- Page 1 S Y S E M Variable Speed PTZ Receiver R131VX Installation Manual 2852-00001...
- Page 2 S Y S E M 2852-00001...
- Page 3 Any motorised lens with two individual wires per function driven by 6-12 VDC can be used, however, to ease installation and for optimum Privacy Zone performance the use of the Ernitec motorised zoom lenses Series Q is highly recommended. The following DC pan & tilt heads are compatible:...
-
Page 4: Installation
S Y S E M Installation All connections are shown on Figure 1 at the fold-out page at the back of this manual. Carefully follow the instructions in order not to cause mal-function, damage to the equipment or humans. Incorrect installation will void the warranty and repairs will consequently be invoiced according to current scale charges. - Page 5 S Y S E M Mains connection Mains connection is located on the relay board, terminal J1. The R131VX must be used with a 3-wire mains connection (2W+PE @ min. 0,75 mm PE=yellow/green, neutral=blue). Note: Terminals marked with hazardous live symbol requires installation by an instructed person.
- Page 6 S Y S E M Selection of network Topology In a free topology network, there are no demands as to how the cables are routed between the nodes. It can be point-to-point, bus, star, tree, or a mixture. Termination Free Topology When using free topology, the maximum cable length in one segment is approx.
- Page 7 S Y S E M Repeater If the maximum numbers of nodes (max. 64) or total cable distance are exceeded, a repeater can be added to interconnect two or more network segments. A repeater can also be used to convert from a free topology network to a bus topology network.
- Page 8 S Y S E M ® Network Cable Lengths Free Topology Bus Topology Cable type Max. Node-to-Node/Total Length Max. Total Length TIA/EIA 568A Category 5 250/450 meters 900 meters Belden 8471 400/500 meters 2700 meters Belden 85102 500/500 meters 2700 meters Level IV 400/500 meters 1400 meters...
-
Page 9: Aux Connection
An optional video transmission module for twisted pair or fiber optical cable may be fitted in the R131VX. Refer to the manual supplied with the module for installation instructions. Connections X6-1 & 2 and connector J2 are reserved for internal use within Ernitec only. All jumpers/pin-headers are factory set and should not be altered. -
Page 10: Push Buttons
S Y S E M Mains switch activation Once all cable connections have been done installation is completed by activating the mains switch. This will identify the unit on the network. Prior to activating the mains switch make sure the S111SX Node Manager is running and on-line to the network. Warning: Make sure correct mains voltage 230/115 VAC is selected prior to activating the mains switch. -
Page 11: Fault Finding Guide
S Y S E M Fault finding guide If the quide below suggests new configuation use the S111SX Node Manager to configure the unit. No operation possible v If green “RUN CPU” LED H2 is off check mains fuse F1 located on the relay board. -
Page 12: Technical Specifications
TELEPHONE: (040) 6756 25 0, TELEFAX: (040) 67 56 25 25 E-MAIL: ernitec@aol.com FRENCH OFFICE: ERNITEC FRANCE, N° 29 PARC CLUB DU MILLENAIRE, 1025 RUE HENRI BECQUEREL, 34036 MONTPELLIER CEDEX 1, FRANCE TELEPHONE: (4) 67 15 10 15, TELEFAX: (4) 67 64 01 81 E-MAIL: ernitec@ernitec.fr...
