  • Page 21 The illustration above is an example of the “SOUND” menu, to enter this menu press the “SYS” button, then select “SOUND”. Here the user can adjust the volume of the key, alarm and trim beeps they can be individually adjusted or all muted (QUIET). Via the “NO POT” entry line a knobs and/or sliders can be used to individually adjust the volume when outside this menu, they can also be combined with haptic if required, of which the strength can also be adjusted in the HAPTIC option.
  • Page 53 At this time press ok to select slot and switch to different slots through ENTER and press ok again and an operation box will pop up for edit, create and delete. Edit: Edit the currently selected slot. Create: Create a new slot below the selected one. Delete: Delete the currently selected slot. Edit of slot. MODEL MENU www.FrSky-rc.com...
  • Page 54 “and”, which means the slot will take effect and participate in the algorithm of mixer control only when the switch is on and it is in corresponding flight mode. If the option of “SW” is “-“, it means on by default. PAGE 2/4 MODEL MENU www.FrSky-rc.com...
  • Page 55 Overview of the mixer edit menu 2/4 menu screen MODEL MENU www.FrSky-rc.com...
  • Page 56 PAGE 3/4 Overview of the mixer edit menu 3/4 menu screen The third interface is for the setting of OFFSET values for five groups. The setting and execution relationship is basically the same as interface 2. MODEL MENU www.FrSky-rc.com...
  • Page 57 PAGE 4/4 Overview of the mixer edit menu 4/4 menu screen MODEL MENU www.FrSky-rc.com...
  • Page 58 This section of the manual goes specifically about predefined helicopters mixes, there are six types of swash plate settings available. During and/or after the creation of a helicopter model, the user can choose preprogramed settings from the second tab to select the desired settings. stole images from futaba need to replaced MODEL MENU www.FrSky-rc.com...
  • Page 59 The Aileron and pitch servos (at 180 degrees) tilt the swashplate left and right. The H-3 TYPE: Has the input points positioned as illustrated. The Aileron and pitch servos (at 80 degrees) tilt the swashplate left and right. The MODEL MENU www.FrSky-rc.com...

  • Page 60: Pitch Curve

    When setting up a model, the user can setup the pitch curve using a special pitch angle measuring tool to acquire the desired setting for each of the available ”FLIGHT MODES”. The operation of this menu is similar MODEL MENU www.FrSky-rc.com...
  • Page 61 “CURVE LIBRARY” and “MIXER”, there will be a more detailed instruction in the “setup guide” on how to use this menu. MODEL MENU www.FrSky-rc.com...

  • Page 62: Throttle Mix

    “rate” options for the two side of the stick，user can set different rates for each flight mode and the possibility to assign the mix to a switch. Overview of the throttle mix menu screen MODEL MENU www.FrSky-rc.com...

  • Page 63: Swash Ring

    NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to check the made changes in the monitor menu, without having to scroll through the menu. MODEL MENU www.FrSky-rc.com...
  • Page 64 NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to check the made changes in the monitor menu, without having to scroll through the menu. MODEL MENU www.FrSky-rc.com...
  • Page 65 "NOR", "IDLE1", "IDLE2", "IDLE3", "HOLD" represent the available flight modes. 6.3· MODEL (AIRPLANE) This section of the manual covers fixed wing airplanes and the predefined mixes that are only shared with glider model types. MODEL MENU www.FrSky-rc.com...
  • Page 66 6.3.1 PITCH CURVE (FIXED-WING) Overview of the pitch curve menu screen MODEL MENU www.FrSky-rc.com...
  • Page 67 NOTE: This feature requires a model that has a variable pitch propeller system. NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to quickly check any changes made. MODEL MENU www.FrSky-rc.com...

  • Page 68: Aileron Differential

    Pay close attention to surface travel near and at the endpoints, incorrect endpoint setup will cause the mix to stop working as intended. NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to quickly check any changes made. MODEL MENU www.FrSky-rc.com...
  • Page 69 NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to quickly check any changes made. MODEL MENU www.FrSky-rc.com...
  • Page 70 Pay close attention to surface travel near and at the endpoints, incorrect endpoint setup will cause the mix to stop working as intended. NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to quickly check any changes made. MODEL MENU www.FrSky-rc.com...
  • Page 71 Pay close attention to surface travel near and at the endpoints, incorrect endpoint setup will cause the mix to stop working as intended. NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to quickly check any changes made. MODEL MENU www.FrSky-rc.com...
  • Page 72 Pay close attention to surface travel near and at the endpoints, incorrect endpoint setup will cause the mix to stop working as intended. NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to quickly check any changes made. MODEL MENU www.FrSky-rc.com...
  • Page 73 Pay close attention to surface travel near and at the endpoints, incorrect endpoint setup will cause the mix to stop working as intended. NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to quickly check any changes made. MODEL MENU www.FrSky-rc.com...
  • Page 74 Pay close attention to surface travel near and at the endpoints, incorrect endpoint setup will cause the mix to stop working as intended. NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to quickly check any changes made. MODEL MENU www.FrSky-rc.com...
  • Page 75 “LEFT_RIGHT” : Allows programing of mix strength (-100/+100%) on both deflection directions, for each of the available channels. Right side of the screen “ACT” : Turns the mix on or off. “SWITCH” : Is used to assign the mix to a switch or knob. MODEL MENU www.FrSky-rc.com...
  • Page 76 NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to check the made changes in the monitor menu, without having to scroll through the menu. MODEL MENU www.FrSky-rc.com...

  • Page 77: Camber Mix

    DOWN” : Allows programing of mix strength (-100/+100) on both deflection directions, for each of the available channels. Right side of the screen “ACT” : Turns the mix on or off. “SWITCH” : Is used to assign the mix to a switch or knob. MODEL MENU www.FrSky-rc.com...
  • Page 78 NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to quickly check any changes made. MODEL MENU www.FrSky-rc.com...
  • Page 79 “UP-DOWN” : Allows programing of mix strength (-100/+100) on both deflection directions, for each of the available channels. Right side of the screen “ACT” : Turns the mix on or off. “SWITCH” : Is used to assign the mix to a switch or knob. MODEL MENU www.FrSky-rc.com...
  • Page 80 “UP-DOWN” : Allows programing of mix strength (-100/+100) on both deflection directions, for each of the available channels. Right side of the screen “ACT” : Turns the mix on or off. “SWITCH” : Is used to assign the mix to a switch or knob. MODEL MENU www.FrSky-rc.com...
  • Page 81 Overview of the elevator->camber 3/3 menu screen MODEL MENU www.FrSky-rc.com...
  • Page 82 Pay close attention to surface travel near and at the endpoints, incorrect endpoint setup will cause the mix to stop working as intended. NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to quickly check any changes made. MODEL MENU www.FrSky-rc.com...
  • Page 83 “UP-DOWN” : Allows programing of two separate deflection rates for each of the available channels. Right side of the screen “ACT” : Turns the mix on or off. “SWITCH” : Is used to assign the mix to a switch or knob. MODEL MENU www.FrSky-rc.com...
  • Page 84 NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to quickly check any changes made. 6.3.13 AIRBRAKE (FIXED-WING) Overview of the airbrake 1/2 menu screen MODEL MENU www.FrSky-rc.com...
  • Page 85 Left side of the screen “ELE2” : Represents the elevator channel, and allows changes fore braking and/ or counter coupling. “FLP-FLP4” : Represents the 4 available flap channels, and allows changes to the deployment position. MODEL MENU www.FrSky-rc.com...
  • Page 86 Right side of the screen “ACT” : Turns the mix on or off. “SWITCH” : Is used to assign the mix to a switch or knob. MODEL MENU www.FrSky-rc.com...

  • Page 87: Snap Roll

    Top of the screen “AIL-AIL4” : Represents the four available aileron channels. ”SWITCH” : Represents the column were switches can be assigned to active to programmed snap-roll function. Bottom of the screen “ACT” : Turns the mix on or off. MODEL MENU www.FrSky-rc.com...
  • Page 88 “SF SW” : The “save switch” option is used to assign a switch to disarm the mix, to prevent accidental operation of the snap roll function. MODEL MENU www.FrSky-rc.com...
  • Page 89 NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to quickly check any changes made. MODEL MENU www.FrSky-rc.com...
  • Page 90 Pay close attention to surface travel near and at the endpoints, incorrect endpoint setup will cause the mix to stop working as intended. NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to quickly check any changes made. MODEL MENU www.FrSky-rc.com...
  • Page 91 Pay close attention to surface travel near and at the endpoints, incorrect endpoint setup will cause the mix to stop working as intended. NOTE: Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again to return to the previous menu. This shortcut allows the user to quickly check any changes made. MODEL MENU www.FrSky-rc.com...

  • Page 92: Motor Curve

    “LINE/SMOOTH” : Are used to manually adjust the shape of the curve. Up to7 segments can be adjusted either via straight lines or smooth curves, depending on the selected option. Right side of the screen Depicts a visual aid to assist the user during programming. MODEL MENU www.FrSky-rc.com...
  • Page 93 CAUTION: We recommend to ALWAYS! Remove the propellers during testing, if this is not possible make sure you take the appropriate safety precautions. MODEL MENU www.FrSky-rc.com...
  • Page 94 CAUTION: Always check for correct system operation, after making changes to flight control related mixes. Pay close attention to surface travel near and at the endpoints, incorrect endpoint setup will cause the mix to stop working as intended. MODEL MENU www.FrSky-rc.com...
  • Page 95 CAUTION: Always check for correct system operation, after making changes to flight control related mixes. Pay close attention to surface travel near and at the endpoints, incorrect endpoint setup will cause the mix to stop working as intended. MODEL MENU www.FrSky-rc.com...
  • Page 96 Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again NOTE: to return to the previous menu. This shortcut allows the user to check the made changes in the monitor menu, without having to scroll through the menu. MODEL MENU www.FrSky-rc.com...

  • Page 97: Rudder Setup

    Pay close attention to surface travel near and at the endpoints, incorrect endpoint setup will cause the mix to stop working as intended. Press and hold the “RTN” button to instantly enter the “Monitor” menu, press “RTN” again NOTE: to return to the previous menu. This shortcut allows the user to quickly check any changes made. MODEL MENU www.FrSky-rc.com...
  • Page 98 “START” : Allows setting up the switch used to activate the INPUT control used to start (not stop) the motor. CAUTION: We recommend to ALWAYS! Remove the propellers during testing, if this is not possible make sure you take the appropriate safety precautions. MODEL MENU www.FrSky-rc.com...
  • Page 99 6.5· MODEL (MULTICOPTER The “MDL” menu of “MULTICOPTER” shares a lot of predefined mixes with the other model types , except for “RUD SET”. The “setup guide” will go in to more detail about how to program a “MULTICOPTER” model. 6.5.1 MODE Overview of the mode menu screen...
  • Page 100 MODEL MENU www.FrSky-rc.com...
  • Page 101 PgDn, then select “GYRO”. Here the user can remotely (only when the installed model hardware support this feature) adjust the gain on a 3 axis gyro on each of the 5 available “FLIGHT MODES” (The default value is 50). MODEL MENU www.FrSky-rc.com...
  • Page 102 6.6· MODEL (CUSTOM Custom model type does contain preassigned mixes and “input map”, as these can both be created using the “MIXER” “LOGIC SWITCHES” and “CURVE LBRARY” menus. It allows the user to start with a clean AETR setup on which he/she can add features as disired. 6.6.1 MIXER Overview of the mixer menu 1/32 screen...
  • Page 103 MODEL MENU www.FrSky-rc.com...
  • Page 104 Here the user can create the basis of the channel, where is coming from (SRC), when it’s active (SW and F.MODE), and how it behaves (METHODE). Page 2/4 Overview of the mixer edit menu 2/4 screen MODEL MENU www.FrSky-rc.com...
  • Page 105 Here the user can modify the limits of the signal, this is similar to setting up “WEIGHT” in “EXPO” and “CURVE LIBRARY”. Up to 5 “WEIGHTS” (W1-5) can be programmed and can be connected with switches, “LOGIC SWITCHES” and “FLIGHT MODES” to determine when it may become active. MODEL MENU www.FrSky-rc.com...
  • Page 106 Page 3/4 Overview of the mixer edit menu 3/4 screen The illustration above is an example of the “MIXER UPDATE” menu, it’s the third of four program pages that can be edited. Here the user can modify the center position of the signal, this is similar to setting up “OFFSET”...
  • Page 107 Overview of the mixer edit menu 4/4 screen MODEL MENU www.FrSky-rc.com...
  • Page 108 “LOGIC SWITCHES” and “FLIGHT MODES” to determine when it may become active. As “WEIGHT” and “OFFSET” are identical programming options as “CURVE LIBRARY” the previous two menu pages can be skipped when the user uses curves created in “CURVE LIBRARY” MODEL MENU www.FrSky-rc.com...

  • Page 109: Telemetry Menu

    TELEMETRY MENU 7.1 TELEMETRY MENU The “TELE” button gives instant access to the telemetry overview menu, here the user can monitor the connected telemetry sensor data. The order of the menu can be changed via the “MDL/TELE SETUP” menu, and the first page set in Screen position is also displayed on the home screen page 1/4. Overview of the telemetry menu 1/8 screen The illustration above is an example of the “TELE”...
  • Page 110 TELEMETRY MENU Overview of the telemetry menu 7/8 screen www.FrSky-rc.com...
