Everhard Industries Bloom Laundry Unit Installation Manual

Polymarble Top

x 1

Bloom Assembled Drawer Cabinet x 1

Bloom Return End

Tools Required – Phillips Head Screwdriver

For best results, we recommend that two people assemble this product.

Step 1- Preparing the assembly

While facing the assembled Drawer Cabinet, determine where the washing machine will be positioned. On that

side, insert the Timber Dowels into the suitable holes located along the top and back edge of the side of the

Drawer Cabinet (4 Dowels in total). Insert the Cam Lock Screws into the threaded holes next to the location of the

Dowels. Screw in the Cam Lock Screws in by hand, do not over tighten.

Repeat this process on the Return End.

Insert Cam Locks into the holes on both the Top Brace and Back Brace of the cabinet.

Bloom Laundry Unit Installation Guide

x 1

Page 1 of 2

Contents

Bloom Back Brace x 1

Bloom Top Brace

Timber Dowels

Cam lock Screws

Cam Locks

Blanking Stickers x 14

Plastic Caps

Plastic Grommets x 2

90mm Basket

Waste

x 1

x 8

x 2

x 1

Table of Contents

Need help?

Do you have a question about the Bloom Laundry Unit and is the answer not in the manual?

Page 1 Bloom Laundry Unit Installation Guide Page 1 of 2 Contents Bloom Back Brace x 1 Polymarble Top Bloom Top Brace Timber Dowels Bloom Assembled Drawer Cabinet x 1 Cam lock Screws Cam Locks Blanking Stickers x 14 Plastic Caps Plastic Grommets x 2...
Page 2 Bloom Laundry Unit Installation Guide Page 2 of 2 Step 2 - Assembling the Cabinet Attach both the Top Brace and Back Brace to the Return End by aligning the Timber Dowels and Cam Lock Screws located on the Return End into the holes and Cam Locks located on the Braces. Once the Timber Dowels and Cam Lock Screws are inserted into both the Back Brace and Top Brace, using a Phillips Head Screwdriver turn the Cam Lock clockwise to lock the Cam Lock Screws into place.
