  • Page 1 Product Manual Barracuda ES.2 SAS ® ST31000640SS ST3750630SS ST3500620SS 100496298 Rev. E April 2009...
  • Page 2 United States and/or other countries. Barracuda ES.2, SeaTools and SeaTDD are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners.

  • Page 3: Table Of Contents

    Scope............... . 1 Standards, compliance and reference documents .
  • Page 4 Seagate Technology support services ........

  • Page 5: Scope

    Scope This manual describes Seagate Technology ® LLC, Barracuda ® ES.2 SAS (Serial Attached SCSI) disk drives. Barracuda ES.2 drives support the SAS Protocol specifications to the extent described in this manual. The SAS Interface Manual (part number 100293071) describes the general SAS characteristics of Barracuda ES.2 and other Seagate SAS drives.
  • Page 6 Barracuda ES.2 SAS Product Manual, Rev. E...

  • Page 7: Standards, Compliance And Reference Documents

    Section 8.3. Standards The Barracuda ES.2 SAS family complies with Seagate standards as noted in the appropriate sections of this manual and the Seagate SAS Interface Manual, part number 100293071. The Barracuda ES.2 disk drive is a UL recognized component per UL1950, CSA certified to CAN/CSA C22.2 No.

  • Page 8: Compliance

    • External modem • Mouse Although the test system with this Seagate model complies with the directives/standards, we cannot guarantee that all systems will comply. The computer manufacturer or system integrator shall confirm EMC compliance and provide the appropriate marking for their product.

  • Page 9: Reference Documents

    In case of conflict between this document and any referenced document, this document takes precedence. Barracuda ES.2 SAS Product Manual, Rev. E Seagate part number: 100293068 Seagate part number: 100293071 X3.270-1996(SCSI-3) Architecture Model Seagate part number: 30553-001 Seagate P/N 30190-001 (under 100 lb.) Seagate P/N 30191-001 (over 100 lb.)
  • Page 10 Barracuda ES.2 SAS Product Manual, Rev. E...

  • Page 11: General Description

    General description Barracuda ES.2 drives combine Tunneling Magnetoresistive (TMR) heads and a Serial Attached SCSI (SAS) interface to provide high performance, high capacity data storage for a variety of systems including engineer- ing workstations, network servers, mainframes, and supercomputers. The Serial Attached SCSI interface is designed to meet next-generation computing demands for performance, scalability, flexibility and high-density storage requirements.

  • Page 12: Standard Features

    Standard features Barracuda ES.2 SAS drives have the following standard features: • Perpendicular recording technology • 1.5 / 3 Gbit Serial Attached SCSI (SAS) interface • Integrated dual port SAS controller • Support for SAS expanders and fanout adapters • Downloadable firmware using the SAS interface •...

  • Page 13: Formatted Capacities

    1,882,972,562 1,876,331,330 2. Seagate drives also may be used at the maximum available capacity at a given block size, but the excess capacity above the guaranteed level will vary between other drive families and from generation to genera- tion, depending on how each block size actually formats out for zone frequencies and splits over servo bursts.
  • Page 14 Barracuda ES.2 SAS Product Manual, Rev. E...

  • Page 15: Performance Characteristics

    Performance characteristics This section provides detailed information concerning performance-related characteristics and features of Bar- racuda ES.2 SAS drives. Internal drive characteristics ST31000640SS Drive capacity 1,000 Read/write data heads Tracks per inch 150,000 Peak bits per inch 1,090k Areal Density Internal data rate 1,287 Sustained data rate Disk rotation speed...

  • Page 16: Format Command Execution Time (Minutes)

    4.2.2 Format command execution time (minutes) ST31000640SS Maximum (with verify) Maximum (without verify) Execution time measured from receipt of the last byte of the Command Descriptor Block (CDB) to the request for a Status Byte Transfer to the Initiator (excluding connect/disconnect). 4.2.3 General performance characteristics Sustainable disk transfer rate*:...

  • Page 17: Prefetch/Multi-Segmented Cache Control

    Prefetch/multi-segmented cache control The drive provides a prefetch (read look-ahead) and multi-segmented cache control algorithms that in many cases can enhance system performance. Cache refers to the drive buffer storage space when it is used in cache operations. To select this feature, the host sends the Mode Select command with the proper values in the applicable bytes in page 08h.

  • Page 18: Prefetch Operation

    If read caching is enabled (RCD=0), then data written to the medium is retained in the cache to be made avail- able for future read cache hits. The same buffer space and segmentation is used as set up for read functions. The buffer segmentation scheme is set up or changed independently, having nothing to do with the state of RCD.

  • Page 19: Reliability Specifications

    Reliability specifications The following reliability specifications assume correct host and drive operational interface, including all inter- face timings, power supply voltages, environmental requirements and drive mounting constraints. Seek error rate: Read Error Rates Recovered Data Unrecovered Data Miscorrected Data Interface error rate: MTBF Annualized Failure Rate (AFR) Preventive maintenance:...

  • Page 20: Seek Errors

    5.1.3 Seek errors A seek error is defined as a failure of the drive to position the heads to the addressed track. After detecting an initial seek error, the drive automatically performs an error recovery process. If the error recovery process fails, a seek positioning error (Error code = 15h or 02h) will be reported with a Hardware error (04h) in the Sense Key.

  • Page 21: S.m.a.r.t

    5.2.4 S.M.A.R.T. S.M.A.R.T. is an acronym for Self-Monitoring Analysis and Reporting Technology. This technology is intended to recognize conditions that indicate imminent drive failure and is designed to provide sufficient warning of a failure to allow you to back up the data before an actual failure occurs. The drive’s firmware monitors specific attributes for degradation over time but can’t predict instanta- Note.

  • Page 22: Predictive Failures

    Error rate is the number of errors per operation. The algorithm that S.M.A.R.T. uses to record rates of error is to set thresholds for the number of errors and their interval. If the number of errors exceeds the threshold before the interval expires, the error rate is considered to be unacceptable.

  • Page 23: Dst Failure Definition

    DST. It is the responsibility of the host application to determine the “not ready” cause. While not technically part of DST, a Not Ready condition also qualifies the drive to be returned to Seagate as a failed drive.

  • Page 24: Product Warranty

    Seagate’s option and at no charge to the customer, if returned by customer at customer’s expense to Seagate’s designated facility in accordance with Seagate’s warranty...

  • Page 25: Product Repair And Return Information

    Seagate will pay for transporting the repair or replacement item to the customer. For more detailed warranty information, refer to the standard terms and conditions of purchase for Seagate products on your pur- chase documentation. The remaining warranty for a particular drive can be determined by calling Seagate Customer Service at 1-800-468-3472.
  • Page 26 Barracuda ES.2 SAS Product Manual, Rev. E...

  • Page 27: Physical/Electrical Specifications

    Physical/electrical specifications This section provides information relating to the physical and electrical characteristics of the drive. AC power requirements None. DC power requirements The voltage and current requirements for a single drive are shown below. Values indicated apply at the drive connector.
  • Page 28 Table 3: DC power requirements ST3750630SS Voltage Regulation Avg idle current DCX Maximum starting current (peak DC) DC 3σ (peak AC) AC 3σ Delayed motor start (max) DC 3σ Peak operating current: Typical DCX Maximum DC 3σ Maximum (peak) DC 3σ...

  • Page 29: Conducted Noise Immunity

    This condition occurs after OOB and Speed Negotiation completes but before the drive has received the Notify Spinup primitive. See paragraph 6.2.1, "Conducted noise immunity." Specified voltage tolerance includes ripple, noise, and transient response. During idle, the drive heads are relocated every 60 seconds to a random location within the band from three-quarters to maximum track.
  • Page 30 Figure 2. Typical ST31000640SS drive +5V and +12V current profiles Figure 3. Typical ST3750630SS drive +5V and +12V current profiles Barracuda ES.2 SAS Product Manual, Rev. E...

  • Page 31: Power Dissipation

    Figure 4. Typical ST3500620SS drive +5V and +12V current profiles Power dissipation Typical power dissipation under idle conditions in 3Gb operation is 8.73 watts (29.79 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 5).
  • Page 32 Figure 5. ST31000640SS (3 Gbit) DC current and power vs. input/output operations per second Figure 6. ST3750630SS (3 Gbit) DC current and power vs. input/output operations per second Figure 7. ST3500620SS (3 Gbit) DC current and power vs. input/output operations per second Barracuda ES.2 SAS Product Manual, Rev.

  • Page 33: Environmental Limits

    Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. Figure 8.

  • Page 34: Relative Humidity

    6.4.2 Relative humidity The values below assume that no condensation on the drive occurs. a. Operating 5% to 95% non-condensing relative humidity with a maximum gradient of 20% per hour. b. Non-operating 5% to 95% non-condensing relative humidity. 6.4.3 Effective altitude (sea level) a.
  • Page 35 >600 cu in (>9,800 cu cm) Drives packaged in single or multipacks with a gross weight of 20 pounds (8.95 kg) or less by Seagate for general freight shipment shall withstand a drop test from 48 inches (1,070 mm) against a concrete floor or equivalent.

  • Page 36: Acoustics

    There will not be any discrete tones more than 10 dB above the masking noise on typical drives when mea- sured according to Seagate specification 30553-001. There will not be any tones more than 24 dB above the masking noise on any drive.

  • Page 37: European Union Restriction Of Hazardous Substances (Rohs) Directive

    6.4.8 European Union Restriction of Hazardous Substances (RoHS) Directive Seagate designs its products to meet environmental protection requirements worldwide, including regulations restricting certain chemical substances. A new law, the European Union Restriction of Hazardous Substances (RoHS) Directive, restricts the presence of chemical substances, including Lead, Cadmium, Mercury, Hexavalent Chromium, PBB and PBDE, in electronic products, effective July 2006.

  • Page 38: Mechanical Specifications

    Mechanical specifications Refer to Figure 9 for detailed physical dimensions. See Section 8.3, “Drive mounting.” Height: Width: Depth: Weight: ST31000640SS ST3750630SS ST3500620SS Figure 9. Physical dimensions 1.028 inches 26.11 mm 4.010 inches 101.85 mm 5.787 inches 146.99 mm 1.53 pounds 0.694 kilograms 1.43 pounds 0.649 kilograms...

  • Page 39: Defect And Error Management

    Defect and error management Seagate continues to use innovative technologies to manage defects and errors. These technologies are designed to increase data integrity, perform drive self-maintenance, and validate proper drive operation. SCSI defect and error management involves drive internal defect/error management and SAS system error considerations (errors in communications between the initiator and the drive).
  • Page 40 The drive firmware error recovery algorithms consists of 11 levels for read recoveries and five levels for write. Each level may consist of multiple steps, where a step is defined as a recovery function involving a single re- read or re-write attempt. The maximum level used by the drive in LBA recovery is determined by the read and write retry counts.

  • Page 41: Sas System Errors

    SAS system errors Information on the reporting of operational errors or faults across the interface is given in the SAS Interface Manual. The SSP Response returns information to the host about numerous kinds of errors or faults. The Receive Diagnostic Results reports the results of diagnostic operations performed by the drive. Status returned by the drive to the initiator is described in the SAS Interface Manual.

  • Page 42: Deferred Auto-Reallocation

    DAR is most effective when AWRE and ARRE are enabled—this is the default setting from the Seagate factory. With AWRE and ARRE disabled DAR is unable to reallocate the failing location and will report an error sense code indicating that a write command is being attempted to a previously failing location.

  • Page 43: Installation

    Installation Barracuda ES.2 disk drive installation is a plug-and-play process. There are no jumpers, switches, or termina- tors on the drive. SAS drives are designed to be used in a host system that provides a SAS-compatible backplane with bays designed to accommodate the drive. In such systems, the host system typically provides a carrier or tray into which you need to mount the drive.

  • Page 44: Cooling

    Cooling The host enclosure must dissipate heat from the drive. You should confirm that the host enclosure is designed to ensure that the drive operates within the temperature measurement guidelines described in Section 6.4.1. In some cases, forced airflow may be required to keep temperatures at or below the temperatures specified in Section 6.4.1.

  • Page 45: Drive Mounting

    (F) is applied to the fourth point. Before mounting the drive in any kind of 3.5-inch to 5.25-inch adapter frame, verify with Seagate Note.
  • Page 46 Barracuda ES.2 SAS Product Manual, Rev. E...

  • Page 47: Interface Requirements

    Interface requirements This section partially describes the interface requirements as implemented on Barracuda ES.2 drives. Addi- tional information is provided in the SAS Interface Manual (part number 100293071). SAS features This section lists the SAS-specific features supported by Barracuda ES.2 drives. 9.1.1 task management functions Table 6 lists the SAS task management functions supported.

  • Page 48: Dual Port Support

    Dual port support Barracuda ES.2 SAS drives have two independent ports. These ports may be connected in the same or differ- ent SCSI domains. Each drive port has a unique SAS address. The two ports run at the same link rate. The first port to successfully complete speed negotiation sets the link rate support by both ports.

  • Page 49: Scsi Commands Supported

    SCSI commands supported Table 8 lists the SCSI commands supported by Barracuda ES.2 drives. Table 8: Commands supported by Barracuda ES.2 SAS family drives Command name Change Definition Compare Copy Copy and Verify Format Unit [1] DPRY bit supported DCRT bit supported STPF bit supported IP bit supported DSP bit supported...
  • Page 50 Table 8: Commands supported by Barracuda ES.2 SAS family drives (continued) Command name Non-medium Error page (06h) Pages Supported list (00h) Read Error Counter page (03h) Read Reverse Error Counter page (04h) Self-test Results page (10h) Background Medium Scan page (15h) Start-stop Cycle Counter page (0Eh) Temperature page (0Dh) Verify Error Counter page (05h)
  • Page 51 Table 8: Commands supported by Barracuda ES.2 SAS family drives (continued) Command name Reassign Blocks Receive Diagnostic Results Supported Diagnostics pages (00h) Translate page (40h) Release Release (10) Request Sense Actual Retry Count bytes Extended Sense Field Pointer bytes Reserve 3rd Party Reserve Extent Reservation Reserve (10)
  • Page 52 Table 8: Commands supported by Barracuda ES.2 SAS family drives (continued) Command name FUA bit Write Long Write Same PBdata LBdata XDRead XDWrite XPWrite Barracuda ES.2 drives can format to 512, 520, 524, or 528 bytes per logical block. Warning. Power loss during flash programming can result in firmware corruption. This usually makes the drive inoperable.

  • Page 53: Inquiry Data

    9.3.1 Inquiry data Table 9 lists the Inquiry command data that the drive should return to the initiator per the format given in the SAS Interface Manual. Table 9: Barracuda ES.2 SAS inquiry data Bytes Data (hex) 0-15 xx** 16-31 32-47 48-63 64-79...

  • Page 54: Current Values

    On standard OEM drives, the saved values are taken from the default values list and stored into the saved values storage location on the media prior to shipping. 3. Current values Current values are volatile values being used by the drive to control its operation. A Mode Select command can be used to change the values identified as changeable values.
  • Page 55 9.3.2.1 ST31000640SS Mode Sense data MODE DATA HEADER: 01 2e 00 10 00 00 00 08 BLOCK DESCRIPTOR: 74 70 6d b0 00 00 02 00 MODE PAGES: 81 0a c0 0b ff 00 00 00 05 00 ff ff 81 0a ff ff 00 00 00 00 ff 00 ff ff 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00...
  • Page 56 9.3.2.2 ST3750630SS Mode Sense data MODE DATA HEADER: 01 2e 00 10 00 00 00 08 BLOCK DESCRIPTOR: 57 54 66 f0 00 00 02 00 MODE PAGES: 81 0a c0 0b ff 00 00 00 05 00 ff ff 81 0a ff ff 00 00 00 00 ff 00 ff ff 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00...
  • Page 57 9.3.2.3 ST3500620SS Mode Sense data MODE DATA HEADER: 01 2e 00 10 00 00 00 08 BLOCK DESCRIPTOR: 3a 38 60 30 00 00 02 00 MODE PAGES: 81 0a c0 0b ff 00 00 00 05 00 ff ff 81 0a ff ff 00 00 00 00 ff 00 ff ff 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00...

  • Page 58: Miscellaneous Operating Features And Conditions

    Miscellaneous operating features and conditions Table 10 lists various features and conditions. A “Y” in the support column indicates the feature or condition is supported. An “N” in the support column indicates the feature or condition is not supported. Table 10: Miscellaneous features Supported Feature or condition...

  • Page 59: Sas Physical Interface

    Figure 12 shows the location of the SAS device connector J1. Figures 13 and 14 provide the dimensions of the SAS device. Details of the physical, electrical, and logical characteristics are provided within this section. The operational aspects of Seagate’s SAS drives are provided in the SAS Interface Manual.. Figure 12. Physical interface...
  • Page 60 5.92 2.00 (3X) 0.30 0.05 (2X) 4.00 0.08 0.15 D 0.30 0.05 (4X) 15.875 1.27 (14X) 0.35MIN Figure 13. SAS connector dimensions 0.80 (6X) 7.62 4.65 0.45 0.03 (7X) 5.08 0.10 M E 42.73 REF. 41.13 0.15 0.20 B SEE Detail1 33.43 0.05 15.875...

  • Page 61: Physical Characteristics

    Detail A 6.10 2.25 0.05 4.85 0.05 0.10 B 4.40 SEE Detail 2 0.35 3.90 0.15 SECTION A - A CONTACT SURFACE FLUSH 0.08 0.05 TO DATUM A 1.23 0.05 Detail 2 0.08 0.05 2.40 Figure 14. SAS connector dimensions 9.4.2 Physical characteristics This section defines physical interface connector.

  • Page 62: Electrical Description

    9.4.4 Electrical description SAS drives use the device connector for: • DC power • SAS interface • Activity LED This connector is designed to either plug directly into a backpanel or accept cables. 9.4.5 Pin descriptions This section provides a pin-out of the SAS device and a description of the functions provided by the pins. Table 12: SAS pin descriptions Signal name...

  • Page 63: Sas Transmitters And Receivers

    9.4.6 SAS transmitters and receivers A typical SAS differential copper transmitter and receiver pair is shown in Figure 15. The receiver is AC cou- pling to eliminate ground shift noise. Transmitter Figure 15. SAS transmitters and receivers 9.4.7 Power The drive receives power (+5 volts and +12 volts) through the SAS device connector. Three +12 volt pins provide power to the drive, 2 short and 1 long.

  • Page 64: Differential Signals

    The Ready LED Out signal is designed to pull down the cathode of an LED. The anode is attached to the proper +3.3 volt supply through an appropriate current limiting resistor. The LED and the current limiting resis- tor are external to the drive. See Table 14 for the output characteristics of the LED drive signals. Table 14: LED drive signal State...
  • Page 65 9.5.2.1.2 Receive eye mask Figure 16 describes the receive eye mask. This eye mask applies to jitter after the application of a single pole high-pass frequency-weighting function that progressively attenuates jitter at 20 dB/decade below a frequency of ((bit rate) / 1.667). Absolute amplitude (in V)
  • Page 66 The leading and trailing edge slopes of figure 16 shall be preserved. As a result the amplitude value of Z1 is less than that given in table 17 and Z1 tion: ---------------------------------------------------------------------------------------------------------------------------------- - where: is the value for Z1 to be used for the tolerance masks; and , X1 , and X2 are the values in table 17 for Z1, X1, and X2.
  • Page 67 9.5.2.2 Transmitter signal characteristics Table 16 specifies the signal requirements at the transmitter end of a TxRx connection as measured into the zero-length test load. All specifications are based on differential measurements. The OOB sequence is performed at signal voltage levels corresponding to the lowest supported transfer rate. Table 16 specifies the signal characteristics.
  • Page 68 9.5.2.3 Receiver signal characteristics Table 17 defines the compliance point requirements of the signal at the receiver end of a TxRx connection as measured into the test loads specified in figure 19 and figure 20. Table 17: Receiver signal characteristics Signal characteristic Jitter (see figure 16) 2 x Z2...
  • Page 69 9.5.2.3.2 Receiver jitter tolerance Table 19 defines the amount of jitter the receiver shall tolerate. Table 19: Receiver jitter tolerance 1.5 Gbps Sinusoidal Deterministic e,f,h jitter jitter 0.10 0.35 a Units are in UI. b The jitter values given are normative for a combination of deterministic jitter, random jitter, and sinusoidal jitter that receivers shall be able to tolerate without exceeding a BER of 10 progressively greater amplitude at lower frequencies, according to the mask in figure 18 with the same deterministic jitter and random jitter levels as were used in the high frequency sweep.

  • Page 70: Transmitter Characteristics

    Table 20: Impedance requirements (Sheet 2 of 2) Requirement Common mode impedance Transmitter source termination Differential impedance Differential impedance imbalance Common mode impedance a All times indicated for time domain reflectometer measurements are recorded times. Recorded times are twice the transit time of the time domain reflectometer signal.
  • Page 71 A combination of a zero-length test load and the transmitter compliance transfer function (TCTF) test load methodology is used for the specification of transmitter characteristics. This methodology specifies the trans- mitter signal at the test points on the required test loads. The transmitter uses the same settings (e.g., pre- emphasis, voltage swing) with both the zero-length test load and the TCTF test load.
  • Page 72 Figure 20 shows the zero-length test load. 50 ohm 10 nF Probe points 10 nF 50 ohm SAS internal connector Figure 20. Zero-length test load Figure 21 shows an ISI loss example at 3.0 Gbps. (dB) Com pliance interconnect m agnitude response and ISI loss exam ple for 3.0 Gbps ISI loss >...

  • Page 73: Receiver Characteristics

    9.5.2.5 Receiver characteristics The drive receiver is A.C. coupled. The receive network terminates the TxRx connection by a 100 ohm equiva- lent impedance as specified in table 20. The receiver operates within a BER of 10 when a SAS signal with valid voltage and timing characteristics is delivered to the compliance point from a 100 ohm source.
  • Page 74 Barracuda ES.2 SAS Product Manual, Rev. E...

  • Page 75: Seagate Technology Support Services

    Seagate Service Centers Presales Support Our Presales Support staff can help you determine which Seagate products are best suited for your specific application or computer system, as well as product availability and compatibility. Technical Support Seagate technical support is available to assist you online at support.seagate.com...

  • Page 76: Usa/Canada/Latin America Support Services

    Seagate Customer Service Operations (CSO) representative for warranty- related issues. Resellers or end users of drive products should contact their place of purchase or Seagate warranty service for assistance. Have your serial number and model or part number available.
  • Page 77 Index Numerics 12 volt pins 59 5 volt pins 59 abort task set function 43 AC coupling 59 AC power requirements 23 ACA active status 54 ACA active, faulted initiator status 54 acoustics 32 active LED Out signal 59 actuator assembly design 7 adaptive caching 54 AFR 8...
  • Page 78 requirements 15 environmental control 32 error management 35 rates 15 errors 35 EU RoHS directive 33 FCC rules and regulations 3 features 8 interface 43 firmware 8 corruption 48 flawed sector reallocation 8 Format command execution time 12 function complete, code 00 43 not supported, code 05 43 reject, code 04 43 Good status 54...
  • Page 79 audible 3 noise immunity 25 non-operating 30 temperature 29 non-operating vibration 32 office environment 32 operating 30 option selection 58 out-of-plane distortion 41 package size 31 package test specification 5 packaged 31 parameter rounding 54 PCBA 41 peak bits per inch 11 peak operating current 23 peak-to-peak measurements 25 performance characteristics...
  • Page 80 operation 54 system chassis 41 task management functions 43 Abort task set 43 Clear ACA 43 Clear task set 43 terminate task 43 task management response codes 43 Function complete 00 43 Function not supported 05 43 Function reject 04 43 task set full status 54 technical support services 71 temperature 29...
  • Page 82 Seagate Technology LLC 920 Disc Drive, Scotts Valley, California 95066-4544, USA Publication Number: 100496298, Rev. E, Printed in USA...
