Mobile Action Q-Band HR+ User Manual

Device Overview

Wristband

How to wear your Q-Band HR+?

1
Wear Q-Band HR+ on your wrist
Wear the band on your wrist and buckle the
strap at its best length.
4

Charge your Q-Band HR+

2
1
Prior to charging Q-Band HR+, make sure it is securely placed inside the
charging box with the lid closed, and the USB connector is plugged in to a
computer or a power source via a power adapter.
Important Notice:
The product is shipped with the screen and keys locked, and will be unlocked once it is
charged via USB connection. Please make sure the "Charging" icon appears while it is
being charged, indicating the device is connected correctly and getting charged.
Video Demo:
http://ww2.voiis.com/igotu-life/charge/Q-Band-HR
HR+
Touch Button
Optical Sensor
2
Fasten Q-Band HR+ with
buckle strap
Adjust the loop on the band to a proper
position to keep the device from falling off.
(1)Push
4
3
Charging icon
(
Q-68HR
Core
Metallic contact for charging
1.
2.
5
Change the wristband
1
(2)Up
2
1. Remove the wristbands by sliding out both bands from the slots on both sides
of the core.
2. Insert the new bands into the slots on both sides of the core.
Important Notice:
Failure to follow the instructions above might cause damage to the device.
( User Manual
Buckle Strap
3
Detecting your Heart Rate
Please make sure the wristband is worn as tightly as
possible on the wrist without any discomfort, in order
to enhance the accuracy of heart rate signals that
are detected.
Wear the wristband three fingers away from your
wrist. When "-----" text appears on the screen,
please stay still briefly for about 10 seconds to obtain
a heart rate reading.
EN
