YORKVILLE PSA1S Service Manual

Hide thumbs Also See for PSA1S:

Advertisement

Quick Links

Download this manual See also: Owner's Manual
WORLD HEADQUARTERS
CANADA
U.S.A.
Yorkville Sound Limited
Yorkville Sound Inc.
550 Granite Court
4625 Witmer Industrial Estate
Pickering, Ontario
Niagara Falls, New York
L1W 3Y8 CANADA
14305, USA
Voice: 905-837-8481
Voice: 716-297-2920
Fax: 905-837-8746
Fax: 716-297-3689
SERVICE MANUAL
PSA1S
REV1 + REV2
SMT Disclaimer
Due to the complex nature of the use of SMT installed components
in Yorkville equipment, we highly caution all service technicians in
attempting to repair or replace SMT factory installed components.
Many of these components may be glued prior to initial soldering.
Replacing SMT components requires expensive
specialized de-soldering equipment and training.
Yorkville Sound will repair and replace defective SMT components
to ensure proper quality assurance and installation is maintained.
Manual-Service-PSA1S-00-2v0 ƒ November 7, 2018

Advertisement

loading
Need help?

Need help?

Do you have a question about the PSA1S and is the answer not in the manual?

Questions and answers

Related Manuals for YORKVILLE PSA1S

Summary of Contents for YORKVILLE PSA1S

  • Page 1 Due to the complex nature of the use of SMT installed components 550 Granite Court 4625 Witmer Industrial Estate in Yorkville equipment, we highly caution all service technicians in Pickering, Ontario Niagara Falls, New York attempting to repair or replace SMT factory installed components.
  • Page 2 Link DISCONNECT POWER BEFORE SERVICING! Power DEBRANCHER L’APPEREIL AVANT D’ENLEVER LES COUVERCLES! Protect when flashing MODEL TYPE: YS1099 A-Z1433 / 1v5 230V 120VAC 50Hz 900mA 60Hz 1.8A DESIGNED & MANUFACTURED BY YORKVILLE SOUND • TORONTO, CANADA W W W.YORK VILLE.COM...
  • Page 3 CET APPAREIL DOIT ETRE MIS Á TERRE! DISCONNECT POWER BEFORE SERVICING! DEBRANCHER L’APPEREIL AVANT D’ENLEVER LES COUVERCLES! Mode PSA1S REV 2 A-Z1460 / 2v1 Clip Line 230V 120VAC Spkr 50Hz Limit 60Hz 1.8A 900mA Level DESIGNED & MANUFACTURED BY YORKVILLE SOUND • TORONTO, CANADA...

  • Page 4: Specifications

    Specifications Active or Passive Active Program Power (watts) 1400 Watts Program (2800 Watts Peak) Max SPL (dB) 135dB Peak (129dB Continuous) 37Hz-100Hz Frequency Response (Hz +/- 3db) fixed @ 100Hz Crossover Frequency (Hz) 2x12-inch (Bass Reflex Cabinet) Driver Configuration LF Driver(s) 2x12-inch Ceramic with 3-inch VoiceCoil LF Impedance (ohms) 2x4 Ohm Load...

  • Page 5: Spécifications

    Spécifications Active ou Passive Active 1400 Watts (Pointe: 2800 Watts) Puissance Nominale (watts) 135dB Pointe (129dB Continue) Niveau de Pression Sonore Max (dB) 37Hz-100Hz Réponse en Fréquence (Hz +/- 3db) fixe @ 100Hz Fréquence de Filtre Séparateur (Hz) 2x12-pouces (enceinte Bass Reflex) Configuration des HP 2x12-pouces - céramique avec bobine de 3 pouce Driver(s) pour Fréquences Graves...
  • Page 6 D E S I G N E D & M A N U FA C T U R E D B Y Y O R K V I L L E S O U N D MODEL TYPE:YS1099 FAST DETECT LIMITER SLOW DETECT LINE / SPKR BUFFERS LEVEL LIMITER LOWPASS LOWPASS REF IN POWER CLASS-D POWER PHYSICS SUPPLY CLIP DETECT A-1214 CIRCUIT WOOFER CLASS-D POWER PHYSICS A-1214 WOOFER BLOCK-DIAG-PSA1S-00-1v0...
  • Page 7 M1449 Parts Reference List 10/11/2018 YS # Description YS # Description YS # Description BUT1 8637 ROUND PUSH BUTTON 1/4 BLK 24MM" 6825 1N4148 75V 0A45 DIODE T&R 6123 1/4W 20K0 1%MINI MF T&R RES 5416 470P 50V 10%CAP T&R BEAD 6438 1N4007 1000V 1A0 DIODE T&R 4777 1/4W 21K5 1%...
  • Page 8 M1694 Parts Reference List 10/24/2018 YS # Description YS # Description YS # Description AI-SUB M1694-59 PSA1S AMP/SUPPLY PCB D305 8130 MURS120T3 200V 1A DIO DO214AA SMT R255 7703 W125 82K5 1% 0805 SMT RES BLANK D306 R256 M1694BLANK 2_OZ 2SD 83.13SQIN 1PER ELITE PSA...
  • Page 10 4148 1/4W 1/4W 2N5551 49K9 TO92 6400 5107 2N5551 49K9 TL072 U3:B 4148 MPSA06 1/4W U8:C U3:E U8:B 5103 TL074CN TO92 PSA1S Product 49K9 Power Limiter Preamp PCB# M1449 Sheet Date: Wed May 27, 2015 Rev: YsType: YSL Filename: M1449V03sch.sch2006...
  • Page 11 U13:C TL072 1/4W 5107 Use YS#4007 10K0 10K0 MINI U13:B MINI TO92 1/4W U13:A 113K 10K0 .2in MINI 4148 1/4W 10K0 BAT85 MINI PSA1S Product MCU/Power Supply PCB# M1449 Sheet Date: Wed May 27, 2015 Rev: YsType: YSL Filename: M1449V03sch.sch2006...
  • Page 12 M1449 PCB HISTORY MODEL(S):- PSA1S LEADS & PINS REFERENCE DATE VER# DESCRIPTION OF CHANGE 03-JUN-2011 28-NOV-2011 PC8329 - MARKED 'WOOFER SHUTDOWN' CIRCUIT PARTS AS DNS. - ML LM13600N (YS#6745) MC33079P (YS#6804) 19-DEC-2011 PC8358 - YS#4100 XLR changed to YS#4135. - ML Changed R65/R67 from YS#6459 to YS#5124.
  • Page 13 A-1214 Power Amplifier YS#9702 Important! This module is not repairable In case of failure it needs to be replaced. Please order Yorkville Sound part # 9702 A-1014 Amplifier Pinout Pin 1: Output + Pin 2: Ground Pin 3: Output -...
  • Page 14 R101 R103 4127 9K76 BC560C 1.0W 4148 100U 18uH 100P 17K40 2355 MC33079P AMP A 6489 M1449 2355 T1.5 100N PSA1S TL074CN 4007 T1.5 ZD67 100N 4007 2355 5124 17K40 4148 470P 4148 4162 470R 3817 820R 5124 9K76 4148...
  • Page 15 SEE LAYOUT DIAGRAM M1449 PRODUCTION NOTES 1. RTV must be applied to the following caps: C22,C23,C24,C25,C26,C28,C36,C37,C50. 2. Apply RTV between C22 and C23 as well as between C24 and C25. 3. RTV must be applied to inductor L1. 4. Apply RTV between C53 and R102 and bend C53 over R102 as in picture.
  • Page 16 SEE LAYOUT DIAGRAM LEADS & PINS REFERENCE POTENTIOMETERS AND KNOBS M1449 - POTS LIST 2N5401 (YS#5108) LM13600N (YS#6745) MC33079P (YS#6804) 2N5551 (YS#5107) TL074CN (YS#6889) MODEL(S):- PSA1S MPSA06 (YS#5103) FUNCTION PART# KNOB STYLE MPSA13 (YS#5105) LEVEL 4432 8653 TO-92 "STYLE_P32" BC560C (YS#5102)
  • Page 17 A-1214 Power Amplifier YS#9702 Important! This module is not repairable In case of failure it needs to be replaced. Please order Yorkville Sound part # 9702 A-1014 Amplifier Pinout Pin 1: Output + Pin 2: Ground Pin 3: Output -...

  • Page 18: Power Supply

    POWER SUPPLY TO POWER AMP PCB D301 AC IN SILENT N1305 ES1J DO-214AC W302:2 D304 120V L301 ES1J DO-214AC +175V PSA1S W302:1 CH1422U PSA1S IEC_RECT +202V ES15P W301:6 CH1426U ES15P N1301 +205V ES18P 15UH CH1423U ES18P +202V PSA2S 3128 W301:5...
  • Page 19 CON_HOLE_140 W125 W125 0805 0805 82K5 82K5 PSGND YS#3114 WOOFER 2x12" 4R 600WPGM #7545 PSA1S 2x15" 8R 1000WPGM #7447 PSA2S Variant name not interpreted 15" 4R 2800WPGM #7470 ES15P 18" 6R 1200WPGM #7420 ES18P Woofer Amp Section: ES12P/ES15P/ES18P/ES21P/PSA1S/PSA2S Product(s): PCB#...
  • Page 20 #6686 #6856 #6857 #2496 #2307 Design Information And History Section: THIS SHEET CONTAINS A CHANGE HISTORY LOG, A LIST OF THE POTS & KNOBS AND A LEADS & PINS REFERENCE SECTION. ES12P/ES15P/ES18P/ES21P/PSA1S/PSA2S Product(s): PCB#: Rev#: EML Rev#: Sheet Modified: 2018-10-09 File: History.SchDoc...
  • Page 21 R259 680N D201 C232 R225 5951 R258 U203 400V U206 R268 D214 R218 R262 Q203 C213 2385 C235 R261 340V M1694-PSA1S C221 4181 ZD200 C210 C231 5972 U205 U204 R237 R223 680N D205 IRGP50B60PD 400V Q205 C224 2385 R202 4181...
  • Page 22 YS#: 8837 heatspreader DESC: 6-32X1/2 PAN NO WASHER NEEDED IMPORTANT: Keep the resistors away from the nearby capacitors (C312, C313) CLIP 4 LEADS SHORT ON D300 Assembly Documentation Section: ES12P/ES15P/ES18P/ES21P/PSA1S/PSA2S Product(s): PCB#: Rev#: EML Rev#: Sheet Modified: 2018-10-10 File: Assembly.SchDoc...
  • Page 23 #6686 #6856 #6857 #2496 #2307 Design Information And History Section: THIS SHEET CONTAINS A CHANGE HISTORY LOG, A LIST OF THE POTS & KNOBS AND A LEADS & PINS REFERENCE SECTION. ES12P/ES15P/ES18P/ES21P/PSA1S/PSA2S Product(s): PCB#: Rev#: EML Rev#: Sheet Modified: 2018-10-10 File: History.SchDoc...
  • Page 24 100N 100N 100N 100N GNDA 18V0 INPUT Section: 0805 D1005 0805 0805 0805 0805 0805 0805 0805 0805 Product(s): PSA1S-M1698 CDSF4148 N1010 PCB# Rev# BOM Rev# Sheet -15VIP -15VIP PSA1S-M1698 7967 -15VIP -15VIP -15VIP -15VIP -15VIP -15VIP -15VIP -15VIP -15VIP...
  • Page 25 CHANGE HISTORY POTENTIOMETERS AND KNOBS DATE VER# DESCRIPTION OF CHANGE 15-SEP-2014 07-JUL-2017 9039 Add M1698-PSA1S and M1699-PSA2S POTENTIOMETERS AND KNOBS 14-JUN-2018 9193 R18 from 348k #7687 to 200k #7685 R32 from 4k7 #7860 to 6k2 #8274 FUNCTION POT# STYLE KNOB#...
  • Page 26 C124 C125 PSA1S M1698 R111 C130 R114 R127 R126 4010 C131 R142 C140 R128 C138 C139 6405 R118 R121 C137 R113 4140 R119 6400 R120 6543 PTC1 R181 6408 R107 R196 C129 C126 R122 C127 R123 4063 R159 C136 C135...
  • Page 27 SPECIAL PRODUCTION NOTES SPECIAL PRODUCTION NOTES 1. THIS BOARD IS FOR : M1596 FOR PS12S M1597 FOR PS15S M1598 FOR PS18S M1698 FOR PSA1S M1699 FOR PSA2S SEE SMT JUMPERS TO IDENTIFY 2. ADD RTV TO COMPONENTS WHERE INDICATED Assembly Documentation Section:...
  • Page 28 CHANGE HISTORY POTENTIOMETERS AND KNOBS DATE VER# DESCRIPTION OF CHANGE 15-SEP-2014 07-JUL-2017 9039 Add M1698-PSA1S and M1699-PSA2S POTENTIOMETERS AND KNOBS 14-JUN-2018 9193 R18 from 348k #7687 to 200k #7685 R32 from 4k7 #7860 to 6k2 #8274 FUNCTION POT# STYLE KNOB#...
  • Page 29 XLR MALE PCB MT VERT 24MM BA-SERIES 3074 POWER CORD 3M V-LOCK (N.A) 4"X5" POLYJET LABEL W/PERM ADHESIVE POPLABEL 8545 RECESSED RUBBER BUMPER WITH WASHER 8529 RUBBER FOOT 65 X 20MM 8565 BAR HANDLE ALL METAL RECTANGULAR 9170 STAND ADAPTER CAST Service-QuickGuide-PSA1S 2V0 Page 1...

  • Page 30: Eyebolt Installation

    CALLING ATM FLY-WARES TECHNICAL SERVICES IN THE UNITED STATES AT (310)639-8282 MONDAY THROUGH FRIDAY FROM 9 AM TO 6 PM (PST) OR FAX AT (310)639-8284. YORKVILLE SOUND MAKES NO CLAIMS AS TO THE SAFETY OF THE ENCLOSURES IF RECOMMENDED LOAD LIMITS AND HARDWARE ARE NOT STRICTLY ADHERED TO. NOR DOES IT MAKE ANY SAFETY CLAIMS TO THE RESULTANT INSTALLATION.

  • Page 31: Outils Requis

    SUGGÉRONS D'APPELER LE SERVICE TECHNIQUE DE ATM FLY-WARE AUX ETATS-UNIS AU (310)639-8282 DU LUNDI AU VENDREDI DE 9 AM À 6 PM (HSP) OU PAR FAX AU (310)639-8284. YORKVILLE SOUND NE GARANTIE PAS UNE UTILISATION SÉCURITAIRE DES ENCEINTES SI LES LIMITES DE CHARGE RECOMMANDÉES NE SONT PAS RESPECTÉES ET SI VOUS N'ADHÉREZ PAS STRICTEMENT À...

  • Page 32: Psa1S Service Bulletin: Limiter Update

    PSA1s Service Bulletin: Limiter Update There is a simple change that can be implemented in any PSA1s having a serial number beginning with a 1. This bulletin will illustrate how to easily make this change, which will lead to greater long-term reliability and which will also improve the sound of the PSA1s when the inputs are excessively overdriven.
  • Page 33 (Yorkville Sound can supply you with 2x YS#6123 for this job if you require). 10. Re-assemble the PSA1s and test that it is working. (NOTE: either speaker wire [see image 4] can connect to either amplifier board when re- assembling).
  • Page 34 Yorkville Sound 550 Granite Court Pickering, Ontario Canada L1W 3Y8 www.yorkville.com Auto Attend: (905) 837-8550 Fax: (905) 837-8746...
