M A N U A L Instructions for Use and Maintenance LEX Plus 10 Connect Water Softener Innovative solutions for smart people... -
Page 2: Menu Level
The company Hans Sasserath GmbH & Co. KG remains the owner of the copyright of the present instructions manual. No part of this publication may be reproduced, transmitted in any form or by any means or used for competitive ends without prior permission of the author. Instructions of Use and Maintenance LEX Plus 10 Connect Water Softener... -
Page 3: Table Of Contents
Check / Replacement Solenoid Valve 7.1.4 Cleaning Salt Tank 7.1.5 Restart Malfunctions Troubleshooting – LEX Plus 10 Connect General troubleshooting Warranty 10 Technical specifications 11 Spare parts 12 Dimensions 13 Overview 14 Maintenance report Instructions for Use and Maintenance LEX Plus 10 Connect Water Softener... -
Page 4: Safety Instructions
Danger of scalding! Load resistances may become hot in operation and should not be touched. Vent the water softening system right after the connection to the water mains to ensure perfect safety. Instructions of Use and Maintenance LEX Plus 10 Connect Water Softener... -
Page 5: Foreword
The SYR LEX Plus 10 Connect Water Softener is designed to protect pipes and water heaters against lime deposits, which reduce the water flow through the pipes and lead to a high energy consumption. -
Page 6: How The System Works
A water meter integrated in the device records the quantity of produced soft water, which is summed up in the electronic system. When the value set for the raw water hardness is reached, the electronic system triggers the required regeneration process. Instructions of Use and Maintenance LEX Plus 10 Connect Water Softener... -
Page 7: Installation Site Requirements
4. Installation site requirements Follow these instructions in order to prevent any problem with the LEX Plus 10 Connect Water Softener. Install the water softener in a dry room, which is not liable to frost. The ambient temperature should not exceed 30 °C. -
Page 8: Instructions Of Use
Menu - directs you to the main menu Help - offers help and gives explanations regarding the settings. Back - goes back to the previous menu Save - saves the setting Instructions of Use and Maintenance LEX Plus 10 Connect Water Softener... - Page 9 Menu structure – Menu level 1 Touch the start screen to activate the main menu: Start-up, cf. Instructions for instal- lation and start-up 9.1500.27 Instructions for Use and Maintenance LEX Plus 10 Connect Water Softener...
-
Page 10: Menu Level
Press any menu point to access the next submenu. Press „Exit“ to confirm settings you possibly changed and quit the menu In case of submenus including several pages, press the arrow keys to navigate through these menus. Instructions of Use and Maintenance LEX Plus 10 Connect Water Softener... - Page 11 Menu structure – Menu level 2 Instructions for Use and Maintenance LEX Plus 10 Connect Water Softener...
-
Page 12: Service / Service Interruption
Should the main water supply of the water softener be interrupted (main shut-off valve closed or on „bypass“), the power supply of the device has to be interrupted as well. Instructions for Use and Maintenance LEX Plus 10 Connect Water Softener... -
Page 13: Maintenance / Inspection
2 Chlorinator cell 3 Solenoid valve ❸ ❷ * In the LEX Plus 10 Connect, the solenoid valve is mounted on the opposite side. For a durable trouble-free operation of the system, we recommend the maintenance kit 1500.01.900, Maintenance Interval... -
Page 14: Check / Replacement Seal Kit
Replace the second seal, if required. Make sure that the second seal is in correct position - the small strap must be visible on the right side at the top! Re-assemble in reversed order. Instructions for Use and Maintenance LEX Plus 10 Connect Water Softener... -
Page 15: Check / Replacement Chlorinator Cell
Remove the push-in connections. Remove the chlorinator cell. Clean the chlorinator cell with cold and clear water or replace if necessary. Re-assemble in reversed order. Instructions for Use and Maintenance LEX Plus 10 Connect Water Softener... -
Page 16: Check / Replacement Solenoid Valve
Remove both screws of the solenoid valve´s fixing bracket. Remove two further screws from the fixing bracket. Once the solenoid valve is unscrewed from the fixing bracket, it can be replaced. Re-assemble in reversed order. Instructions for Use and Maintenance LEX Plus 10 Connect Water Softener... -
Page 17: Cleaning Salt Tank
Remove the brine line by pushing-in the John-Guest angle‘s grey ring with two fingers and removing the angle with the other hand. Remove both captive nuts. Instructions for Use and Maintenance LEX Plus 10 Connect Water Softener... -
Page 18: Restart
Re-assemble in reversed order. 7.2.5 Restart When using the LEX Plus 10 Connect Single Water Softener, open the bypass valve again, vent the pipe at a close draw-off point and re-plug the device. Restart the device and observe the steps of the instructions „Installation and Start-Up“, chapter „Start-Up“. -
Page 19: Malfunctions
8 bar. to a maximum of 8 bar. The upstream pressure reducing Repair the pressure valve is defective. reducing valve. No pressure reducing valve. Mount a pressure reducing valve. Instructions for Use and Maintenance LEX Plus 10 Connect Water Softener... - Page 20 Contact the manu- facturer. Dirty electrodes. Clean the electrodes. Defective cable connection. Verify the cable connection. The salt reserve is less than Refill salt, wait for two weeks. 30 min. Regenerate. Instructions of Use and Maintenance LEX Plus 10 Connect Water Softener...
-
Page 21: General Troubleshooting
Connect the device. Faulty control unit Replace the control unit. No regeneration of the water softener. Faulty drive motor Contact the manufacturer. Failing power supply Verify the power supply. Instructions for Use and Maintenance LEX Plus 10 Connect Water Softener... -
Page 22: Warranty
Always indicate the model and the serial number of the device. Postal address: Hans Sasserath GmbH & Co. KG Muehlenstrasse 62 D-41352 Korschenbroich Phone +49 2161 6105 - 0 +49 2161 6105 - 20 E-Mail info@syr.de www.syr.de Instructions of Use and Maintenance LEX Plus 10 Connect Water Softener... -
Page 23: Technical Specifications
Flushing water quantity (value measured at 3 bar upstream pressure, may vary with other pressures ) Regeneration time 27 min. 22 m x °dH Volume of the exchanger resin Instructions for Use and Maintenance LEX Plus 10 Connect Water Softener... -
Page 24: Spare Parts
6 Cabinet 1500.01.908 7 Resin bottle 1500.01.904 No figure Cable harness vertical pipe 1500.01.911 Cable harness control head 1500.01.912 Cable harness blending 1500.01.913 Mains adapter control unit 1500.01.915 Tundish 0214.00.908 Instructions of Use and Maintenance LEX Plus 10 Connect Water Softener... - Page 25 3 Chlorinator cell 1500.01.921 1500.01.902 1500.01.920 4 Solenoid valve 5 Drive unit 6 Board control head 1500.01.922 1500.01.903 1500.01.914 1 Turbine 1500.01.919 2 Reed-contact 1500.01.918 3 Pressure sensor 1500.01.917 Instructions for Use and Maintenance LEX Plus 10 Connect Water Softener...
-
Page 26: Dimensions
12. Dimensions Connection flange (DN 20 - 32) not included in delivery! Dimensions (mm) LEX 10 Safety overflow (S1) Flushing water overflow (S2) Instructions of Use and Maintenance LEX Plus 10 Connect Water Softener... -
Page 27: Overview
13. Overview Blending valve 6 Lid salt tank Bypass and blending valve 7 Cover cabinet Bypass valve 8 Salt tank Connection hoses 9 Cabinet Control unit Instructions for Use and Maintenance LEX Plus 10 Connect Water Softener... -
Page 28: Maintenance Report
Check / Exchange optical eye Cleaning / Exchange chlorinator cell Cleaning / Check injector Hans Sasserath GmbH & Co. KG • Muehlenstr. 62 • D-41352 Korschenbroich • Tel. +49 2161 6105-0 • Fax +49 2161 6105-20 • info@syr.de • www.syr.de...
