Specifications - 90° Module Mod. 19-01-03
Dimensions:
L 700 x W 990 x H 1100 mm
Material/ Colour:
Wood, white coated or painted, satin
Weight:
Approx. 26 kg
Illuminant:
DUAL-MULTICOLOUR RGB LEDs MAX 23 W
LED-Unit:
This product includes built-in LEDs, which
c
can be replaced.
Energy Class:
B
Life Span:
30.000 h
Luminous Flux:
Max. 900 lm
Light Colour:
Multicolour/ white
Voltage:
200 V/ 240 V~ 50 Hz
Cable:
Ca. 4 m
Protection Class:
II
Use:
For indoor use
Specifications - 60° Module Mod. 19-01-04
Dimensions:
L 700 x W 1448 x H 1100 mm
Material/ Colour:
Wood, white coated or painted, satin
Weight:
Approx. 40 kg
Illuminant:
DUAL-MULTICOLOUR RGB LEDs MAX 37 W
LED-Unit:
This product includes built-in LEDs, which
c
can be replaced.
Energy Class:
B
Life Span:
30.000 h
Luminous Flux:
Max. 1450 lm
Light Colour:
Multicolour/ white
Voltage:
200 V/ 240 V~ 50 Hz
Cable:
Ca. 4 m
Protection Class:
II
Use:
For indoor use

Specifications - Buffet 86 Module Mod. 19-01-07

Dimensions:
L 660 x W 1000 x H 1100 mm
Material/ Colour:
Wood, white coated or painted, satin
Weight:
Approx. 25 kg
Illuminant:
DUAL-MULTICOLOUR RGB LEDs MAX 14 W
LED-Unit:
This product includes built-in LEDs, which
c
can be replaced.
Energy Class:
B
Life Span:
30.000 h
Luminous Flux:
Max. 540 lm
Light Colour:
Multicolour/ white
Voltage:
200 V/ 240 V~ 50 Hz
Cable:
Ca. 4 m
Protection Class:
II
Use:
For indoor use

Remote Control 2.4 GHz (Mod. 20-02-02)

Dimensions:
W 53 x L 120 x H 20 mm
Weight:
53 g
Range:
25 m
Radio Frequency:
2.4 GHz
Batteries:
2x AAA (Alkaline only)

Accessory: WIFI-Controller 2.4 GHz (Mod. 20-02-03)

Dimensions:
W 60 x L 90 x H 15 mm
Weight:
42 g
Power Source:
USB, DC/ 5 V, 0.5/1 A
Compatible OS:
Android, iOS
Power:
2.3 W
Range:
25 m
Radio Frequency:
2.4 GHz

Maintenance

• Make sure that the power supply is disconnected
before cleaning.
• Clean the product with a soft, damp cloth only. Do not
use abrasives, alcohol or solvent based cleaners.
• Please remove liquids on painted or coated surfaces im-
mediately.

Disposal/ Ecology

Packaging material and appliance are made from recyclable
materials. Separation of the remaining waste materials into
different types facilitates the recycling of valuable raw materials.
When the appliance is to be no longer used please dispose of it
in the proper manner.
This Symbol on the product indicates that it should not be
disposed in the normal household waste. Please take it
to a recycling point for electrical and electronic applianc-
es to be recycled in a proper manner.
Also rechargeable batteries which are dead or defective should
not be disposed of in the household rubbish; always take them
to a special waste disposal and make an important contribution
to protecting our environment.
Please obtain information on disposal from your local
authority.

Original Packaging

The device can be safely transported in the original
packaging. If insufficient protective packaging is
used, the customer is liable for any damages during
transportation.
PLEASE KEEP THE ORIGINAL PACKAGING AND USE IT,
IF POSSIBLE, IN CASE OF WARRANTY OR RETURN OF
THE EQUIPMENT.
Distribution
www.moree.de
Moree Ltd.
Kaiserswerther Markt 11
40489 Düsseldorf
Germany
Designed and produced by Moree in Germany ©2016
Design Patented. Products are subject to change.
Moree product appliances meet
European safety standards.
Apple, the Apple logo and iPhone are trademarks of Apple Inc., registered
in the U.S. and other countries. App Store is a service mark of Apple Inc..
Android is a trademark of Google Inc.
MODULAR LED BAR SYSTEM
INSTRUCTION MANUAL (EN)
MOD. 19-01-01 - 1M MODULE
MOD. 19-01-02 - 2M MODULE
MOD. 19-01-03 - 90° MODULE
MOD. 19-01-04 - 60° MODULE
MOD. 19-01-07 - BUFFET 86 MODULE
1M MODULE
Mod. 19-01-01
Mod. 19-01-03
BUFFET 86 MODULE
2M MODULE
Mod. 19-01-02
Mod. 19-01-07
LED
+
APP
WIFI
WHITE
ENDCAP LEFT
ENDCAP RIGHT
Mod.19-01-05
Mod.19-01-06
MADE IN GERMANY
MOD. 19-01-08 - BUFFET 110 EXTENSION
MOD. 19-01-05 - ENDCAP LEFT
MOD. 19-01-06 - ENDCAP RIGHT
MOD. 19-01-09 - WHEEL WITH BRAKE
90° MODULE
60° MODULE
Mod. 19-01-04
I
I
I
I
0
0
0
0
ACCESSORY
REMOTE CONTROL
WIFI-CONTROLLER
Mod. 20-02-03
Mod. 20-02-02
Please read the instruction manual fully, before using
the product. Keep it for the entire life of the product.
BUFFET 110 EXTENSION
WHEEL WITH BRAKE
Mod.19-01-08
(Mod. 19-01-09)
