INSTALLATION
AND
OPERATING
INSTRUCTIONS
UNIT MUST BE KEPT CLEAR OF COMBUSTIBLES AT ALL TIMES
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and
!
liquids in the vicinity of this or any other appliance.
WARNING: Improper installation, adjustment, alteration, service or maintenance can
!
cause property damage, injury or death. Read the Installation, Operating and
Maintenance Instructions thoroughly before installing or servicing this equipment.
Initial heating of unit may generate smoke or fumes and must be done in a well ventilated area.
Overexposure to smoke or fumes may cause nausea or dizziness.
This equipment has been engineered to provide you with year-round dependable service when used
according to the instructions in this manual and standard commercial kitchen practices.
Phone:
(214) 421-7366
Fax:
(214) 565-0976
Toll Free: (800) 527-2100
Website: www.apwwyott.com
E-mail:
info@apwwyott.com
R
TM
Model:
HOLDING DRAWERS
INTENDED FOR OTHER THAN HOUSEHOLD USE
RETAIN THIS MANUAL FOR FUTURE REFERENCE
HDX
1
ANSI/NSF4
P/N 70504626
APW WYOTT
729 Third Avenue
Dallas, TX 75226
!
!
9/05
Advertisement
Related Manuals for APW Wyott Ease Extreme HDX-1-120
Summary of Contents for APW Wyott Ease Extreme HDX-1-120
- Page 1 This equipment has been engineered to provide you with year-round dependable service when used according to the instructions in this manual and standard commercial kitchen practices. ANSI/NSF4 P/N 70504626 9/05 Phone: (214) 421-7366 Fax: (214) 565-0976 APW WYOTT Toll Free: (800) 527-2100 Website: www.apwwyott.com 729 Third Avenue E-mail: info@apwwyott.com Dallas, TX 75226...
- Page 2 Never hold food below 150°F (66°C). Warranty Information: Reliability Backed ByAPW Wyott’s Warranty: All APW Wyott Holding Drawers are backed by a one year parts and labor warranty, including On-Site Service calls within 50 miles of authorized service technicians. Service Information:...
-
Page 3: Specifications
2. SAFETY INFORMATION APW Wyott Holding Drawers are designed, built and sold for commercial use and should be operated by trained personnel only. Clearly post all CAUTIONS, WARNINGS and OPERATING INSTRUCTIONS near each unit to insure proper operation and to reduce the chance of personal injury and/or equipment damage. - Page 4 HDX-1 HDX-2 25.580 21.000 25.580 21.000 25.287 15.912 4.000 4.000 22.860 18.397 22.860 18.397 HDX-3 HDX-4 21.000 25.580 25.580 21.000 44.037 34.662 6.00 4.000 18.397 22.880 22.860 18.397...
- Page 5 WARNING: ELECTRICAL SHOCK HAZARD. FAILURE FOLLOW INSTRUCTIONS IN THIS MANUAL COULD RESULT IN SERIOUS INJURY OR DEATH. Electrical Ground is required on this appliance. Do not modify the power supply cord plug. If it does not fit into the outlet, have the proper outlet installed by a qualified electrician Do not use an extension cord with this appliance.
- Page 6 HDX-1 EXPLODED VIEW % # "$ ...
- Page 7 HDX-1 PARTS LIST QUAN QUAN ITEM PART NUMBER DESCRIPTION ITEM PART NUMBER DESCRIPTION 70504101 70504624 S/A, COMPONENT PARTS WELD ASSY, BASE BOTTOM 88961 NUT, HEX 10-24, GREEN 70504601 W/ASS'Y, RIGHT SIDE PANEL 70504812 70504605 W/ASS'Y, LEFT SIDE PANEL P CLIP 70504100 W/ASS'Y, BOTTOM SHELF 70504805...
- Page 8 HDX-2 EXPLODED VIEW 28 27 47 49 % # " ...
- Page 9 HDX-2 PARTS LIST QUAN QUAN ITEM PART NUMBER DESCRIPTION ITEM PART NUMBER DESCRIPTION 70504101 WELD ASSY, BASE BOTTOM 89491 SWITCH, ROCKER 70504102 W/ASS'Y, RIGHT SIDE PANEL 89207 HEYCO BUSHING .750 P/N 2093 70504103 W/ASS'Y, LEFT SIDE PANEL 88989 STANDOFF, #4-40, MALE /FEMALE 70504801 SHELF, MIDDLE 70504623...
- Page 10 HDX-3 EXPLODED VIEW 44 46 % # "! ...
- Page 11 HDX-3 PARTS LIST QUAN QUAN ITEM PART NUMBER DESCRIPTION ITEM PART NUMBER DESCRIPTION 70504101 WELD ASSY, BASE BOTTOM 89491 SWITCH, ROCKER 70504304 W/ASS'Y, RIGHT SIDE PANEL 88989 STANDOFF, #4-40, MALE /FEMALE 70504307 W/ASS'Y, LEFT SIDE PANEL 89207 HEYCO BUSHING .750 P/N 2093 70504801 SHELF, MIDDLE 70504622...
- Page 12 HDX-4 EXPLODED VIEW % # "" ...
- Page 13 HDX-4 PARTS LIST QUAN QUAN ITEM PART NUMBER DESCRIPTION ITEM PART NUMBER DESCRIPTION 70504101 WELD ASSY, BASE BOTTOM 88961 NUT, HEX 10-24, GREEN 70504401 W/ASS'Y, RIGHT SIDE PANEL 70504812 P CLIP 70504403 W/ASS'Y, LEFT SIDE PANEL 70504805 HDX ELEMENT, 120V 70504801 SHELF, MIDDLE 70504806...
- Page 14 6. WIRING DIAGRAMS HDX-1 (120, 208 &240V) RELAY 1 NEUTRAL POWER CONTROL 1 ELEMENT YELLOW PROBE 120V, 208 & 240 - 450W TYP FOR ALL CONTROLS SWITCH...
- Page 15 HDX-2 (120, 208 &240V) RELAY 1 RELAY 2 NEUTRAL POWER CONTROL 2 ELEMENT 120V, 208 & 240 - 450W CONTROL 1 YELLOW ELEMENT PROBE 120V, 208 & TYP FOR ALL CONTROLS 240 - 450W SWITCH...
- Page 16 HDX-3 (120, 208 &240V) RELAY 1 RELAY 2 NEUTRAL POWER RELAY 3 CONTROL 3 ELEMENT 120V, 208 & 240 - 450W CONTROL 2 ELEMENT 120V, 208 & 240 - 450W CONTROL 1 YELLOW PROBE ELEMENT 120V, 208 & TYP FOR ALL CONTROLS 240 - 450W SWITCH...
- Page 17 HDX-4 (120, 208 &240V) RELAY 1 RELAY 2 RELAY 3 RELAY 4 NEUTRAL POWER CONTROL 4 ELEMENT 120V, 208 & 240 - 450W CONTROL 3 ELEMENT 120V, 208 & 240 - 450W CONTROL 2 ELEMENT 120V, 208 & CONTROL 1 240 - 450W YELLOW PROBE...
- Page 18 7. CLEANING General Cleaning Instructions: NEVER clean any electrical unit by immersing it in water. Turn off before surface cleaning. Always clean equipment thoroughly before first use. Clean unit daily. Except where noted on charts: Use warm, soapy water. Mild cleansers and PLASTIC scouring pads may be used to remove baked-on food and water scale.
- Page 19 IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment. For Warranty Service and/or Parts, this information is required. Model Number Serial Number Date Purchased Notes:...
- Page 20 APW Wyott's option or its Authorized Service Agency, it will be serviced on site or replaced. From day two through the conclusion of this warranty period, portable units must be taken to or sent prepaid to the APW Wyott Authorized Service Agency for in-warranty repairs.
