Installing the Externally Mounted Players' Card Dispenser on

EA SPORTS™ PGA TOUR

This document describes how to install the externally mounted Players' Card dispenser.

GLOBAL VR

cutting an opening in the front of the cabinet.

Kit Contents for Part # 90541-00

Part #

Description

Players' Card Dispenser

Assembly with Vault

115-0003-01

DB25 Ribbon Cable

4600-0062

DB Mounting Posts (2)

USBIO

Nytric Version 1.5 USBI/O Card

(or USBI/O Extreme Card)

115-0074-01

Players' Card Dispenser Harness

44-1100-01

+5/+12 VDC Power Supply*

115-0008-01

AC Power Harness*

115-0079-01

DC Power Harness*

*Power supply and associated harnesses are not required for Canadian cabinets.

Tools Required

• Nutdriver or Wrench

• Phillips Screwdriver

• Drill

• 1/4" and 3/4" Drill Bits

• Pencil

8/8/2005

trademarks are the properties of their respective owners.

Document Part #: 040-0074-01

also offers an internally mounted dispenser (part # 90538-00), which is installed by

Golf Challenge Edition Upgrade Cabinets

Part #

4600-0012

100-0021-01

PLC1.5IS8-C

52-6212-00

040-0074-01

3100-0001

Description

Wood Screws (3)

Cable Ties (2)

Screw-Mounted Cable Tie

1/4-20 x 1-1/4" Bolts with Nuts and

Washers (4)

Button Plugs (2)

Installation Instructions (This Document)

Players' Cards (25)

Pre-paid UPS Mailing Label for Returning

the USBI/O Card to GLOBAL VR

Domestic Use Only)

(for

Page 1 of 7

Need help?

Do you have a question about the PGA TOUR Golf and is the answer not in the manual?

Questions and answers

Summary of Contents for EA Sports PGA TOUR Golf

Page 1 Page 1 of 7 © 2005 GLOBAL VR, INC. All Rights Reserved. Electronic Arts, EA, and EA SPORTS are trademarks or registered trademarks of Electronic Arts Inc. in the U.S. and/or other countries. All rights reserved. PGA TOUR is a trademark of PGA TOUR, INC. and used by permission. Global VR is a registered trademark of Global VR, Inc. All other...
Page 2 Procedures ® CAUTION: GLOBAL VR assumes no liability for any damage or injuries incurred while servicing the cabinet. Only qualified service personnel should perform service and installation of cabinet hardware. Install the Nytric Version 1.5 USBI/O or USBI/O Extreme Card CAUTION: To prevent electrostatic discharge (ESD) damage, handle PCBs by the edges only and use a grounding wrist strap or similar precaution.
Page 3 10. Depending on your computer, you may need to remove the power supply to access the DB25 mounting hole, as shown in Figure 2. To remove the power supply, remove the four mounting screws that are circled in the first part of the picture below. Note: If you prefer, you can purchase a DB25 PC blanking plate, such as PLATE925 from StarTech.com, that will allow you to mount the connector in an unused PCI card bay.
Page 4 Re-Install the Computer 1. Replace the computer in the cabinet and secure it in place. 2. Refer to the figure below to reconnect the cables. Note: Connections are shown for computers with the PS-35BL motherboard. Connector positioning is slightly different on the NB-32 Motherboard. AC Power In Com 1 To Tournament Header...
Page 5 Install the Power Supply (as Needed) Note: Skip this section for Canadian cabinets with electronic coin mechs. They already have a DC power supply installed. 1. Connect the two harnesses to the +5/+12 VDC power supply as shown below: Set Input Voltage (115 or 230) through hole in top.
Page 6 5. Connect the DB25 connector on the dispenser harness to the connector that you installed in the computer. SmartCard Dispenser Harness (Part # 115-0074-01) To SmartCard Dispenser DB37 Port on USB I/O Card in System Computer +5/+12 VDC In From Power Harness DB25 Port on USB I/O Card in System Computer...
Page 7 Harness PN: Harness PN: 115-0074-01 GLO-01111-02 USBI/O Extreme DB37 Port Ground 3 BLK-WHT +5 VDC 23 RED-WHT Trackball Encoder 1B 2 YEL-WHT +5 VDC 21 RED-WHT Ground 1 BLK-WHT Encoder 1A 20 GRN-WHT Encoder 2A 22 VIO-WHT Encoder 2B 4 BLU-WHT +5 VDC 7 Shot Type Button 8...
