, 40-2) FIGURE 40-1 FIGURE 40-2 CONNECT THE VEHICLE’S ELECTRICAL CONNECTOR TO THE COIL SENSOR. (FIGURES 40-3, 40-4)
