Librestream Onsight Cube Quick Start Manual

CUBE
FRONT VIEW
Illumination
1 Camera 5
Laser Microphone
2 6
3 Buttons 7 Stream LED
4 Thermal Imager 8 Power Button
1 2
8 7
TOP VIEW
PAIRED
HOLD both to unpair
from Host
QUICK START GUIDE
• Onsight Cube
• External Power Adapter
• Magnetic USB charging cable
BACK VIEW
CHARGING Indicator
1
CONNECTION Indicator
2
3 CAMERA MODE Indicator
3
4
5
6
6
STANDALONE
PRESS Start/Stop
local recording
HOLD Toggle Video/
Thermal/Fusion
STANDALONE
PRESS Capture Local
TAP ANY BUTTON TO ACCEPT A CALL
STANDALONE
PRESS Toggle laser
HOLD
Toggle illumination
• Wearable Mount, Straps and Clips
• Headband (for Rugged only)
• Monopod and Phone Attachment
4 Mount Connector
1 CHARGING INDICATOR:
5 Power/USB Port
On Battery Power:
6 Speaker
Green
Orange
Red
Flashing Red <10%
While Battery is Charging:
1
Orange
2
Green
3
CONNECTION STATUS INDICATOR:
2
Blue
4
Blue
Green
White
5
3 CAMERA MODE INDICATOR:
Green
PAIRED
Red
PRESS Start/Stop recording
Orange
on host device
HOLD Toggle Video/
CHARGE THE ONSIGHT CUBE
Thermal/Fusion
Connect the power adapter to the Power Port and
allow the battery to fully charge. When the Cube is
PAIRED
powered off, charging will take approximately 4 hours.
PRESS Capture Picture The battery will charge at a slower rate if the Cube is
powered on.
on Host Device
HOLD
Capture and Share
TURN POWER ON
Press the Power Button for one second
to turn ON the Cube.
TURN POWER OFF
PAIRED
Press the Power Button for one second to turn
PRESS Toggle laser
OFF the Cube. When running on battery, the Cube
HOLD
Toggle illumination
automatically powers off after 5 minutes of inactivity.
>40%
<40%
<20%
<100%
100%
Flashing: Waiting to pair to a host
device over bluetooth
Solid: Wireless is connected but
not paired to host device
Solid: Connected to host device with
a wireless connection
Flashing: Firmware update in progress
Video
Thermal
Fusion
