L I S T E N T O E X T E R N A L S P E A K E R S O R A M P L I F I E R V I A
U S B D A C I N P U T
Your O2+ODAC must be equipped with "Dedicated DAC line-output"
HEADPHONE AMPLIFIER: Bypassed
DAC: In use
FRONT
Move headphones to right 3.5mm jack
to bypass amplifier and mute head-
phones. This connection is important
for optimal line-output performance!
REAR
Connect external speakers or amplifier
to the rear, dedicated 3.5mm or RCA
line-output.
Line-output volume may be adjusted at
your receiving amplifier or from your
PC. Disconnect rear output when using
headphones.
