Page 2
Table Of Contents Safety, General Care & Maintenence............3 Parts List......................4 Installation & Assembly Bushings to Sleeve................5 Bushing/Sleeve Assembly to Frame..........6 Torsion Springs to Handle..............7 Pawl to Handle..................8 Front Cover to Frame.................10 Securing Bushing/Sleeve Assembly to Frame......11 Top Cover and Seat Post..............12 Limit Pin....................13...
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INFORMATION It is the sole responsibility of the purchaser of Matrix products to instruct all individuals, whether they are the end user or supervising personnel on proper usage of the equipment. It is recommended that all users of Matrix exercise equipment be informed of the following information prior to its use.
Page 4
Parts List SEAT KIT EXPLODED UPDATED G3 SEAT KIT DESCRIPTION QUANITY Rubber Cap M8 Square Nut Bushing Sleeve 22 mm OD Washer 12 mm Snap Ring Left Torsion Spring M5 Flat Washer M5 X 25L SHC Clip Nut Cover Right Torsion Spring Pawl Screw Handle...
Page 5
ASSEMBLY STEP 1: BUSHING/SLEEVE ASSEMBLY Step 1: Assemble two bushings (#3) onto sleeve (#4). Bend four tabs in to secure bushing (#3) onto sleeve (#4)
Page 6
ASSEMBLY STEP 2: BUSHING ASSEMBLY Step 2: Assemble bushing assembly into frame tube. M8 Square nuts must be at top of assembly...
Page 7
ASSEMBLY STEP 3: HANDLE ASSEMBLY Step 3: Assemble springs onto handle. Springs must be oriented as shown Assemble one snap ring and washer to handle shaft before assembling onto frame...
Page 8
ASSEMBLY STEP 4: PAWL ASSEMBLY Step 4: Assemble pawl onto handle shaft. Assemble the pawl under- neath the springs. Reach your hand inside the bushings to support the pawl while bolting it to the handle shaft. NOTE: The text “TOP” must be positioned as shown...
Page 9
ASSEMBLY STEP 4: PAWL ASSEMBLY Step 4: Assemble pawl onto handle shaft. Be sure to use blue Locktite 242 or equivalent threadlocker on M5 X 25L screws that are included.
Page 10
ASSEMBLY STEP 5: COVER ASSEMBLY Step 5: Assemble cover onto frame. 1. Assemble Push-nut onto cover. 2. Assemble cover to frame. Insert bottom edge of cover then rotate up as shown. Secure cover with screw.
Page 11
ASSEMBLY STEP 6: BUSHING/SLEEVE ASSEMBLY Step 6: Secure bushing/sleeve assembly to tube. 1. Secure bushing assembly to frame tube as shown using (4) M8 X 12L screws and washers into the M8 square nuts. 2. Torque two rear screws to 13 N-m/115 in-lbs. Torque two front screws less than rear screws.
Page 12
ASSEMBLY STEP 7: SEAT POST ASSEMBLY Step 7: Assemble cover and seat post. 1. Assemble rubber cap. 2. Rotate handle up to stop and then assemble seat post.
