Gebrauchs- und Montageanleitung
Instructions for installation and use
Instructions de montage et d'emploi
Wichtig: Unbedingt lesen und aufbewahren!
Important: Read these instructions carefully and then store them in a safe place
Important: Lire attentivement et ranger soigneusemnt ce mode d'emploi
Wein-Kühlgerät / Kühl-Gefriergerät
Wine cooler / Fridge -Freezer
Réfrigérateur a vin / Réfrigérateur - Congélateur
Modell: KE 680-1-3T
F
GB
p.: 13-25
26-39
2223 474-31
Advertisement
Table of Contents
Related Manuals for Kuppersbusch KE 680-1-3T
Summary of Contents for Kuppersbusch KE 680-1-3T
- Page 1 Important: Read these instructions carefully and then store them in a safe place Important: Lire attentivement et ranger soigneusemnt ce mode d’emploi Wein-Kühlgerät / Kühl-Gefriergerät Wine cooler / Fridge -Freezer Réfrigérateur a vin / Réfrigérateur - Congélateur Modell: KE 680-1-3T p.: 13-25 26-39 2223 474-31...
-
Page 2: General Safety
WARNINGS It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings. -
Page 3: Environment Protection
• Do not place carbonated or fizzy drinks in the back in the compressor. freezer as it creates pressure on the container, which may cause it to explode, resulting in Environment Protection damage to the appliance. This appliance does not contain gasses which Installation could damage the ozone layer, in either its refrigerant circuit or insulation materials. - Page 4 Use of the fridge Control Panel On/OFF light D. Temperature indicator Fridge button ON/OFF During normal functioning the indicator shows the Temperature setting button (warmest) temperature inside the fridge. Temperature indicator Temperature setting button (coldest) Attention! Super cooling light Super cooling button Difference between the temperature displayed and temperature setting is normal.
- Page 5 Shelf holders Your appliance is equipped with shelf retainers that make it possible to secure the shelves during transportation. To remove them proceed as follows: Move the shelf retainers in the direction of the arrow, raise the shelf from the rear and push it forward until it is freed and remove the retainers.
- Page 6 Use of the Wine cooler Control Panel On/OFF light Attention! Fridge button ON/OFF Temperature setting button (warmest) Difference between the temperature displayed and temperature setting is normal. Especially when: Temperature indicator a new setting has recently been selected Temperature setting button (coldest) the door has been left open for a long time warm food has been placed in the compartment A.
-
Page 7: Using The Wine Cooler
Using the wine cooler Normal operating sounds Wine cooler You may hear faint gurgling or bubbling sounds when the refrigerant is pumped through the coils or To obtain the best performance the temperature can tubing at the rear, to the cooling plate/evaporator or be adjusted between +6 and + 16°C. -
Page 8: Use Of The Freezer
Use of the freezer Control Panel On/OFF light Appliance button ON/OFF Temperature setting button (warmest) Temperature indicator Temperature setting button (coldest) Super frost light Super frost button Alarm reset light Alarm reset button J - L. Temperature setting buttons F. Light ON/OFF The temperature can be adjusted between -15°C G. -
Page 9: Freezing Fresh Food
I. Temperature indicator Operation During normal functioning the indicator shows the Insert the plug in the power socket. Press the button warmest temperature inside the freezer. ON/OFF (G) for the functioning of the whole appliance. The freezer is switched on. Difference until 5°C inside the compartment are quite normal. - Page 10 Storage of frozen food Thawing When first starting-up or after a period out of use, Deep-frozen or frozen food, prior to being used, can before putting the products in the compartment let be thawed in the refrigerator compartment or at the appliance run for at least two hours on the fast room temperature, depending on the time available frost setting, then push again the Super-frost button.
-
Page 11: Maintenance
MAINTENANCE Periods of non-operation Unplug the appliance before carrying out When the appliance is not in use for long periods, any maintenance operation. take the following precautions: Warning remove the plug from the wall socket; This appliance contains hydrocarbons in its cooling unit;... -
Page 12: Customer Service And Spare Parts
Defrosting Frost is automatically eliminated from the evaporator of the refrigerator compartment every time the motor compressor stops, during normal use. The defrost water drains out through a trough into a special container at the back of the appliance, over the motor compressor, where it evaporates. -
Page 13: Installation
INSTALLATION Location The appliance should be installed well away from sources of heat such as radiators, boilers, direct sunlight etc. Electrical connection ATTENTION! It must be possible to disconnect the appliance from Before plugging in, ensure that the voltage and the mains power supply;... - Page 14 KÜPPERSBUSCH HAUSGERÄTE AG Postfach 10 01 32, D-45801 Gelsenkirchen, Küppersbuschstr. 16, D-45883 Gelsenkirchen Telefon: (02 09) 4 01-0, Telefax: (02 09) 4 01-3 03 www.kueppersbusch.de Küppersbusch Ges. m. b. H. Eitnergasse 13, 1231 Wien, Telefon: 01 / 8 66 80-0, Telefax: 01 / 8 66 80 72 www.kueppersbusch.at ·...
