Tournament Play Hardware Kit Instructions for
EA SPORTS™ PGA TOUR
Document Part Number: 040-0054-01 Rev. A
This document describes the steps for installing the tournament hardware for an EA SPORTS™
®
PGA TOUR
GOLF Conversion Cabinet. Hardware installation consists of the following steps:
• Convert the Tournament Header (Important: The Tournament Header Controller
Board is required for the system to run tournaments. If you do not have an existing
tournament header, you must still connect the board. See Header Controller Board
Installation for Systems with no Tournament Header on page 2.)
• Install the Card Reader
• Install the Telephone Cable
Once all hardware is installed, you will be ready to register your cabinet for tournament play.
For complete registration information, refer to the Tournament Operator Guide or Online
Tournament Quick-Start Guide for Operators.

Tournament Header Conversion

Perform the steps in this section to convert an old tournament header for use with your converted
EA SPORTS™ PGA TOUR
tournament header, contact GLOBAL VR
The Tournament Header Upgrade Kit contains the following components:
Description
Header Controller Board
Control Harness
Power Harness
Artwork
Mounting Plate
Nylon Screws, 6-32 x 1/4"
Figure 1.
1. Remove the screws from the top of the tournament header and remove the clear plastic that
holds the header artwork in place. Slide the artwork out from in front of the LED board.
Clean the clear plastic.
2. Install the new artwork and replace the clear plastic and screws.
©2004 GLOBAL VR, Inc. All rights reserved. GLOBAL VR and the GLOBAL VR logo are registered trademarks of GLOBAL VR, Inc. All other trademarks
are the property of their respective owners. Electronic Arts, EA SPORTS, and the EA SPORTS logo are trademarks or registered trademarks of
Electronic Arts Inc. in the U.S. and/or other countries. All rights reserved. EA SPORTS™ is an Electronic Arts™ brand. PGA TOUR, and PGA TOUR and
Swinging Golfer Design are trademarks of PGA TOUR, INC. and used by permission.
®
GOLF Conversion Cabinets
®
GOLF cabinet. If you prefer to install a standard GLOBAL VR
®
for ordering information.
Qty
1
1
1
1
1
4
Tournament Header After Upgrade
Part Number
990-0010-01
GLO-D9-R6
V2-420035-00
PGAK-AW-24
37052-00
4600-0030
®
