Important!
1. When you receive your Acclaim shower check contents for any freight damage or defect.
2. If this is a Custom Order the size will be in the outside of the box. Check this is correct.
3. Advise Newline on 0508 639 5463 if any damage has occurred or questions on the size
within 8 hours of receiving the goods so this is can be rectified.
4. Do not proceed with installation until resolved as there cannot be a valid claim later.
July 2018
Acclaim Neo
INSTRUCTION MANUAL
CODE: G9632
Advertisement
Related Manuals for NewLine Acclaim Neo
Summary of Contents for NewLine Acclaim Neo
- Page 1 2. If this is a Custom Order the size will be in the outside of the box. Check this is correct. 3. Advise Newline on 0508 639 5463 if any damage has occurred or questions on the size within 8 hours of receiving the goods so this is can be rectified.
- Page 2 DOOR SET / IMPORTANT INFORMATION WARRANTY • Faulty goods are covered under warranty for 5 years. Visit www.newline.co.nz for warranty information. • Breakages incurred during construction are not covered under warranty. • Installations must conform to the instructions to be covered by the warranty.
-
Page 3: Preparation Checklist
Tiling: 1. Newline requires the use of complete systems by licenced/trained applicators. Waterproofing, Tile Adhesive, Grouting and Silicone detailing for full accountability and performance requirements. 2. The tiles must conform to gradients provide with the “ProFinish Tile Tray” to comply to NZ Building Code. - Page 4 EXPLODED VIEW 2 SIDED - CHROME ACCLAIM SHOWER 2 SIDED COMPONENT LIST - CHROME Part Number Part Number 10 Waterbar Clips LH & RH H6355 10mm Fixed Glass Panel 10mm Door Glass B2343 11 Threshold Waterbar A9076 12 Fastening Screw Pack H1665 10mm Glass Hinge Panel Glass Lintel C2879 6 x 40 Pan square screws x 9...
-
Page 5: Installation Layout
INSTALLATION LAYOUT STEP 1 • Identify your installation measurement from the Frame Dimensions Table “A”. Mark the position of the outside of the Wall Profiles on the sill • If this is a custom order the size will be printed on the outside of the packaging •... -
Page 6: Installation
INSTALLATION STEP 2 Fit Fixed Glass Panels 1. Ensure the fixed panel with the cut outs is placed on the side as ordered. 2. Fit the Glass Panels progressively into the Wall Profiles until outer glass edge is at Door line. (Prevents horizontal scratching of inner profiles). - Page 7 INSTALLATION STEP 3 • Apply silicone into end of Side panel floor profiles to hold base at this point when cured. • Take the Waterbar, LH & RH brackets and fit assembly in place. Note: the Waterbar requires a bead of silicone underneath and the brackets sealed to the lower profiles both sides and floor •...
- Page 8 INSTALLATION STEP 4 • Install the glass lintel to the top edge of the glass panels, using four clamps along the top edge of the panels. • Ensure the Door gap remains at 656mm top and bottom. STEP 5 • Re check the glass is still aligned correctly to the Tile Tray. •...
- Page 9 INSTALLATION STEP 6 • Attach the hinges to hinged panel and fix the handle, and then install the door glass. Close the door carefully and adjust for even clearance in the door opening. STEP 7 • Silicone seal the outside boundary as indicated lines. •...
- Page 10 Technokolla 101 2. Strataflex & Rasogum over laps • Newline warrants the performance and integrity of the Profinish Tile Shower Base for 20 years. Non-conformity to installation instructions has the risk of failure. • All Waterproofing and Tile Installation must be installed as per manufactures Specifications as any deviation from the instructions may result in a performance failure.
