1600 PSI
Electric Pressure Washer
94627-KN
ASSEMBLY, CARE AND
USE INSTRUCTIONS
Model AR 143 S-Q2
READ CAREFULLY
IMPORTANT:
RETAIN THESE INSTRUCTIONS
AND
ATTACH RECEIPT TO MANUAL FOR FUTURE
REFERENCE.
Questions, problems, missing parts?
Before returning to your retailer, call (1-866-235-5112)
or email (info@arnorthamerica.com) our customer
service department. They are available from 8:00 a.m. -
5:00 p.m., CST, Monday - Friday. www.arblueclean.com
Advertisement
Table of Contents
Related Manuals for AR Blue Clean AR 143 S-Q2
Summary of Contents for AR Blue Clean AR 143 S-Q2
- Page 1 1600 PSI Electric Pressure Washer ASSEMBLY, CARE AND USE INSTRUCTIONS Model AR 143 S-Q2 READ CAREFULLY IMPORTANT: RETAIN THESE INSTRUCTIONS ATTACH RECEIPT TO MANUAL FOR FUTURE REFERENCE. Questions, problems, missing parts? Before returning to your retailer, call (1-866-235-5112) or email (info@arnorthamerica.com) our customer service department.
-
Page 2: Table Of Contents
Pump Saver ........................13 Troubleshooting ....................... 14 Limited Warranty ......................15 Replacement Parts List ....................16 PRODUCT SPECIFICATIONS SPECIFICATIONS Max PSI Max GPM Weight (lbs.) Model (lbs/sq. in.) (Gal/per min) Cold Water Volts Amps AR 143 S-Q2 1600 16.3 ✔... -
Page 3: Package Contents
PACKAGE CONTENTS PACKAGE CONTENTS PACKAGE CONTENTS OFF/O ON/I PW909142S 1600 750ml 600ml 450ml 300ml 150ml PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Spray Gun Holster Variable Spray Nozzle Lance Handle Extension Lance Nozzle Cleaning Wire Power Washer Unit 15'' Extension Lance Cord Hook Fixed Brush High Pressure Hose... -
Page 4: Safety Information
SAFETY INFORMATION SAFETY INFORMATION SAFETY INFORMATION Please read and understand this entire manual before 9. DO NOT use your power washer when you are under attempting to assemble and operate product. carefully and only when you are alert. This manual contains information that relates to 10. - Page 5 SAFETY INFORMATION SAFETY INFORMATION SAFETY INFORMATION Protect eyes, lungs, and skin from exposure to 30. NEVER use a water supply to your power washer detergent. that exceeds 150 PSI maximum. 31. NEVER disconnect the high pressure hose from the 26. Warning-If connection is made to a potable water power washer while the system is pressurized.
-
Page 6: Assembly Instructions
PREPARATION PREPARATION PREPARATION Before beginning assembly of product, make sure all Tools Required for Assembly (not included): Phillips parts are present. Compare parts with package contents screwdriver. list and hardware contents list. If any part is missing or damaged, DO NOT attempt to assemble the product. Please call customer service at 1-866-235-5112. - Page 7 ASSEMBLY INSTRUCTIONS OFF/O ON/I 1600 Slide cord hook (D) onto right side, when facing High Pressure Hose Assembly the power washer unit (C) as shown. Screw high pressure hose (E) clockwise onto bottom front of power washer unit (C). Pull back collar and insert Note: This step does not require any screws.
- Page 8 PREPARATION ASSEMBLY INSTRUCTIONS Unlock Lock Extension Lance Installation With spray gun (F) in locked position, attach extension lance (J) directly to spray gun. Insert lance extension into gun, pushing together and turning clockwise simultaneously. Turn the extension collar clockwise Locking Spray Gun (Be fore Lance Installation) to lock into place.
- Page 9 ASSEMBLY INSTRUCTIONS 750ml 600ml 450ml 300ml 150ml Foam Cannon Installation Insert foam cannon (H) into extension lance (J), foam cannon push in and turn clockwise. into high pressure top. If you do not see the straw, look inside the foam cannon and attach it to the high Note: Always lock spray gun when changing pressure top.When using foam cannon, fill it with a the foam cannon to ensurn it does not eject...
-
Page 10: Operating Instructions
OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS OFF/0 OFF/0 ON/I ON/I • Turn the power switch to the “ON” (|) position. The unit will turn on for 1 - 2 seconds and shut off. This is a normal function of the auto start feature. •... - Page 11 OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS Adjusting Soap Levels on Foam Cannon • When using the variable spray nozzle, the spray Twist knob to adjust the level of soap as indicated on pattern and intensity can be adjusted for each task by the top of the Foam Cannon (H).
-
Page 12: Care And Maintenance
CARE AND MAINTENANCE unfolded paper clip), insert the wire into the nozzle hole and move back and forth until debris is dislodged. • Tap quick connect end of lance on hard surface several times. • garden hose and highest pressure available (either standard water nozzle or use your thumb over the nozzle to create water pressure for back Storage... -
Page 13: Pump Saver
ALL climates. It also assists with protection from internal corrosion. The AR Blue Clean part #is: PW64511(16oz. bottle). Order online at Note: Instructions on Pump Saver Bottle are generic www.arblueclean.com... -
Page 14: Troubleshooting
CARE AND MAINTENANCE TROUBLESHOOTING If you have any questions regarding the product,please call customer service at 1-866-235-5112. PROBLEM CORRECTIVE ACTION Unit will not turn on. 1. The GFCI module on the end of the power cord must be plugged directly into an outlet. 2. -
Page 15: Limited Warranty
LIMITED WARRANTY ARE AND MAINTENANCE PROBLEM CORRECTIVE ACTION The power washer the accessories are assembled properly, and the power switch is turned on, the power turns on for washer may turn on for 1 - 2 seconds to prime the pump. It automatically shuts off and 2 seconds, shuts waits for the spray gun trigger to be pressed. -
Page 16: Replacement Parts List
LIMITED WARRANTY REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-866-235-5112, 8:00 a.m. - 5:00 p.m., CST, Monday - Friday or order online at www.arblueclean.com 750ml 600ml 450ml 300ml 150ml PW909142S PART DESCRIPTION PART # PART DESCRIPTION PART # Foam Cannon (25 oz.)
