9. PACKAGE

9.1.

DIMENSIONS AND SOLDERPADS LAYOUT

RV-1805-C3 Package:
Package dimensions (bottom view):
1
10
All dimensions in mm typical.
9.2.

MARKING AND PIN #1 INDEX

Laser marking RV-1805-C3 Package: (top view)
3,7
0,8 0,3
2 3 4 5
9 8 7 6
#10
#1
Pin 1 Index
Recommended solder pad layout:
0,8 0,8 0,8 0,8
Metal lid is connected to V
Tolerances: unless otherwise specified ± 0.1mm
Drawing: RV-1805-C3_Pack-drw_20181025
Product Date Code
M843A1
1805
Part Designation
0,5
3,7
(pin #6)
SS
#6
#5
RV-1805-C3
