Physical

Standard and
Motorcycle Pad
SW 8.8K and 20K
Weigh Pad
SW Kart Weigh
Pad
Indicator
(with cables)
Carrying Case

Optional Equipment

15" x 15" Ramp, aluminum, set of four (100342)
This option allows you to drive the car onto the pads in the case that you are not using
a setup rack or jacking the car up.
Lightweight composite ramps (171002)
Lightweight composite ramps with roll-off area (171005)
NiMH Rechargeable Battery (9V) (330101)
Tape Printer (340105)
An external tape printer can be connected to the control box. Call Intercomp for details.
Printer Cable, (170002)
Provides RS232 connection, 25 pin connector
Computer Cable (170136)
Replacement Cables, set of 4 (170135)
Replacement Cable, red (560036)
Replacement Cable, green (560038)
Replacement Cable, white (560037)
Replacement Cable, black (560035)
Dimensions: 15" x 15" x 2.5" / 381 X 381 X 635 mm
Weight: 23 lb / 10.5 kg
Dimensions: 15" x 15" x 4" / 381 x 381 x 100 mm
Weight: 35 lb / 15.9 kg
Dimensions: 10" x 10" x 2" / 254 x 254 x 510 mm
Weight : 6.6 lbs / 3.0 kg
Dimensions : 11" x 8" x 2.7" / 279 x 203 x 685 mm
Weight: 8 lbs / 3.6 kg
Dimensions: 17" x 11" x 7" / 432 x 279 x 178 mm
Material: ABS structural foam
