Owner's Manual
Read Rules for Safe Operation and Instructions Carefully
Working in vicinity of a lead-acid battery is dangerous. Batteries generate explosive gases during normal
battery operation. For this reason, it is of utmost importance that each time before using your charger, you
read this manual and follow the instructions exactly.
WARNING: Handling the cord on this product or cords associated with accessories sold with this product, will expose you to lead, a
chemical known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling.
1.
Before you use your battery charger, be sure to read all
instructions and cautions printed on:
• Battery Charger
• Battery
• Vehicle or unit using battery
2.
Use battery charger on LEAD ACID type rechargeable bat-
teries only, such as used in autos, trucks, tractors, airplanes,
vans, RVs, trolling motors, etc. Charger is not intended to
supply power to low-voltage electrical system other than in
an automotive application.
WARNING: Do not use battery charger for charging dry-
cell batteries that are commonly used with home appliances.
These batteries may burst and cause injury to persons and
damage to property.
3.
Use only attachments recommended or sold by manufac-
turer. Use of non-recommended attachments may result in
fire, electric shock, or injury.
4.
When disconnecting the battery charger, pull by the plug
not by the cord. Pulling on the cord may cause damage to
cord or plug.
5.
Locate battery power cord so it cannot be stepped on, tripped
over, or subjected to damage or stress.
6.
Do not operate charger with damaged cord or plug. Have
cord replaced immediately.
7.
Do not operate charger if it has received a sharp blow, been
dropped, or otherwise damaged in any way. Take it to a
qualified professional for inspection and repair.
8.
Do not disassemble charger. Take it to a qualified profes-
sional when service or repair is required. Incorrect reas-
sembly may result in electric shock or fire.
9.
To reduce risk of electric shock, unplug charger from outlet
before attempting any maintenance or cleaning.
10. Do not use an extension cord unless absolutely necessary.
Use of an improper extension cord could result in fire or
Important Safety Instructions
GENERAL BATTERY SAFETY
SCHUMACHER ELECTRIC CORPORATION
801 BUSINESS CENTER DRIVE • MOUNT PROSPECT, ILLINOIS 60056-2179
Send Warranty Product Repairs to: 1025 E. Thompson, Hoopeston, IL 60942-0280
Call Customer Service if you have questions: 1-800-621-5485
Battery
Charger
Model:
–Save–
electric shock. If an extension cord must be used, make
sure that:
• Pins on plug of extension cord are the same number,
size, and shape as those of plug on charger.
• Extension cord is properly wired and in good electrical
condition.
• Wire size is large enough for AC ampere rating of charger,
as specified below:
Length of cord (feet):
AWG size of cord:
11. Always charge battery in a well ventilated area.
NEVER operate in a closed-in or restricted area without
adequate ventilation.
WARNING: Risk of explosive gas.
12. Locate charger as far away from battery as DC charger
cables permit.
13. Do not expose charger to rain or snow.
14. NEVER charge a frozen battery. If battery fluid (electrolyte)
is frozen, bring into a warm area to thaw before charging.
15. NEVER allow battery acid to drip on charger when reading
specific gravity or filling battery.
16. NEVER set a battery on top of charger.
17. NEVER place charger directly above battery being charged.
Gases from battery will corrode and damage charger.
18. NEVER touch the battery clips together when the charger
is energized.
19. NEVER crank engine with charger attached to battery.
WARNING: Battery chargers get hot during operation and
must have proper ventilation. Air needs to flow around en-
tire charger. Do not set on flammable items like carpeting,
upholstery, paper, cardboard, etc. Will damage leather and
melt plastic and rubber.
1
SS-51A-PE, 10 Amp
Fully Automatic Battery Charger
For 12 Volt Marine Deep Cycle &
Automotive Batteries
25
50
18
18
100
150
16
14
00-00-000558/0103

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SS-51A-PE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Schumacher SS-51A-PE

Summary of Contents for Schumacher SS-51A-PE

  • Page 1 WARNING: Handling the cord on this product or cords associated with accessories sold with this product, will expose you to lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling. Before you use your battery charger, be sure to read all instructions and cautions printed on: •...

  • Page 2: Preparing To Charge

    Metal may cause sparking or short circuit the battery or another electrical device. Sparking may cause an explosion. 7. Always operate battery charger in an open, well- ventilated area. 8. NEVER smoke or allow a spark or flame in the vicinity of the battery or engine.

  • Page 3: Battery Charger Controls

    .7 volts, switch to MANUAL until the ammeter begins to move up scale, than switch back to the de- sired AUTOMATIC position. BATTERY CHARGER CONTROLS IO AMP FULLY AUTOMATIC BATTERY CHARGER FIGURE 3 CHARGER CONTROLS...

  • Page 4: Circuit Breaker

    Initial charge current to the battery is typically 10 Amps. This battery charger is equipped with a self-resetting circuit breaker. This device protects the charger from temporary over- loads. In the event of an overload, the circuit breaker will trip open and after a short cooling off period will reset automatically.

  • Page 5: Operating Instructions: Charging Battery In Vehicle

    NOTE: The negative post is normally grounded. NEGATIVE GROUNDED POST 5A. For negative-grounded vehicle, connect POSITIVE (RED) clamp from battery charger to POSITIVE (POS, P, +) un- grounded post of battery. Connect NEGATIVE (BLACK) clamp to vehicle chassis or engine block away from bat- tery.

  • Page 6: Troubleshooting

    The battery charger is designed to work automatically. However, If a problem does occur, check the following: PROBLEM No meter reading. Charger will not turn on when properly connected to power. Charger will not turn OFF. Meter needle pulses (fluctuates) every few seconds AFTER THREE HOURS without slowing down.

  • Page 7: Maintenance/Cleaning Instructions

    MAINTENANCE/CLEANING INSTRUCTIONS Very little maintenance is required for the battery charger. Follow common sense in wiping the charger clean and store in a clean, dry area. After use, wipe all battery corrosion and other dirt or oil from clamp, cord, and the charger case. Use a dry cloth.

  • Page 8: Important Safety Instructions

    • IMPORTANT SAFETY INSTRUCTIONS • • SAVE THESE INSTRUCTIONS • ELECTRIC CORPORATION 801 BUSINESS CENTER DRIVE • MOUNT PROSPECT, ILLINOIS 60056-2179 Send Warranty Product Repairs to: 1025 E. Thompson Avenue, Hoopeston, IL 60942-0280 Call Customer Service if you have questions: 1-800-621-5485...

  • Page 9: Instrucciones Importantes De Seguridad

    17. Al activar el cargador, NUNCA toque al mismo tiempo las 18. NUNCA junte las pinzas de los cables (una con otra) cuando 19. NUNCA arranque un motor cuando el cargador esté SS-51A-PE, 10 Amperios 12 Voltios Cargador de Acumuladores iguales en cantidad, tamaño y forma a aquéllas del enchufe en el cargador.
  • Page 10 PRECAUCIONES Y SEGURIDAD PERSONALES ADVERTENCIA: Al trabajar con baterías de plomo-ácido, use protección completa de los ojos y protección de la ropa. Cuando usted trabaje con o esté cerca de una batería de plomo-ácido, asegúrese que alguien esté al alcance de su voz o suficientemente cerca como para ayudarlo.

  • Page 11: Battery Charger

    MANUAL hasta que el amperímetro indique una carga en la escala y luego cambie a carga AUTOMATICA. IO AMP FULLY AUTOMATIC BATTERY CHARGER NOTA: Con algunos acumuladores, en especial los que tienen incorporados indicadores de carga y que han sido cargados...

  • Page 12: Lectura Del Amperimetro

    D C AMPS CHARGED CHARGING CHARGE COMPLETE ACUMULADOR COMPLETAMENTE DESCARGADO. La corriente de carga inicial al acumulador es, típicamente, de 10A. Este cargador de batería esta equipado con un interruptor de circuito para auto-restablecimiento. Este dispositivo protege al cargador de cualquier sobrecarga temporal. En el caso que ocurra una sobrecarga, el interruptor de circuito se desenganchará...
  • Page 13 Inspeccione la polaridad de los postes de la batería. La caja de la batería estará marcada por cada poste: POSITIVA (POS, P, +) y NEGATIVA (NEG, N, -). NOTA: El poste positivo de la batería generalmente tiene un diámetro mayor que el poste negativo.
  • Page 14 El cargador de acumuladores está diseñado para funcionar automáticamente. Sin embargo, si ocurre un problema, verifique lo siguiente: PROBLEMA No hay lectura del medidor. El cargador no se enciende (al estar debidamente conectado a corriente). No se APAGA el cargador. La aguja del amperímetro fluctúa seguidamente varios segundos DESPUES DE TRES HORAS sin...
  • Page 15 ESTE PRODUCTO. ESTA GARANTIA LIMITADA NO ES TRANSFERIBLE. Schumacher Electric Corporation garantiza este cargador de batería por dos años a partir de la compra minorista por material o mano de obra defectuosos. La unidad será reparada o reemplazada a la opción del fabricante de ocurrir lo anterior.

  • Page 16: Instrucciones De Seguridad Importantes

    • INSTRUCCIONES DE SEGURIDAD IMPORTANTES • • GUARDE ESTAS INSTRUCCIONES • ELECTRIC CORP. 801 BUSINESS CENTER DRIVE • MOUNT PROSPECT, ILLINOIS 60056-2179 Para reparación del producto baja garantía, envíelo a:1025 E. Thompson, Hoopeston, IL 60942-0280. Para más información comuníquese al Dep. de Servicios al Cliente: 1-800-621-5485...
