SB2T
TubBuddy + Tilt
Owners Manual
elimination through innovation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TubBuddy and is the answer not in the manual?

Questions and answers

Summary of Contents for Showerbuddy TubBuddy

  • Page 1 SB2T TubBuddy + Tilt Owners Manual elimination through innovation...
  • Page 3: Table Of Contents

    Exploded Parts ............... 3 Parts List ................ 4 TubBuddy + Tilt Assembly ..........5 TubBuddy + Tilt Setup ............. 13 TubBuddy + Tilt Operation ..........Strut Adjustment ............Cleaning + Maintenance ..........Safety Instructions ............Warranty Information ............34 Registration Form ............
  • Page 4: Exploded Parts

    3 SB2T TubBuddy + Tilt...
  • Page 5: Parts List

    Foot Rest Paddle (Right) Suction Cups Foot Rest Knob Height Adjustment Tubes (Rolling Base) Foot Rest Adjustment Knob Rolling Base Track Calf Strap Primary Brake Lever (Left) Bath Base Leg (Rear) Primary Brake Lever (Right) SB2T TubBuddy + Tilt page 4...
  • Page 6: Tubbuddy + Tilt Assembly

    Swing the arm rest forward so that it locks into position in the arm rest clip. Slide the arm rest lock over the arm rest clip to lock the arm rest in position. page 5 SB2T TubBuddy + Tilt...
  • Page 7 The clip pin which secures the armrest in position stops the armrest from rotating to far. NOTE - The armrest locks should always be used when the armrests aren’t in the swing-away position. SB2T TubBuddy + Tilt page 6...
  • Page 8 By screwing the neck rest handle in a clockwise direction the neck rest attachment will tighten and secure the neck rest height adjustment tube in position. page 7 SB2T TubBuddy + Tilt...
  • Page 9 Screw the foot rest knob into the thread on the footrest connector. Tighten the foot rest knob until the footrest connector is firmly secured in position. SB2T TubBuddy + Tilt page 8...
  • Page 10 When required rotate the footrests inwards to reposition the footrests. Rotate the footrests until the locking pin clicks and secures the footrest back in position. page 9 SB2T TubBuddy + Tilt...
  • Page 11 Ensure the commode bucket is pushed in far enough that the brackets securely hold the commode bucket in position. The commode bucket should be centred under the opening in the cushion. SB2T TubBuddy + Tilt page 10...
  • Page 12 Choose the attachment points you prefer for your lap belt. Slide the washer onto the screw and then insert through the grommet in the lap belt. Screw the lap belt securely into position. page 11 SB2T TubBuddy + Tilt...
  • Page 13 Slide the chest belt through the 2 attachment loops on the back rest. Before use adjust the length of the chest belt to suit the user. SB2T TubBuddy + Tilt page 12...
  • Page 14: Tubbuddy + Tilt Setup

    NOTE - Each height adjustment hole raises the seat base 1”. - Check to ensure all securing clips are fully inserted. - Ensure both height adjustment tubes are aligned at the same height. page 13 SB2T TubBuddy + Tilt...
  • Page 15 If required the height of the bath base track can be raised or lowered depending on the bath threshold height. NOTE - Each height adjustment hole raises the bath base track 1”. SB2T TubBuddy + Tilt page 14...
  • Page 16 Firmly push the wheeled base onto the tongues on the bridge so the secondary brakes are pushed out of the way. Secure the bridge to the wheeled base using the latch in the centre of the bridge track. page 15 SB2T TubBuddy + Tilt...
  • Page 17 NOTE - Do not unscrew the thread more than 1”. If you require more height, raise the bath base track by adjusting the height adjust- ment tubes up or down. SB2T TubBuddy + Tilt page 16...
  • Page 18 Press the clip pin in on the stabilising tube and slide outwards to the correct position. For smaller adjustments unscrew the rubber stopper to firmly secure the bath base in position. page 17 SB2T TubBuddy + Tilt...
  • Page 19: Tubbuddy + Tilt Operation

    Secure the neck rest in the correct position by securely tightening the neck rest handles. NOTE - Ensure both handles are securely tightened prior to use to prevent the neck rest moving. SB2T TubBuddy + Tilt page 18...
  • Page 20 This will allow the castor to move freely again. NOTE - The castor wheels should always be locked when performing transfers . The castor wheels can be rotated forward to make the chair more stable. page 19 SB2T TubBuddy + Tilt...
  • Page 21 NOTE - Before reclining the chair is it important to be confident with the motion and how the chair operates. - The chair has safety stoppers which prevent the chair reclining further than 30°. SB2T TubBuddy + Tilt page 20...
  • Page 22 (bath base or wheeled base). If you leave the bridge attached it prevents the secondary brake from operating correctly. step 8 With your Tubbuddy + Tilt assembled you are now ready to transfer the chair into the bath. Lift and hold the primary brake lever to release the chair.
  • Page 23 10 With your Tubbuddy + Tilt secured in position on the bath base remove the bridge and wheeled base. Release the latch which connects the bridge to the bath base and roll the wheeled base and bridge away.
  • Page 24 11 With your Tubbuddy + Tilt secured in position on the bath base with the bridge and wheeled base removed you have easy access to the user and chair. If required you can adjust how far your TubBuddy + Tilt is reclined by squeezing the tilt handle.
  • Page 25 13 With the bridge and wheeled base re-connected you can transfer the your Tubbuddy + Tilt back onto the wheeled base. Lift and hold the primary brake lever to release the chair. The primary brakes are located on each side of the wheeled and bath base tracks at the front.
  • Page 26 While returning the chair to the up-right position, you will initially need to support a small amount of the users weight. page 25 SB2T TubBuddy + Tilt...
  • Page 27 17 Ensure the primary brake securely locks your Tubbuddy + Tilt in position on the wheeled base before disconnecting the bridge. Unlock the brakes on the castor wheels. Release the latches which connect the bridge to the wheeled base and roll the wheeled base away.
  • Page 28: Strut Adjustment

    If the handle doesn’t return to position freely, use a screw driver to slightly loosen the screw on the tilt handle. This will allow the handle to move freely and will also make the handle easier to squeeze. page 27 SB2T TubBuddy + Tilt...
  • Page 29 Check to ensure that the stainless steel caps on the ends of both of the orange cables are inserted all the way into the cable adjustor as shown. During packaging/shipping and owner setup these parts can sometimes come out. SB2T TubBuddy + Tilt page 28...
  • Page 30 NOTE - Be careful not to unscrew the cable adjustor to far as this will prevent the struts locking in position when the chair is reclined. page 29 SB2T TubBuddy + Tilt...
  • Page 31: Cleaning + Maintenance

    + maintenance It is recommended that your shower chair is serviced annually by your Showerbuddy Dealer or an authorised, competent service agent, in addition: 1. Regularly inspect all parts of the chair for defects. Any defective part should be removed promptly.
  • Page 32: Safety Instructions

    It is important that the user(s), and/or the caregivers of the user(s), learn how to safely operate the Showerbuddy shower chair. The following must be read before use of the Showerbuddy shower chair to ensure the safe operation of your Showerbuddy shower chair: The Owner(s) Manual must be read and understood before using the Showerbuddy shower chair.
  • Page 33 A slippery floor can be caused by dust, water, soap or any substance that doesn’t Transfers should never be attempted with the Showerbuddy allow the tires (tyres) to grip. shower chair positioned on slippery surfaces since the wheel locks can only prevent the wheels from rotating.
  • Page 34 All castor wheel shafts must be adjusted to the same height. Never attempt to change the frame angle by changing the castor position. If the castor wheels are uneven this will cause the chair’s stability to be compromised and may result in tipping. page 33 SB2T TubBuddy + Tilt...
  • Page 35: Warranty Information

    - Do not return the unit to Showerbuddy without first obtaining a Return Authorization Number from Customer Service. - A defective unit must be shipped to Showerbuddy within 14 days of issuance of a Return Authorization Number by Customer Service.
  • Page 36 Our Responsibilities - Showerbuddy’s sole responsibility is to repair or replace, at our discretion, the covered components of the unit. This is the exclusive remedy for consequential or incidental damages. - Upon pre-approval, Showerbuddy may provide exchange services for Warranty returns.
  • Page 37: Registration Form

    Register your Showerbuddy Thank you for purchasing a Showerbuddy product!! About You Salutation Name First Last Your Date of Birth Month Year Address Street Address City State / Province Zip / Postal Code Country Phone Email About Your Product...
  • Page 38 Fax: (888) 312-3645 For all Other Countries Warranties www.showerchairs.co/resources/register-product Register online at: Or you can email it to us. Showerbuddy Global Limited PO Box 494 Waikanae 5250 New Zealand Email: info@showerbuddy.co.nz Phone: (+64) 21 449-806 page 37 SB2T TubBuddy + Tilt...
  • Page 39 All ShowerBuddy products are CE, TUV, ISO9001 and TGA (Australian Government Department of Health and Ageing Therapeutic Goods Administration) certified. Copyright © 2009 by Showerbuddy Global Limited, PO Box 494, Waikanae, 5250, New Zealand. e: info@showerbuddy.co.nz, t: +64 21 449 806.
