Summary of Contents for Visionis VIS-3020
- Page 1 VIS-3020 Fingerprint and Card Reader User Manual www.visionistech.com...
- Page 2 Fingerprint and Card Reader User Manual User Manual About this Manual This manual is applied for fingerprint and card Reader. The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only.
- Page 3 Fingerprint and Card Reader User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 4 Fingerprint and Card Reader User Manual EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under Directive 2014/30/EU, the RoHS Directive 2011/65/EU. 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union.
- Page 5 Fingerprint and Card Reader User Manual This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements. Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death.
- Page 6 Fingerprint and Card Reader User Manual If smoke, odors or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center. If the product does not work properly, please contact your dealer or the nearest service center.
- Page 7 Fingerprint and Card Reader User Manual Please keep all wrappers after unpack them for future use. In case of any failure occurred, you need to return the device to the factory with the original wrapper. Transportation without the original wrapper may result in damage on the device and lead to additional costs.
-
Page 8: Table Of Contents
Fingerprint and Card Reader User Manual Content Chapter 1 Introduction ............3 Product Overview ............. 3 Product Appearance ..........3 Chapter 2 Installation ............5 Introduction for DIP Switch ........5 Definition of Cable ............ 6 Wiring Cables ............6 Installing Card Reader .......... -
Page 9: Chapter 1 Introduction
Fingerprint and Card Reader User Manual Chapter 1 Introduction 1.1 Product Overview Fingerprint and card reader is a kind of high-performance product, with a 32 bit high-speed processor. It communicates with access controller via the RS-485 protocol. And a built-in tamper-proof module helps to protect card reader from malicious damage. - Page 10 Fingerprint and Card Reader User Manual Table 1-1 Components Description Name Fingerprint Scanner Cable Interface of RS-485, Power, LED Control, etc. DIP Switch...
-
Page 11: Chapter 2 Installation
Fingerprint and Card Reader User Manual Chapter 2 Installation 2.1 Introduction for DIP Switch The DIP switch module is shown below. The No. of DIP switch from left to right is 1 ~ 4, representing the RS-485 address. Figure 2-1 DIP Switch Module Table 1-2 Description of DIP Switch Icon Description... -
Page 12: Definition Of Cable
Fingerprint and Card Reader User Manual the DIP switch addresses may be different. 2.2 Definition of Cable The description of 5 cables is shown below. Table 1-3 Description of Cables Color Description Blue RS-485 - Yellow RS-485 + PWR (DC +12V) Black GND (Power Grounding) Black... -
Page 13: Installing Card Reader
Fingerprint and Card Reader User Manual Figure 2-3 Wiring for RS-485 Communication Mode 2.4 Installing Card Reader Before you start: Set the DIP switch. For details, refer to 2.1 Introduction for DIP Switch. Steps:... - Page 14 Fingerprint and Card Reader User Manual Fix the mounting plate on the wall with 2 provided screws. Note: Do not warp the mounting plate when installing. Connect the cables between controller and card reader. For details, refer to 2.3 Wiring Cables.
-
Page 15: Chapter 3 Sound Prompt And Indicator
Fingerprint and Card Reader User Manual Chapter 3 Sound Prompt and Indicator After the card reader is powered on, LED status indicator will turn green and blink for 1 time. Then it will turn red and blink for 3 times. At last the buzzer will send out a beep sound indicating the starting up process is completed. - Page 16 Fingerprint and Card Reader User Manual LED Indicator Status Description prompt for pressing the fingerprint after swiping the card. operation configuring fingerprint. Solid green for 2s The operation of swiping card is valid. Solid red Card reader is working normally. Red and blink for 3 The operation of swiping card is invalid.
-
Page 17: Appendix: Tips For Scanning Fingerprint
Fingerprint and Card Reader User Manual Appendix: Tips for Scanning Fingerprint Recommended Finger Forefinger, middle finger or the third finger. Correct Scanning The figure displayed below is the correct way to scan your finger: You should press your finger on the scanner horizontally. The center of your scanned finger should align with the scanner center. - Page 18 Fingerprint and Card Reader User Manual successfully. You can blow your finger and scan again after drying the finger. Others If your fingerprint is shallow, or it is hard to scan your fingerprint, we recommend you to use other authentication methods. If you have injuries on the scanned finger, the scanner may not recognize.
