Transverse Adapter and Inlet Nozzles
Technical Data
R 3/4 Inch
Transverse Adapter:
Outer diameter of inlet pipe:
Inner diameter of inlet pipe:
Pipe length (l
) without thread:
R
Adapter height (h
):
Q
Adapter diameter (d
):
Q
Connection thread:
Flow tolerances achievable with MBASS30:
when loading one PU foam cylinder
when loading two PU foam cylinders
Weight:
Transverse adapter with inlet pipe:
Inlet pipe only:
Material:
Anodized aluminum and POM
Article No.:
Total length (l
):
D
Length when inserted (l
):
A
Outer diameter (d
):
D
Weight depending on nozzle diameter:
Material:
POM (Polyoxymethylene)
Article No.:
Note:
Subject to technical changes
Please do also consult the operating manuals of LKS 30 and
LKS100 and of the used air-conveying devices.
Umweltanalytik Holbach GmbH
Sperberweg 3 D-66687 Wadern
50 mm
46 mm
123 mm
55 mm
64 mm
R 3/4 Inch
± 6 %
± 8 %
675 g
155 g
02-160
70 mm
40 mm
50 mm
100 ~ 130 g
see table on page 3
Issued: 04/2017
Phone: 06874 / 18 22 77
Telefax: 06874 / 18 22 78
Internet: www.holbach.biz
eMail:
info@holbach.biz
Transverse Adapter and Inlet Nozzles
for Air Samplers LKS 30 / LKS100
Adapter head
Inlet Pipe
Operating Manual
Inlet Nozzle
